Ixia Optixia Ngy-np8-01, 10 Gigabit Application Network Processor Load Module

US $26,999.99

Granada Hills, California, United States
Jun 27th

Open on mobile:
QR code

ZOMBIE COMPONENTSTHE LARGEST IXIA RESELLER ON EBAY IXIA OPTIXIA NGY-NP8-01, 10 GIGABIT APPLICATION NETWORK PROCESSOR LOAD MODULE NGY-NP8-01 Ixia's NGY-NP family of load modules is the industry’s highest performing density application traffic generation solution. It offers complete layer 2-7 packet generation, and routing and application testing functionality in a single load module. NGY-NP combines the CPU processing and Ixia’s unique NP (network processor) architecture to create a scalable, high-performance application traffic generation platform, emulating up to 40Gbps of data traffic. Each 10GbE port uses multiple network processors, a powerful RISC processor running Linux, and a complete TCP/IP stack – all of which are optimized for layer 4-7 testing. Each test port also supports wire-speed layer 2-3 traffic generation and analysis, and high-performance routing/bridging protocol emulation in conjunction with true layer 4-7 application subscriber emulation and traffic generation. NGY-NP is available in 2-port, 4-port and 8-port configurations offering a wider range of price points, interfaces densities, and performance capabilities. A single twelve slot XGS12 chassis can generate up to 480Gbps of stateful traffic in a single test system. • Extensive support for layer 4-7 protocols including DHCPv4, DHCPv6-PD, PPPoE, IPSec, VLANs, 802.1q, and 802.1p. • True user emulation with multiple applications per subscriber. • Realistically simulates dynamic network interface setup and teardown behavior linked with subscriber emulation. • Advanced network attachment support to test with any network topology. • Sets up 802.1x and EAPoUDP sessions and carries out authentication and access control. • Transmits high-performance multiplay traffic over authenticated sessions for performance benchmarking, while performing web-based HTTP session authentication and running HTTP performance scalability tests. • HTTP, SSL, FTP, peer-to-peer, RTSP, RTP, SMTP, POP3, IMAP, CIFS, Radius, SSH, Radius, Telnet, DNS, DHCP, LDAP, DDoS, • vulnerability attacks and application replay for true replay of application flows. '• VoIP, SIP, SCCP (Skinny), H.248, SIP, and MGCP. '• IPTV, video on demand, streaming video, RTSP, RTP, IGMP, and MLD APPLICATION TRAFFIC CAPABILITIES APPLICATION FEATURE DETAILS Network Protocols Extensive support for layer 4-7 protocols including DHCPv4, DHCPv6- PD, PPPoE, IPsec, VLANs, 802.1q, and 802.1p. Unique MAC addresses, flexible IP and VLAN mapping, traffic to network associations are available for complex scenarios. Dynamic Subscriber Behavior True user emulation with multiple applications per subscriber. Realistically simulates dynamic network interface setup and tear-down behavior linked with subscriber emulation. Advanced network attachment support to test with any network topology. Layer 2-3 Authentication and Access Control Sets up 802.1x and EAPoUDP sessions and carries out authentication and access control. Transmits high-performance multiplay traffic over authenticated sessions for performance benchmarking, while performing web-based HTTP session authentication and running HTTP performance scalability tests. Data Protocol Emulation HTTP, SSL, FTP, peer-to-peer, RTSP, RTP, SMTP, POP3, IMAP, CIFS, Radius, SSH, Radius, Telnet, DNS, DHCP, LDAP, DDoS, vulnerability attacks and application replay for true replay of application flows. Voice Protocol Testing VoIP, SIP, SCCP (Skinny), H.248, SIP, and MGCP. Video Protocol Testing IPTV, video on demand, streaming video, RTSP, RTP, IGMP, and MLD. APPLICATION PERFORMANCEi NGY-NP load modules provide the industry’s highest performance in real-world application emulation. METRIC NGY-NP8 NGY-NP4 NGY-NP2 L2/3 Throughput 160Gbps 80Gbps 40Gbps L7 Throughput 40Gbps 20Gbps 10Gbps Connections/sec 400,000 252,000 125,000 Concurrent Connections 3,200,000 1,600,000 800,000 FLEXIBLE PACKET GENERATION Each Ixia 10 gigabit Ethernet test port is capable of generating precisely controlled network traffic at wire speed using Ixia’s IxExplorer test application. Millions of packet flows, with fully customizable packet header fields, can be configured on each port. Flexible header control is available for Ethernet, IPv4/v6, IPX, ARP, TCP, UDP, VLANs, QinQ, MPLS, GRE, and many others. Payload contents can also be customized with incrementing, decrementing, fixed, random, or user-defined information. Frame sizes can be fixed, varied according to a pattern, or randomly assigned across a weighted range. Rate control can be flexibly defined in frames