Imsa Advantage 5600x Edgebander

US $14,500.00

Tyler, Texas, United States
Aug 9th

Open on mobile:
QR code

This unit is 22 foot long Manufacture spec info us below This will be local pickup only and we cant guarantee all functions work perfectly we can only state it was being used up until the company closed last monthThe last pic shows the unit on a flat bed wrecker to you give you an idea of the wat we ,moved it and a quick easy way for you to possibly move it. This is local pick up only I M A Advantage 5620 Edgebander.0.4 - 12 mm (1/2") Edgebanding thickness cap., 14 - 55 mm panel thickness, 65 mm min. panel width & 150 mm min. length; automatic magazine for coil, strip & solid edgebanding, HD reinforced guillotine for 3 mm PVC. -- Rapid melt glue system with hopper feed, electronic temperature control and separate applicator roll drive. -- 5-Roller pressure section with (1) large drive and (4) idle rollers, all pneumatically controlled. -- Microprocessor control and line control for workstation function.Equipped with: -- (2) Pre-Milling heads equipped with Diamond premill cutters and driven by 4 HP - 12,000 RPM motor ea. 200 Hz, both w/jump movement and reversible rotation, SIKO digital readouts, particle & debris air jet blower followed by infrared heating zone for panel edge.Workstations: -- Double motor end trim (0.6 HP - 12,000 RPM motors), adjustable 0° - 20° for chamfer cuts. -- Top & bottom flush/radius trimmer (2) 2.5 HP - 12,000 RPM ea. 200 Hz) -- Multi-purpose "MMU" unit acts like a second Fine trimming unit; fine or radius trimming of top & bottom longitudinal edge (0.88 HP - 12,000 RPM ea. 200 Hz). -- Top & bottom profile scrapers for up to 3 mm thick PVC banding, SIKO digital readouts for easy setup (currently set up with 3 mm Radius tooling). -- Top & Bottom glue scraping station; last station: Top & bottom buffing unit (0.33 HP - 1,500 RPM ea. motor) tilts 0° - 30°. -- Siemens SPS AG 95 controller to operate all working stations and machine line control; feed speed 16 MPM (52 FPM). Complete with: 5 KVA (200 Hz) Frequency changer, 80 mm wide track pads, sound enclosure w/interior lighting over all milling units. , 2 glue pots, IMA installed updated flat scraper units

“Just removed from a company that closed down last mint nd was building furniture using equipment up until they closed .Local pickup only”

MPN

02164

Model

Advantage /3212

Brand

IMA

Inventory #

150-LS
