Innovative Integration X3-Timing precision timing card PCIe GPS, US $500.00 – Picture 0

Innovative Integration X3-Timing precision timing card PCIe GPS, US $500.00 – Picture 1

Innovative Integration X3-Timing precision timing card PCIe GPS, US $500.00 – Picture 2

Innovative Integration X3-Timing precision timing card PCIe GPS, US $500.00 – Picture 3

Innovative Integration X3-timing Precision Timing Card Pcie Gps

US $500.00

Kalaheo, Hawaii, United States
May 5th

Open on mobile:
QR code

Pulled from working environment. Precision Timing for Sample Rate Generation and Triggering Controls with GPS-disciplined and 1 PPM Reference Clocks Features Clock generation and distribution Four single-ended clock outputs External clock/reference input Low jitter: 0.2 ps jitter RMS Programmable 1.5 kHz to 1 GHz range 10 MHz, 1 ppm frequency reference Optional GPS-disciplined reference Indoor GPS reception under most conditions Four programmable trigger outputs Supports PXI DSTAR, DCLKA, DCLKB, triggers and local bus External trigger input Instant-on configuration XMC Module (75x150 mm) PCI Express (VITA 42.3) Applications Sample clock generation for high speed data acquisition applications Sample clock generation for multi-channel systems Synchronization for distributed systems GPS-coordinated systems Timing Generation (Analog cover and heatsink removed.) Overview The X3-Timing is an XMC I/O module with precision, low-noise clock generation and distribution. The module has 4 output clocks and four output triggers as well as a clock/reference input and a trigger input. The X3-Timing can also act as a system timing card in PXI systems, providing the reference clock, sample clocks and triggering. In the sample clock generation mode, the X3-Timing can generate clocks from 1560 kHz to 1 GHz. The clocks are referenced to GPS, an on-card 1 ppm oscillator, or an external input. The PLL circuit is fully programmable, providing extremely low noise clocks with 0.2 ps RMS jitter typically. The output clocks are phase aligned to within 100 ps. Each output clock is a 1 to 80 subdivision of the PLL or external clock. The optional GPS receiver outputs a 10 MHz reference signal locked to the GPS that is very stable and low noise. This GPS receiver has been specially optimized for the best time stability and receiver sensitivity. The receiver requires only one satellite for time tracking and -186 dBw power, making it able to receive indoors in most conditions. A Windows and Linux application are provided that are used to configure and control the X3-Timing features. Configurations can be stored for instant-on use in the on-card memory. Software tools for host development include C++ libraries and drivers for Windows and Linux. This extremely versatile module is easily adapted for use in virtually any type of system. Our XMC carrier adapters offer conduction and convection cooling and are available for a range of interfaces including Desktop PCI, Desktop PCI Express, Cabled PCI Express, CompactPCI, and PXI/PXI Express. This module is also readily installed into Innovative Integration's eInstrument Embedded PC, SBC-ComEx Single-Board Computer, and Andale Data Loggers.