per second, bits per second, percentage of line rate, or inter-packet gap time. REAL-TIME LATENCY Packets representing different traffic profiles can be associated with packet group Identifiers (PGIDs). The receiving port measures the minimum, maximum, and average latency in real time for the packets belonging to different groups. Measurable latencies include: · Instantaneous latency and inter-arrival time where each packet is associated with one PGID · Latency bins, where PGIDs can be associated with a latency range · Latency over time, where multiple PGIDs can be placed in "time buckets" with fixed durations · First and last time stamps, where each PGID can store the timestamps of first and last received packets TRANSMIT SCHEDULER There are two modes of transmission are available - packet stream and advanced stream scheduler: · Packet Stream Scheduler. In packet stream scheduler mode, the transmit engine allows configuration of up to 4000 unique sequential stream groupings on each port. Multiple streams can be defined in sequence, each containing multiple packet flows defined by unique characteristics. After transmission of the first stream, control is passed to the next defined stream in the sequence. After reaching the last stream in the sequence, transmission may either cease, or control may be passed on to any other stream in the sequence. Therefore, multiple streams are cycled through, representing different traffic profiles to simulate real network traffic. · Advanced Stream Scheduler. In advanced stream scheduler mode, the transmission of stream groupings is interleaved per port. For example, assume a port is configured with three streams. If stream 1 is defined with IP packets at 20% of line rate, stream 2 is defined with TCP packets at 50% of line rate, and stream 3 is defined with MPLS packets at 30% of line rate, data on the port will be transmitted at an aggregate utilization of 100% with interleaved IP, TCP, and MPLS packets. EXTENSIVE STATISTICS · Real-time 64-bit frame counts and rates · Spreadsheet presentation format for convenient manipulation of statistics counters · Eight QoS counters (supporting 802.1p, DSCP, and IPv4 TOS measurements) · PRBS mode per-PGID statistics: o PRBS Bits Received o PRBS Errored Bits · PRBS BERT user-defined statistics with trigger condition · Extended statistics for ARP, ICMP, and DHCP · Transmit stream statistics for frame counts and rate · External logging to file for statistics and alerts · Audible and visual alerts with user-definable thresholds DATA CAPTURE Each port is equipped with 512 MB of capture memory, capable of storing tens of thousands of packets in real time. The capture buffer can be configured to store packets based on user-defined trigger and filter conditions. Decodes for IPv4, IPv6, UDP, ARP, BGP-4, IS-IS, OSPF, TCP, DHCP, IPX, RIP, IGMP, CISCO ISL, VLAN, and MPLS are provided. DATA INTEGRITY As packets traverse through networks, IP header contents may change resulting in the recalculation of packet CRC values. To validate device performance, the data integrity function of GbE ports allows packet payload contents to be verified with a unique CRC that is independent of the packet CRC. This ensures that the payload is not disturbed as the device changes header fields. In addition to the data integrity check, NGY-NP offers PRBS testing, which detects errors within encapsulated Ethernet frames and provides errored-bit identification and bit error rate (BERT) calculations. SEQUENCE AND DUPLICATE PACKET CHECKING Sequence numbers can be inserted at a user-defined offset in the payload of each transmitted packet. Upon receipt of the packets by the device under test (DUT), out-of-sequence errors or duplicated packets are reported in real time at wire-speed rates. The user can define a sequence error threshold to distinguish between small versus big errors, and the receive port can measure the amount of small, big, reversed, and total errors. Alternatively, the user can use the duplicate packet detection mode to observe that multiple packets with the same sequence number are received and analyzed. TCL API Ixia's GbE ports are supported by a comprehensive Tcl application programming interface (API). This API allows users to develop custom scripts, and integrate the modules into automated test environments. APPLICATION SUPPORT · IxExplorer: Layer 2-3 wire-speed traffic generation and analysis including FCoE. · IxAutomate: Automated test environment for layer 2-3 data and control plane testing, includes RFC- based test suites. · IxNetwork: Integrated layer 2-3 data/control plane performance and functional testing. Data Center Ethernet (FCoE, IxSAN) Routing/bridging emulation