Infrared Receiver Remote Control Receiving Plate Suite Brand New Diy Kits

US $2.94

China, China
Jan 29th

Open on mobile:
QR code

DIY Kit DIY Kit Parameters: 1. Kit Model: HRX2. 2. Operating Voltage: 5V. 3. Output Type: Normally open and normally closed switch. 4. Output Load: Less than 300W. 5. Control Type: Remote + Manual. 6. PCB Material: FR-4 plate. 7. Dimensions: 66.5 (L) * 24 (W) mm. Circuit Schematic: Negative pulse is output when the infrared receiver receives the infrared remote control signal, after inverted by the transistor Q1, through a C2 R5 constituting the pulse width gating circuit, and input to the pulse input terminal of U1 pin 14. U1 connected to the bistable trigger circuit, the status of each input pin 2 of a pulse output flipped once in order to achieve opening, the closed control. Functionality: Successfully assembled, can use any kind of infrared remote control for remote control of the receiver. Press once the relay is energized (disconnected); press the relay disconnected (pull). The manual key functions with the same remote control, press once the relay is energized (disconnected); press again the relay disconnected (pull). The receiver uses a 5V power supply, the first power circuit breaker to pull (disconnect) the second conduction the relay disconnected (pull), this cycle. Package Including: 1Pcs Infrared Receiver Remote Control Receiving Plate Suite Electronic DIY Kits. Payment 1.We accept Paypal only. 2.Please confirm your ebay shipping address is exact after payment. 3.If your purchased is more than £30.00, please offer your phone number with shipping address. Delivery details 1.All item will be shipped by Airmail post within 1 business days. It takes approximately 15-25 days (USA ,CA,AU,UK,DE).other country 15-35 days. 2.Express by EMS ,it must add 25 USD shipping fee, it takes 5-10 workdays for delivery.If you need other Epxress(DHL,Fedex.UPS etc.),please contact us to talk about shipping fee. 3.Once you purchase, please DONOT leave negative, neutral feedback or open any case if you have not received item in 30 days, because we have mentioned the shipping time repeatedly. Contact us ???? 2 1.We offer retail and wholesale services. We can provide products in accordance with your requirements. If you have any questions or something to consult, please send us ebay message. 2.All messages will be answered within 1 business day. If you do not receive our reply, please kindly re-sent your message and we will reply to you as soon as possible. 3.Our aim is to provide Top Level Customer Service, Business hours are 9am to 6pm Beijing time (+8 GMT), Monday to Friday. Engineered for professional eBay sellers! On Nov-14-14 at 23:22:44 PST, seller added the following information:
