Integral Solutions Int'l-eps-100-esd/cdm Pulse System

US $395.00

Fort Wayne, Indiana, United States
Jan 29th

Open on mobile:
QR code

You are bidding on a Integral Solutions Int'l-EPS-100-ESD/CDM Pulse System.The ISI EPS-100 (ESD/CDM Pulse System), designed specifically for ESD sensitive devices such as (G)MR heads, allows the user to stress these devices with controlled ESD waveforms. When used with ISI QST-2001 systems, magnetic performance of the (G)MR head versus ESD stress can be characterized.The EPS-100 can be used with any or all of the following waveforms: D-CDM (Direct Charged Device Model) HBM (Human Body Model) MM (Machine Model) Custom The unit integrates directly with the QST-2002 systems, or can be used as a stand-alone device. As a stand-alone device, the user can control all functions of the ESD/CDM Pulse System through either a menu or ActiveX programming interface. With relay-switched I/O connections, the ESD Waveform Generator Module can isolate external connections during pulses. The HBM waveform conforms with EIA-JESD22-A114-A specifications. The MM waveform conforms with EIA-JESD22-A115-A specifications. The CDM Module is a Direct CDM (D-CDM) module using a socketed CDM configuration, and conforms with JESD22-C101 specifications. Key Benefits DCDM (Direct Charged Device Model) HBM (Human Body Model) MM (Machine Model) Bipolar voltage range +-100V with 3 mV Resolution Built-in Waveform Monitoring Probe Lightweight, Table Top unit Direct Integration with QST 2002 and Blazer-X5B systems Stand-alone unit with ActiveX programming interface Relay switched device connections for isolation during pulses Guaranteed non-DOA with a 7 day ROR. Buyer pays a $5.00 packaging fee plus shipping from 46835.Unit weight- 8 lbs. PLEASE READ OUR CONDITIONS OF SALE BELOW BEFORE PLACING YOUR BID! Payment & Shipping Terms:NOTE: ITEMS THAT SELL OVER $1000.00 OR MORE,WE PREFER HAVING WIRED FUNDS OR PAY BY CERTIFIED CHECKS.We take wire transfers,cashiers checks,personal or business checks.We also take Paypal payments. Personal or business Checks will take 3 to 5 days to clear. We will NOT ship any item sold until money is received into our bank account and it has cleared.We will have up to 5 business days to ship item once the money is in our account. Because of the amounts of items that we are shipping we will ship out items once a week.If you would like an estimate of shipping, all shipments will be shipped from zip code 46835 and the items estimated weight will be posted in the items description: Actual shipping cost may vary a little bit due to Actual weight once packaged. Please note shipping charges and packaging are not refundable. Transit times may vary according to shipper. NOTE:We ship FedEx unless it is being shipped out of the Country. We ship USPS for International Shipments. We Ship UPS or USPS to Canada. If want your item shipped out by a different carrier please advise. Thank You !! NOTE:We prefer to ship by FedEx. If you insist on UPS or USPS then here are the conditions. After we ship the item we will provide you with a tracking or reference number. After that we are not responsible. Do not contact us to try to track it. As you can tell we are tired of dealing with USPS problems.UPS is OK.But accordling ebay's site we can only use UPS or USPS for figuring a cost of s/h.Which I do not thing is right on their part.But we will use Fedex for shipping unless you specify.Thanks
