Itw Model 3924 Helical Lead Measuring Instrument

US $5700

  • Lincolnwood, Illinois, United States
  • Jun 2nd
Open on mobile:
QR code
ITW Model 3924 Helical Lead Measuring Instrument Specification Description Nominal gear diameter 24" Min. Gear Diameter 1/4" Max. Apron Travel (w/sine bar set at 0°) 10-1/2" Max. Angular Headstock Rotation (w/sine bar set at 90°) 140° Max. Distance between Centers 36" Min. Distance between Centers 0" Max. Distance Work can be checked from Headstock Center 36" Length 82" Depth 48" Height 54" Weight 5,400 lbs Equipped With: Power Driven Sine Bar Unit For Setting Proper Angle Using Vernac Optical Setting Device. Manufactured Gear And Gage R1004 Electric Recording System With 200, 250, 400, 500, 800 And 1000X Magnification. Tailstock With Positioning And Center. Headstock With Direct Feed To Sine Bar For Correct And Rigid Positioning And Movements. Sine Bar Drive Forward/Reverse. Instrument Stand With 2-Axis Positioning. Notes: The ITW tester appears to be in very good condition and can be inspected under power on our floor.  All of the equipment shown is included.   Shipping: We will load the machine on flat be truck at no additional charge.  No Vans.  No Containers.
