INSMA DC 12V 4CH Channel 433Mhz Wireless Remote Control Switch With 2 Transim..., US $82 – Picture 0
INSMA DC 12V 4CH Channel 433Mhz Wireless Remote Control Switch With 2 Transim..., US $82 – Picture 0

Insma Dc 12v 4ch Channel 433mhz Wireless Remote Control Switch With 2 Transim...

US $82

  • US, United States
  • Jun 10th
Open on mobile:
QR code
INSMA DC 12V 4CH Channel 433Mhz Wireless Remote Control Switch With 2 Transimitter Output working way: 1. Self-lock: connect the JP1 with the cutting out cap. 2. Jog: the cutting-out cap is non-occupation, JP1 and JP2 do not connect either. 3. Inter-lock: Connect the Jp2 with the Cutting out cap, Jog: press one button is ON, loosen your finger on the same button is OFF (need one channel switch and one buttons remote control). Self -lock: press one button for one time is ON, press the same button again is OFF (need one channel switch and one buttons remote control). Inter-lock: press one button is ON, press another button is OFF (need one channel switch and 2 buttons remote control). Receiver: 1. Working voltage: DC12V 2. Quiescent condition: Less than 6mA 3. Working temperature: -40 Degree +80 Degree 4. Receiver sensitivity: more than -105dBm 5. Working frequency: 433mhz 6. Output voltage: DC and AC is optional 7. Output current: Less than 3A 8. Max load current: 10A Remote control transmitter: 1. Remote Distance: 200M 2. Operating Voltage: DC 12V 3. Frequency: 433mhz 4. Operating Current: 13 mAh 5. Code Type: Fixed code / Learning code Package include: 2 x Transimitter 1 x Receiver Part Number: INSMA1f40sAMG3 Item Weight: 4 ounces Product Dimensions: 3.7 x 2.2 x 0.1 inches Origin: USA Special Features: DC12V 4CH Channel 433Mhz Batteries Included?: No Batteries Required?: No Shipping Weight: 4 ounces Date First Available: February 29, 2016 high receive sensitivity. it is easy to match the transmitter. The volume is small and the performance is stable and reliable DC 12V 4CH Channel 433Mhz Wireless Remote Control Switch With 2 Transimitter It has 4 Relays which can make the equipment turn or reverse,
