Intronix Logicport La1034 34ch Logic Analyzer

US $670

Gainesville, Florida, United States
Oct 29th

Open on mobile:
QR code

Our LA1034 LogicPort logic analyzer fills the void between expensive analyzers with many channels, and inexpensive analyzers with few channels and limited sample rates. The LogicPort provides 34 channels sampled at 500MHz. This includes two state-clock inputs which function as normal sampled channels in timing-mode. The LogicPort logic analyzer's hardware is controlled and powered via your PC's USB 1.1 or 2.0 port for the ultimate in convenience and portability. Features include multi-level sequential trigger capability, qualified state-mode sampling with adjustable setup/hold window, selectable logic sense and threshold, built-in interpreters for CAN, I2C, SPI, 1-wire, RS232 and ISO7816-3 (SIM/Smart Card) protocols and much more. The LogicPort's advanced trigger features allow it to trigger on simple or complex sequences of edges, patterns and bus numerical ranges, as well as on specified pattern, range or pulse durations. You'll find the LogicPort to be feature-rich, yet simple to use. Visit our downloads page to try the free logic analyzer support software for yourself. The installation includes real-world examples of actual acquired data. Explore a 125MHz SDRAM interface sampled at 500MHz, the outputs of a 100MHz A/D converter sampled in state mode, interpreted CAN, I2C, SPI, 1-Wire, SIM and RS232 data streams, activity on a typical Intel processor bus and more. Compare the LogicPort's specifications to those of logic analyzers costing thousands more. With its high-speed sampling, sophisticated trigger capabilities and real-time sample compression, the LogicPort gives the big guys a run for their money!