includes: BGP4/4+, OSPFv2/v3, IS-ISv4/v6, RIP/RIPng, RSVP-TE, LDP, L2 MPLS VPNs, L3 MPLS VPNs, VPLS, IGMPv1/v2/v3, MLDv1/v2, PIM-SMv4/v6, STP, RSTP, EIGRP, and MSTP. · IxLoad: Layer 4-7 performance testing. · IxSAN: Stateful FCoE emulation of storage devices including emulation of initiators and targets. · Tcl API: Custom user script development for layer 2-7 testing. SPECIFICATIONS LOAD MODULE NGY-NP8, NGY-NP4, AND NGY-NP2 Connector Type SFP+ for 10GbE port Number of Ports 8 / 4 / 2 Maximum Ports per Chassis: - XGS12-HS or XGS12-SD or XM12 - XGS2-HS or XGS2-SD or XM2 96 / 48 / 24ii 16 / 8 / 4 Layer 2-3 Routing Protocol and Emulation Yes Layer 4–7 Application Traffic Testing Yes Capture Buffer per Port 512 MB Number of Transmit Flows per Port (sequential values) Billions Number of Transmit Flows per Port (arbitrary values) 1 Million Number of Trackable Receive Flows per Port 1 Million Number of Stream Definitions per Port 512 in packet stream mode (sequential) or advanced stream (interleaved) modes. Each stream definition can generate millions of unique traffic flows LOAD MODULE NGY-NP8, NGY-NP4, AND NGY-NP2 Transmit Engine Wire-speed packet generation with timestamps, sequence numbers, data integrity signature, and packet group signatures Receive Engine Wire-speed packet filtering, capturing, real-time latency for each packet group, data integrity, and sequence checking User Defined Field (UDF) Features Fixed, increment or decrement by user-defined step, value lists, range lists, cascade, random, and chained Table UDF Feature Comprehensive packet editing function for emulating large numbers of sophisticated flows. Up to 1 million table UDF entries are supported on the NGY-NP. Filters 48-bit source/destination address, 2x128-bit user-definable pattern and offset, frame length range, CRC error, data integrity error, sequence checking error (small, big, reverse) Data Field (per stream) Fixed, increment (byte/word), decrement (byte/word), random, repeating, user-specified up to 13K bytes Statistics and Rates: Counter Size: 64-Bit Link state, line speed, frames sent, valid frames received, bytes sent/received, fragments, undersize, oversize, CRC errors, VLAN tagged frames, 6 user-defined stats, capture trigger (UDS 3), capture filter (UDS 4), user-defined stat 5, user-defined stat 6, 8 QoS counters, data integrity frames, data integrity errors, sequence checking frames, sequence checking errors, ARP, and ping requests and replies Error Generation CRC (Good/Bad/None), Undersize, Oversize Packet Flow Statistics Real-time statistics to track up to 1 million packet flows on the NGY-NP with throughput and latency measurements. Latency Measurements 20ns resolution IPv4, IPv6, UDP, TCP Hardware checksum generation Frame Length Controls Fixed, random, weighted random, or increment by user- defined step, random, weighted random Operating Temperature Range 41°F to 86°F (5°C to 30°C) ATTENTION PLEASE! IXIA CLIENT SOFTWARE: The software provided on all Ixia items is the server software only. The server software has ixserver and ixplorer as the only desktop applications. The server application licensed features are accessed through various Ixia client applications that interact with the chassis server. If you do not already have this set up, you will need to download the Ixia client applications you need from Ixia. These client applications are typically free from Ixia but you will need a logon account. We will not supply you with these. In a single user environment you can set the client side GUI interface on a external PC or you can set them up on an application server when using a chassis in a multi-user environment to access and configure all the sub-license features included in a listing. WHAT YOU SEE IS WHAT YOU GET... What is included in this listing will be shown in the pictures. If you do not see an accessory in the pictures and it is not specifically listed as included in the condition description or the listing description, the accessory is not included. Please read the descriptions completely for exceptions on this. GENERAL REFUND POLICY: You are covered with a full money back guarantee for at least 30 days or longer as specified in the listing, unless an item is indicated as "Sold as is - no returns". We go beyond that by promising that if you are dissatisfied for any reason and if we cannot fix this with you, we will give you 100% of your purchase price back as a cash refund. This will include the original shipping costs if your dissatisfaction is due to an issue with the item you bought being "Not as described". ALL WE ASK IS THAT YOU CONTACT US FIRST AND GIVE US A CHANCE TO WORK THINGS OUT WITH YOU. PLEASE DO NOT LEAVE NEGATIVE FEEDBACK IF