Ion Beam Deposition System Versatile Compact Ibd 4 3-inch Targets

US $7200

New Windsor, New York, United States
Jun 6th

Open on mobile:
QR code

NEWLY CONSTRUCTED ION BEAM DEPOSITION SYSTEM , FEATURING A NEW FRAME, AND MANY NEW PARTS. ALSO FEATURING A LIKE-NEW, WATER-COOLED, ELECTRO-POLISHED, VACUUM CHAMBER.ALSO FEATURING A NEARLY-NEW, LIGHTLY USED, COMBINATION OF A VEECO ION SOURCE, AND ION TECH MPS-3000 FC POWER SUPPLY.. NEW MKS M100B00421CR1BV 20 SCCM MFC. 8.0 X 10^-7 TORR RANGE ULTIMATE VACUUM PROVIDED VIA A VERY GOOD CONDITION LEYBOLD TW 250 S TURBO PUMP, BACKED BY A GOOD TO VERY CONDITION EDWARDS E2M-12 TWO STAGE ROUGH PUMP. VACUUM GAUGING PROVIDED BY EXCELLENT CONDITION PFEIFFER PKR 251 COMPACT WIDE RANGE GAUGE AND ASSOCIATED DIGITAL DISPLAY. THE CHAMBER FEATURES TWO LARGE VIEW PORTS, AND A LARGE TOP LID FOR SAMPLE LOADING AND EASY ACCESS TO ALL INTERIOR COMPONENTS. INITIAL PROCESS TESTING WITH AN ALUMINUM TARGET INDICATED DESIRABLE QUALITY DEPOSITION RATE, AND UNIFORMITY OVER A 3 TO 4 INCH BY 3 TO 4 INCH SAMPLE SIZE COATING AREA. WATER COOLED, FOUR TARGET, 3-INCH STANDARD TARGET SIZE, ROTATABLE, SOURCE STAGE, FOR SELECTIVELY, SEQUENTIALLY DEPOSITING UP TO FOUR DIFFERENT MATERIALS WITHOUT BREAKING VACUUM . MICRO-TORR RANGE VACUUMS ACHIEVABLE WELL WITHIN ONE-HOUR OF SAMPLE LOADING. 6.5 INCH DIAMETER, ROTATING SUBSTRATE STAGE WITH SAMPLE HOLDING CLIPS FOR ONE LARGE SAMPLE, OR FOR ONE OR MORE SMALL SAMPLES. INTERLOCK-INTEGRATED, LIGHTED PUSH-BUTTON PANEL FOR SELECTING/ACTIVATING VACUUM PUMPING, CHAMBER VENTING, PROCESS GAS FLOW, TARGET SELECTION 1 THROUGH 4, AND SUBSTRATE ROTATION, ROTARY KNOB FOR ADJUSTING PROCESS GAS FLOW. SYSTEM VOLTAGE IS 208-230 SINGLE PHASE. PRICING INCLUDES DEMONSTRATION AT OUR FACILITY. FREIGHT SHIPPING OR LOCAL PICK-UP DELIVERY OPTIONS. VERY REASONABLE, DESTINATION DEPENDENT, SHIPPING QUOTES PROVIDED UPON REQUEST. SYSTEM COULD POTENTIALLY BE UPGRADED, AND SO AS TO INCLUDE A DEPOSITION RATE SENSOR. PLEASE INQUIRE FOR ANY INTERESTS IN THIS OR ANY OTHER PROSPECTIVE, POTENTIAL UPGRADE. WOULD ALSO CONSIDER TEST SAMPLE COATING REQUESTS.
