Itech8511 Dc Programmable Electronic Load 120v/30a/150w

US $714.39

default, default, Hong Kong
Jan 29th

Open on mobile:
QR code

ITECH 8511 DC Programmable Electronic Load 120V 30A 150W MIB-INSTRUMENTS "Can Buy It Now in my ebay store" IT8511 120V / 30A / 150W High performance and affordable single channel DC electronic load. IT8500 DC electronic loads provide you with the flexibility to test a wide range of applications from power supply, charger to battery. The high resolution voltage(1mV), current(0.1mA) measurement system provides both accuracy and convenience, and eliminates the need for a DMM, external shunts and wiring.IT8500 DC electronic loads are the most cost effective choose in your power testing application. Feature High accuracy and resolution 1mV/0.1mA OCP / OVP / OPP / OTP Protection CC / CV / CR / CW Operation Mode VFD display Free software for remote control Battery test and short test function Intellective fan cooling Convenient numeric keypad GPIB / USB / RS232 Interface Remote sensing capability Self-test at power-on Auto test function without Computer Specifications Input Rating - 150W / 120V / 30A CC-MODE Range 0-3A 0-30A Resolution 0.1mA 1mA Accuracy 0.05%+0.1%FS 0.1%+0.1%FS CR-MODE Range 0.1-99? 100-4K? Resolution 0.01? 1? Accuracy 1%+0.3%FS 1%+0.8%FS CV-MODE Range 0-18V 0-120V Resolution 1mV 10mV Accuracy 0.05%+0.02%FS 0.05%+0.025%FS CW-MODE Range 0-100W 100-150W Resolution 1mW 10mW Accuracy 1%+0.1%FS 1%+0.1%FS V - Measurement Range 0-18V 0-120V Resolution 1mV 10mV Accuracy 0.02% + 0.02%FS 0.02% + 0.025%FS A - Measurement Range 0-3A 0-30A Resolution 0.1mA 1mA Accuracy 0.1% + 0.1%FS 0.2% + 0.15%FS Short Circuit Current ?30A Resistance ?40m? Tempature Operating 0-40°C Battery Test Capacity MAX 999AH Transition Frequency 0.1Hz - 1KHz Dimension(mm) W * H * D 214.5 * 88.2 * 354.6 Standard Accessories AC INPUT CABLE USER Manual Calibration Report Optional Accessories IT-E131 RS232 Communication Cable IT-E132 USB Communication Cable IT-E134 GPIB Communication Cable IT-E151 19" Rack Mount Kit IT-E253 Remote Controller You can buy IT-E131 RS232 Communication Cable on our store. http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=390072915932 Payment Shipping We accept Paypal, credit card through Paypal. Buyer may need to pay for import tax depend on your country's custom. You can ask us for more detail. We ship to international and item will be shipped by airmail from HongKong. Items are shipped within 2-3 business day after receive cleared payment. An additional USD8 for insurance Most item will arrive within 8-14 business days. It depend on your location. In some case, ship to some countries will take over 3 weeks, especially brazil, Italy and France . Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Aug-12-14 at 02:35:13 PDT, seller added the following information: Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