YOU HAVE NOT FIRST CONTACTED US TO FIX WHATEVER ISSUE YOU HAVE. WE SHIP WORLD WIDE! PAYMENT SHIPPING RETURNS QUALITY CONTROL CONTACT US PAYMENT SHIPPING RETURNS QUALITY CONTROL CONTACT US We accept payment by any of the following methods: PayPal PREFERRED WE CAN ALSO ACCEPT CASH ON PICK UP, PROCESS CREDIT CARDS THROUGH PAYPAL OR OTHER FORMS OF PAYMENT BUT WE ASK THAT YOU COORDINATE THIS WITH US PRIOR TO MAKING A PURCHASE ALSO PLEASE NOTE THAT WE MAY TAKE UP TO 3 BUSINESS DAYS TO SHIP FROM THE TIME YOU ORDERED, WEEKENDS ARE NOT COUNTED.... SO IF YOU PLACE AN ORDER FRIDAY NIGHT WE MAY NOT GET IT OUT UNTIL THE FOLLOWING WEDNESDAY (WORST CASE SCENARIO) THOUGH WE SHIP AS SOON AS WE CAN. WE ALSO RESERVE THE RIGHT TO CHANGE THE METHOD OF SHIPPING SELECTED AT THE TIME OF PURCHASE TO AN EQUIVALENT OR BETTER DELIVERY SERVICE THAT BEST FITS THE ITEM BEING DELIVERED. IF YOU NEED A FASTER SERVICE, PLEASE TELL US SO WE CAN ADJUST OUR PRIORITIES BUT PLEASE DON'T EXPECT EXPEDITED SERVICE UNLESS YOU ASK US TO DO SO FIRST AS OUR COMMITMENT IS 3 DAYS IF YOU HAVE NOT SPECIFICALLY ASKED FOR FASTER SHIPPING. WE SHIP WORLD WIDE .. SOME ITEMS MAY TAKE UP TO 5 DAYS TO PALLETIZE AND SHIP Please note that the US Mail (USPS) may not be an acceptable choice for international shipping due to package size and weight restrictions and export documentation requirements. If you choses USPS for your international shipment, you may be told you have to select FedEx or USPS or even DHL at a higher price due to the restrictions when using USPS. If you have a question on this, please confirm your shipping choice with us before placing your order. INTERNATIONAL SHIPMENTS MAY BE DELAYED OR CANCELLED DUE TO EAR AND ITAR EXPORT COMPLIANCE REQUIREMENTS. THE VAST MAJORITY OF OUR ITEMS DO NOT NEED EXPORT LICENSES AND CAN BE SHIPPED UNDER EAR99 AND OTHER EXEMPTIONS. ITEMS THAT DO REQUIRE EXPORT LICENSES SHOULD BE INDICATED WITHIN THE LISTING. International Orders are subject to DUTIES, TAXES or other Import Fees; the bidder/buyer[s] is solely responsible for these fees, documents and transportation if held at a customs office in the destination country. In the event that you have questions about international shipping logistics please contact us before purchase. UNLESS INDICATED AS "SOLD AS IS NO RETURNS, If you are not 100% satisfied with your purchase, you can return the product and get a full refund or exchange the product for another one, be it similar or not. You can return a product for 30 days from the date you purchased it OR LONGER, DEPENDING ON THE TERMS IN THE LISTING. Any product you return must be in the same condition you received it and in the original packaging. Please keep the receipt. UNLESS AN ITEM IS INDICATED AS "SOLD AS IS - NO RETURNS" YOU ARE COVERED WITH A FULL MONEY BACK GUARANTEE FOR AT LEAST 30 DAYS OR LONGER AS SPECIFIED IN THE LISTING. ELECTRONICS IN GENERAL WHERE POSSIBLE ITEMS ARE TESTED. THE VALUE OF AN ITEM GREATLY CONTRIBUTES TO THE AMOUNT OR EFFORT PUT INTO TESTING. IT JUST ISN'T POSSIBLE TO TEST MANY LOW VALUE ITEMS DUE TO THE TIME REQUIRED AND THE EXPENSES ASSOCIATED WITH IT. ITEMS THAT ARE NOT SPECIFICALLY TESTED IN DETAIL ARE VISUALLY INSPECTED AND REVIEWED FOR THEIR OPERATIONAL STATUS. REMEMBER ...YOU ARE COVERED WITH A MONEY BACK GUARANTEE REGARDLESS. COMPUTERS IN MOST CASES THE ITEMS WE SELL ARE Removed from used computers. THEY ARE Tested where possible. ON COMPUTER ITEMS WE GO A LITTLE FARTHER WITH OUR 100% MONEY BACK GUARANTEE BY OFFERING YOU OUR ZERO RISK NO QUESTIONS ASKED 60 DAY MONEY BACK WARRANTY ON ALL OUR COMPUTER PARTS .... WE WILL EVEN PAY THE RETURN SHIPPING COSTS FOR YOU IN ADVANCE. (ANY EXCEPTIONS ARE NOTED IN THE SPECIFIC LISTING) APPLIANCE PARTS Used items are cleaned, clear plastics are hand polished to reduce visible scuffs or scratches. Paint chips are sometimes but not always repaired. Lime and rust deposits are removed to the best of our ability. Some minor repairs may be performed. Any exceptional wear will be noted in our description. We do our best to restore any used item but the final condition the restoration is subjective to ones opinion. If you take issue with an Items condition we promise to work with you to resolve this. Note that stock photos are often used and are not the exact item being sold. If you would like to request a different or an actual photo of an Item you are interested in, please submit a request before buying. Confused by the part numbers? Keep in mind that many companies make parts for many different brand names. There is a ton of crossover, here are some examples: GE Brand Part: GE brands include: Hotpoint RCA Sears / Kenmore. Frigidaire Brand Part: Frigidaire brands include: Gibson Kelvinator