Instek Lcr-8101g Lcr Meter New

US $6,374.72

Elgin, Illinois, United States
Jul 20th

Open on mobile:
QR code

Features: Test Frequency: 20 Hz ~ 1 MHz Large LCD Display with Intuitive User Interface 6-digit Measurement Resolution 0.1% Basic Measurement Accuracy Multiple Step Mode DC Resistance Measurement Comprehensive Measurement Functions Monitoring of DUT Voltage and Current Pass/Fail Test Standard Interface: RS-232 & GPIB Graph Mode Included Accessories: User Manual x 1 Power Cord x 1 LCR-12 x 1 Applications Education Lab and Training Institution Research & Design Quality Assurance Verification The LCR-8101G LCR meter, with test frequency up to 1 MHz, provides accuracy, versatility and high resolution for a wide range of component measurements, even including DC resistance measurement and Voltage/Current monitoring. The Multi-Step function allows on-screen programming of customized measurement sequence with Pass/Fail indication. Each program includes 30 test steps and each test step can be set with selected parameters and test limits. Under Multi-Step operation, a tedious work routine can be done step by step automatically just at a press of a button. With Graph Mode the LCR-8101G displays the component impedance response either over a wide range of test frequency sweep or over a wide range of test voltage sweep in a graph chart. This gives an analysis result of either impedance vs. frequency or impedance vs. applied voltage all at a glance. GPIB and RS-232C interfaces are available as standard for instrument control and test result display on the PC. The rich features of LCR-8000G Series easily make your measurement tasks done at a very competitive price. Wide Frequency Range With Friendly Intuitive User Interface The LCR-8000G Series is designed to perform precision impedance measurements over a wide frequency range of 20Hz ~ 1MHz for LCR-8101G, 20Hz ~ 5MHz for LCR-8105G and 20Hz ~10MHz for LCR-8110G. The instrument is capable of measuring 11 different parameters with 0.1% basic accuracy, which meets the precision measurement requirements of components and modules used in the RF circuits. The large LCD display with single-layer operation menu of LCR-8000G Series provides users with ultimate convenience to plug and play without much learning time. Multi Step Mode The Multi-Step mode is capable of running a series of measurements of a component at a number of user-defined steps in sequence automatically. Total 64 programs can be saved into the non-volatile memory, and each program contains up to 30 test steps. The parameter and Hi/Lo limits can be set respectively for each test step. After a program being properly edited, the instrument can run through all the measurement steps either at a press of the button under the Manual Trigger selection, or automatically run the program by detecting the connection of a DUT under the Auto Trigger selection. When all the test steps are completed, the screen shows the measurement reading of the parameter being selected for each step with Pass, HI, or LO measurement result. Graph Mode The graph function shows the component characteristics in visual manner. Either voltage sweep or frequency sweep can be selected for horizontal scale. Just select the parameter, and set the start/stop voltage or the start/stop frequency of the sweep, LCR -8000G will run through the sequence of measurements and show the results on a graph. This graphical parameter measurement performs the characteristic verification of components and materials over the response to the changes in AC test frequency or AC test voltage without the need of complex programming of an external controller. When the graph gets out of the vertical range, the LCR- 8000G Series can automatically adjust the scale to get full test information. On the graph the marker operation is available for detailed observation. Pass/fail Function with Judgment Alarm In the Pass/Fail test, primary parameter measurement result is compared with user-defined limits and the pass or fail result is then displayed. Three methods, including absolute limit, percentage and delta limit, are available for Hi(high) and Lo(low) limit setting based on the nominal test value. The Pass/Fail test checks whether the parameter measurement result sits within the limits, then display "PASS" for within the limits, or "LO" for lower than the low limit, or "HI" For higher than the high limit. A scale and bar for displaying measurement result is shown at the center of the screen to give a graphical identification, which greatly reduces operator's load in a long time inspection work. This scale and bar also facilitate the adjustment of the variable components. Either Pass or Fail result can be set with a buzzer alarm, which makes component or material sorting easy with sound identification. GUARANTEED QUALITY Payment Terms We accept payment prior to shipping Domestic: Payment methods accepted: PayPal - Preferred Illinois buyers pay appropriate sales tax based on county (Please contact ValueTronics before making payment). International: Payment methods accepted: PayPal All international buyers must request an invoice via email from ValueTronics to include shipping costs before finalizing purchase. Return Policy ValueTronics honors the buyer’s right of refusal for 14 days from receipt. Buyer pays return shipping/packaging of all returns (Domestic and International). Refund is credited to buyer’s account upon verification of unit’s condition. Returns must be shipped with all original accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be cancelled. If you need to return your purchase please contact ValueTronics for a RMA. Shipping & Handling Domestic: Varies by listing (Includes Insurance) All buyers in the continental United States pay a flat rate or determined rate for larger items. Contact us for freight charges where not listed. Insurance is mandatory and included on all shipments.Other shipping methods are available at the request and expense of the buyer. International: Buyer pays all shipping costs. Buyer must request invoice that includes shipping costs before finalizing sale on eBay. Shipping insurance is mandatory on all overseas orders.Your phone number is required for shipping purposes so please provide your phone number with all correspondence. Estimated Delivery: We can usually ship orders within 5 business days of payment receipt. If we can not meet this expectation you will be promptly notified. Many items can be shipped same day. Contact us for more information. Shipping: All items are professionally packed to arrive undamaged. If a purchase is received in damaged condition, you must immediately file a claim with the freight carrier and report the same to us. All packaging materials must be saved for inspection by the carrier representatives. Feedback We pride ourselves on exceptional customer service. With 28 years experience in the industry we proudly extend that expertise to our customers.We respond quickly to all comments and concerns with urgency and professionalism. We ask that if you have any problems with your purchase, please try to resolve it with us directly before leaving us a Neutral or Negative rating on eBay. We have built a sterling reputation based on highly satisfied customers. If you do leave us negative feedback before attempting to resolve the problem with us directly, we reserve the right to deem that as final resolution to that matter and will not accept a return or issue a refund.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Instek
MPN	LCR-8101G
Model	LCR-8101G
