Itech Triple Output Power Supply 30v/3a/90w, 30v/3a/90w, 5v/3a/15w Programmable

US $812.97

Denver, Colorado, United States
Jul 15th

Open on mobile:
QR code

Store New Arrivals Add to Favorite View Feedback Contact ITECH Triple Output Power Supply 30V/3A/90W, 30V/3A/90W, 5V/3A/15W Programmable Adjustable DC Bench Power Source 3 Channel with Remote Sense Connectors IT6302 Description Style IT6302: Optional RS232/USB communication interface Triple Output Power Supply: 0~30V / 0~3A / 0~90W x2; 0~5V / 0~3A / 0~15W x1; Resolving: 10mV/1mA ( Voltage: 3-Digit Display; Current: 4-Digit Display) Over-Voltage Protection & Over Temperature Protection 3 output modes of the laboratory power supply: track, series and parallel. IT6302 only supports to set Serial/Parallel mode for CH1 and CH2 in menu operation. Free PC software: IT9000-PV6300 control software. Users can remotely control the programmable power supply. User can program power supply operation time sequence, save data and depict I-t and V-t curves through software. Package contents: Multiple Output DC Power Supply, Certificate, User Manual, Calibration Report, Power Cord ( Notice: The Red and Black Test Line and USB Communication Module are optional accessories, not standard accessories, you can buy these two products in ITECH Electronic store Product Description IT6300 Triple Channels DC power supply IT6300 serie is high-performance programmable triple channels DC power supply, each output voltage and current can be set from 0 to maximum rated output. This bench DC power supply provides series connection, parallel connection and synchronous functions of channels, which increase the output capacity of voltage or current and offer multi-purpose solutions for test. The high resolution can meet the needs of various applications. It is an excellent choice for teaching, R&D departments and manufacturers. Features Three independent and electrically isolated outputs, all are adjustable Switch to control the output status Shut off memory function, 27/36 groups instrument settings for save and recall Monitored by computer software Displays voltage and current settings for all three channels simultaneously Low ripple, low noise, linear regulation Three channels can set to serial/parallel/track mode Intelligent fan control, energy conservation, noise reduction Series and parallel modes combine channels to increase the output voltage or current Tracking mode allows users to set up channels to maintain a programmed ratio Difference between IT6302 and IT6322A Memory: IT6302-27 groups; IT6322A-36 groups Resolution: IT6302-10mV/1mA; IT6322A-1mV/1mA Interface: IT6302-Optional RS232/USB; IT6322A-Built-in RS232/USB Serial/Parallel/Track Mode: IT6302- CH1, CH2; IT6322A- CH1, CH2, CH3 Open or close the key sound You can set the key sound state. If in on mode, then key sound will be there when you press buttons. If in off mode, the beeper will not make a sound. The default set is in on mode. keylock Function Software Softpanel for remote control, test sequence generation, and datalogging available Handle The handle can be adjusted and unloaded to facilitate power test

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ITECH
Type	Does not apply