Westinghouse Electrolux -Electrolux also makes various appliance models for Sears / Kenmore Various others Whirlpool Brands Parts: Whirlpool brands include Whirlpool Maytag LG KitchenAid Jenn-Air Amana Magic Chef Admiral Norge Roper Samsung Various others Sears / Kenmore WE ASK THAT YOU STICK TO USING EBAY AS OUR COMMUNICATION MEDIUM. PLEASE DO NOT SHARE YOUR CONTACT INFO WITH US OR ASK FOR OUR CONTACT INFO UNLESS YOU HAVE PURCHASED AN ITEM AND NEED TO PICK IT UP OR YOU NEED TO DISCUSS AN ITEM THAT YOU HAVE ALREADY PURCHASED. ONCE YOU HAVE PURCHASED AN ITEM WE WILL BE GLAD TO TALK WITH YOU DIRECTLY ON THAT ITEM. ANY CONTACT OUTSIDE OF EBAY CAN RESULT IN THE SUSPENSION OF OUR ACCOUNT IN ANY SITUATION OUTSIDE OF THESE REQUIREMENTS. See our other items NGY-NP8-01 Ixia's NGY-NP family of load modules is the industry’s highest performing density application traffic generation solution. It offers complete layer 2-7 packet generation, and routing and application testing functionality in a single load module. NGY-NP combines the CPU processing and Ixia’s unique NP (network processor) architecture to create a scalable, high-performance application traffic generation platform, emulating up to 40Gbps of data traffic. Each 10GbE port uses multiple network processors, a powerful RISC processor running Linux, and a complete TCP/IP stack – all of which are optimized for layer 4-7 testing. Each test port also supports wire-speed layer 2-3 traffic generation and analysis, and high-performance routing/bridging protocol emulation in conjunction with true layer 4-7 application subscriber emulation and traffic generation. NGY-NP is available in 2-port, 4-port and 8-port configurations offering a wider range of price points, interfaces densities, and performance capabilities. A single twelve slot XGS12 chassis can generate up to 480Gbps of stateful traffic in a single test system. • Extensive support for layer 4-7 protocols including DHCPv4, DHCPv6-PD, PPPoE, IPSec, VLANs, 802.1q, and 802.1p. • True user emulation with multiple applications per subscriber. • Realistically simulates dynamic network interface setup and teardown behavior linked with subscriber emulation. • Advanced network attachment support to test with any network topology. • Sets up 802.1x and EAPoUDP sessions and carries out authentication and access control. • Transmits high-performance multiplay traffic over authenticated sessions for performance benchmarking, while performing web-based HTTP session authentication and running HTTP performance scalability tests. • HTTP, SSL, FTP, peer-to-peer, RTSP, RTP, SMTP, POP3, IMAP, CIFS, Radius, SSH, Radius, Telnet, DNS, DHCP, LDAP, DDoS, • vulnerability attacks and application replay for true replay of application flows. '• VoIP, SIP, SCCP (Skinny), H.248, SIP, and MGCP. '• IPTV, video on demand, streaming video, RTSP, RTP, IGMP, and MLD APPLICATION TRAFFIC CAPABILITIES APPLICATION FEATURE DETAILS Network Protocols Extensive support for layer 4-7 protocols including DHCPv4, DHCPv6- PD, PPPoE, IPsec, VLANs, 802.1q, and 802.1p. Unique MAC addresses, flexible IP and VLAN mapping, traffic to network associations are available for complex scenarios. Dynamic Subscriber Behavior True user emulation with multiple applications per subscriber. Realistically simulates dynamic network interface setup and tear-down behavior linked with subscriber emulation. Advanced network attachment support to test with any network topology. Layer 2-3 Authentication and Access Control Sets up 802.1x and EAPoUDP sessions and carries out authentication and access control. Transmits high-performance multiplay traffic over authenticated sessions for performance benchmarking, while performing web-based HTTP session authentication and running HTTP performance scalability tests. Data Protocol Emulation HTTP, SSL, FTP, peer-to-peer, RTSP, RTP, SMTP, POP3, IMAP, CIFS, Radius, SSH, Radius, Telnet, DNS, DHCP, LDAP, DDoS, vulnerability attacks and application replay for true replay of application flows. Voice Protocol Testing VoIP, SIP, SCCP (Skinny), H.248, SIP, and MGCP. Video Protocol Testing IPTV, video on demand, streaming video, RTSP, RTP, IGMP, and MLD. APPLICATION PERFORMANCEi NGY-NP load modules provide the industry’s highest performance in real-world application emulation. METRIC NGY-NP8 NGY-NP4 NGY-NP2 L2/3 Throughput 160Gbps 80Gbps 40Gbps L7 Throughput 40Gbps 20Gbps 10Gbps Connections/sec 400,000 252,000 125,000 Concurrent Connections 3,200,000 1,600,000 800,000 FLEXIBLE PACKET GENERATION Each Ixia 10 gigabit Ethernet test port is capable of generating precisely controlled network traffic at wire speed using Ixia’s IxExplorer test application. Millions of packet flows, with fully customizable packet header fields, can be configured on each port. Flexible header control is available for Ethernet, IPv4/v6, IPX, ARP, TCP, UDP, VLANs, QinQ, MPLS, GRE, and many others. Payload contents can also be customized with incrementing, decrementing, fixed, random, or user-defined information. Frame sizes can be fixed, varied according to a pattern, or randomly assigned across a weighted range. Rate control can be flexibly defined in frames per second, bits per second, percentage of line rate, or inter-packet gap time. REAL-TIME LATENCY Packets representing different traffic profiles can be associated with packet group Identifiers (PGIDs). The receiving port measures the minimum, maximum, and average latency in real time for the packets belonging to different groups. Measurable latencies include: · Instantaneous latency and inter-arrival time where each packet is associated with one PGID · Latency bins, where PGIDs can be associated with a latency range · Latency over time, where multiple PGIDs can be placed in "time buckets" with fixed durations · First and last time stamps, where each PGID can store the timestamps of first and last received packets TRANSMIT SCHEDULER There are two modes of transmission are available - packet stream and advanced stream scheduler: · Packet Stream Scheduler. In packet stream scheduler mode, the transmit engine allows configuration of up to 4000 unique sequential stream groupings on each port. Multiple streams can be defined in sequence, each containing multiple packet flows defined by unique characteristics. After transmission of the first stream, control is passed to the next defined stream in the sequence. After reaching the last stream in the sequence, transmission may either cease, or control may be passed on to any other stream in the sequence. Therefore, multiple streams are cycled through, representing different traffic profiles to simulate real network traffic. · Advanced Stream Scheduler. In advanced stream scheduler mode, the transmission of stream groupings is interleaved per port. For example, assume a port is configured with three streams. If stream 1 is defined with IP packets at 20% of line rate, stream 2 is defined with TCP packets at 50% of line rate, and stream 3 is defined with MPLS packets at 30% of line rate, data on the port will be transmitted at an aggregate utilization of 100% with interleaved IP, TCP, and MPLS packets. EXTENSIVE STATISTICS · Real-time 64-bit frame counts and rates · Spreadsheet presentation format for convenient manipulation of statistics counters · Eight QoS counters (supporting 802.1p, DSCP, and IPv4 TOS measurements) · PRBS mode per-PGID statistics: o PRBS Bits Received o PRBS Errored Bits · PRBS BERT user-defined statistics with trigger condition · Extended statistics for ARP, ICMP, and DHCP · Transmit stream statistics for frame counts and rate · External logging to file for statistics and alerts · Audible and visual alerts with user-definable thresholds DATA CAPTURE Each port is equipped with 512 MB of capture memory, capable of storing tens of thousands of packets in real time. The capture buffer can be configured to store packets based on user-defined trigger and filter conditions. Decodes for IPv4, IPv6, UDP, ARP, BGP-4, IS-IS, OSPF, TCP, DHCP, IPX, RIP, IGMP, CISCO ISL, VLAN, and MPLS are provided. DATA INTEGRITY As packets traverse through networks, IP header contents may change resulting in the recalculation of packet CRC values. To validate device performance, the data integrity function of GbE ports allows packet payload contents to be verified with a unique CRC that is independent of the packet CRC. This ensures that the payload is not disturbed as the device changes header fields. In addition to the data integrity check, NGY-NP offers PRBS testing, which detects errors within encapsulated Ethernet frames and provides errored-bit identification and bit error rate (BERT) calculations. SEQUENCE AND DUPLICATE PACKET CHECKING Sequence numbers can be inserted at a user-defined offset in the payload of each transmitted packet. Upon receipt of the packets by the device under test (DUT), out-of-sequence errors or duplicated packets are reported in real time at wire-speed rates. The user can define a sequence error threshold to distinguish between small versus big errors, and the receive port can measure the amount of small, big, reversed, and total errors. Alternatively, the user can use the duplicate packet detection mode to observe that multiple packets with the same sequence number are received and analyzed. TCL API Ixia's GbE ports are supported by a comprehensive Tcl application programming interface (API). This API allows users to develop custom scripts, and integrate the modules into automated test environments. APPLICATION SUPPORT · IxExplorer: Layer 2-3 wire-speed traffic generation and analysis including FCoE. · IxAutomate: Automated test environment for layer 2-3 data and control plane testing, includes RFC- based test suites. · IxNetwork: Integrated layer 2-3 data/control plane performance and functional testing. Data Center Ethernet (FCoE, IxSAN) Routing/bridging emulation includes: BGP4/4+, OSPFv2/v3, IS-ISv4/v6, RIP/RIPng, RSVP-TE, LDP, L2 MPLS VPNs, L3 MPLS VPNs, VPLS, IGMPv1/v2/v3, MLDv1/v2, PIM-SMv4/v6, STP, RSTP, EIGRP, and MSTP. · IxLoad: Layer 4-7 performance testing. · IxSAN: Stateful FCoE emulation of storage devices including emulation of initiators and targets. · Tcl API: Custom user script development for layer 2-7 testing. SPECIFICATIONS LOAD MODULE NGY-NP8, NGY-NP4, AND NGY-NP2 Connector Type SFP+ for 10GbE port Number of Ports 8 / 4 / 2 Maximum Ports per Chassis: - XGS12-HS or XGS12-SD or XM12 - XGS2-HS or XGS2-SD or XM2 96 / 48 / 24ii 16 / 8 / 4 Layer 2-3 Routing Protocol and Emulation Yes Layer 4–7 Application Traffic Testing Yes Capture Buffer per Port 512 MB Number of Transmit Flows per Port (sequential values) Billions Number of Transmit Flows per Port (arbitrary values) 1 Million Number of Trackable Receive Flows per Port 1 Million Number of Stream Definitions per Port 512 in packet stream mode (sequential) or advanced stream (interleaved) modes. Each stream definition can generate millions of unique traffic flows LOAD MODULE NGY-NP8, NGY-NP4, AND NGY-NP2 Transmit Engine Wire-speed packet generation with timestamps, sequence numbers, data integrity signature, and packet group signatures Receive Engine Wire-speed packet filtering, capturing, real-time latency for each packet group, data integrity, and sequence checking User Defined Field (UDF) Features Fixed, increment or decrement by user-defined step, value lists, range lists, cascade, random, and chained Table UDF Feature Comprehensive packet editing function for emulating large numbers of sophisticated flows. Up to 1 million table UDF entries are supported on the NGY-NP. Filters 48-bit source/destination address, 2x128-bit user-definable pattern and offset, frame length range, CRC error, data integrity error, sequence checking error (small, big, reverse) Data Field (per stream) Fixed, increment (byte/word), decrement (byte/word), random, repeating, user-specified up to 13K bytes Statistics and Rates: Counter Size: 64-Bit Link state, line speed, frames sent, valid frames received, bytes sent/received, fragments, undersize, oversize, CRC errors, VLAN tagged frames, 6 user-defined stats, capture trigger (UDS 3), capture filter (UDS 4), user-defined stat 5, user-defined stat 6, 8 QoS counters, data integrity frames, data integrity errors, sequence checking frames, sequence checking errors, ARP, and ping requests and replies Error Generation CRC (Good/Bad/None), Undersize, Oversize Packet Flow Statistics Real-time statistics to track up to 1 million packet flows on the NGY-NP with throughput and latency measurements. Latency Measurements 20ns resolution IPv4, IPv6, UDP, TCP Hardware checksum generation Frame Length Controls Fixed, random, weighted random, or increment by user- defined step, random, weighted random Operating Temperature Range 41°F to 86°F (5°C to 30°C) ZOMBIE COMPONENTSTHE LARGEST IXIA RESELLER ON EBAY IXIA OPTIXIA NGY-NP8-01, 10 GIGABIT APPLICATION NETWORK PROCESSOR LOAD MODULE NGY-NP8-01 Ixia's NGY-NP family of load modules is the industry’s highest performing density application traffic generation solution. It offers complete layer 2-7 packet generation, and routing and application testing functionality in a single load module. NGY-NP combines the CPU processing and Ixia’s unique NP (network processor) architecture to create a scalable, high-performance application traffic generation platform, emulating up to 40Gbps of data traffic. Each 10GbE port uses multiple network processors, a powerful RISC processor running Linux, and a complete TCP/IP stack – all of which are optimized for layer 4-7 testing. Each test port also supports wire-speed layer 2-3 traffic generation and analysis, and high-performance routing/bridging protocol emulation in conjunction with true layer 4-7 application subscriber emulation and traffic generation. NGY-NP is available in 2-port, 4-port and 8-port configurations offering a wider range of price points, interfaces densities, and performance capabilities. A single twelve slot XGS12 chassis can generate up to 480Gbps of stateful traffic in a single test system. • Extensive support for layer 4-7 protocols including DHCPv4, DHCPv6-PD, PPPoE, IPSec, VLANs, 802.1q, and 802.1p. • True user emulation with multiple applications per subscriber. • Realistically simulates dynamic network interface setup and teardown behavior linked with subscriber emulation. • Advanced network attachment support to test with any network topology. • Sets up 802.1x and EAPoUDP sessions and carries out authentication and access control. • Transmits high-performance multiplay traffic over authenticated sessions for performance benchmarking, while performing web-based HTTP session authentication and running HTTP performance scalability tests. • HTTP, SSL, FTP, peer-to-peer, RTSP, RTP, SMTP, POP3, IMAP, CIFS, Radius, SSH, Radius, Telnet, DNS, DHCP, LDAP, DDoS, • vulnerability attacks and application replay for true replay of application flows. '• VoIP, SIP, SCCP (Skinny), H.248, SIP, and MGCP. '• IPTV, video on demand, streaming video, RTSP, RTP, IGMP, and MLD APPLICATION TRAFFIC CAPABILITIES APPLICATION FEATURE DETAILS Network Protocols Extensive support for layer 4-7 protocols including DHCPv4, DHCPv6- PD, PPPoE, IPsec, VLANs, 802.1q, and 802.1p. Unique MAC addresses, flexible IP and VLAN mapping, traffic to network associations are available for complex scenarios. Dynamic Subscriber Behavior True user emulation with multiple applications per subscriber. Realistically simulates dynamic network interface setup and tear-down behavior linked with subscriber emulation. Advanced network attachment support to test with any network topology. Layer 2-3 Authentication and Access Control Sets up 802.1x and EAPoUDP sessions and carries out authentication and access control. Transmits high-performance multiplay traffic over authenticated sessions for performance benchmarking, while performing web-based HTTP session authentication and running HTTP performance scalability tests. Data Protocol Emulation HTTP, SSL, FTP, peer-to-peer, RTSP, RTP, SMTP, POP3, IMAP, CIFS, Radius, SSH, Radius, Telnet, DNS, DHCP, LDAP, DDoS, vulnerability attacks and application replay for true replay of application flows. Voice Protocol Testing VoIP, SIP, SCCP (Skinny), H.248, SIP, and MGCP. Video Protocol Testing IPTV, video on demand, streaming video, RTSP, RTP, IGMP, and MLD. APPLICATION PERFORMANCEi NGY-NP load modules provide the industry’s highest performance in real-world application emulation. METRIC NGY-NP8 NGY-NP4 NGY-NP2 L2/3 Throughput 160Gbps 80Gbps 40Gbps L7 Throughput 40Gbps 20Gbps 10Gbps Connections/sec 400,000 252,000 125,000 Concurrent Connections 3,200,000 1,600,000 800,000 FLEXIBLE PACKET GENERATION Each Ixia 10 gigabit Ethernet test port is capable of generating precisely controlled network traffic at wire speed using Ixia’s IxExplorer test application. Millions of packet flows, with fully customizable packet header fields, can be configured on each port. Flexible header control is available for Ethernet, IPv4/v6, IPX, ARP, TCP, UDP, VLANs, QinQ, MPLS, GRE, and many others. Payload contents can also be customized with incrementing, decrementing, fixed, random, or user-defined information. Frame sizes can be fixed, varied according to a pattern, or randomly assigned across a weighted range. Rate control can be flexibly defined in frames per second, bits per second, percentage of line rate, or inter-packet gap time. REAL-TIME LATENCY Packets representing different traffic profiles can be associated with packet group Identifiers (PGIDs). The receiving port measures the minimum, maximum, and average latency in real time for the packets belonging to different groups. Measurable latencies include: · Instantaneous latency and inter-arrival time where each packet is associated with one PGID · Latency bins, where PGIDs can be associated with a latency range · Latency over time, where multiple PGIDs can be placed in "time buckets" with fixed durations · First and last time stamps, where each PGID can store the timestamps of first and last received packets TRANSMIT SCHEDULER There are two modes of transmission are available - packet stream and advanced stream scheduler: · Packet Stream Scheduler. In packet stream scheduler mode, the transmit engine allows configuration of up to 4000 unique sequential stream groupings on each port. Multiple streams can be defined in sequence, each containing multiple packet flows defined by unique characteristics. After transmission of the first stream, control is passed to the next defined stream in the sequence. After reaching the last stream in the sequence, transmission may either cease, or control may be passed on to any other stream in the sequence. Therefore, multiple streams are cycled through, representing different traffic profiles to simulate real network traffic. · Advanced Stream Scheduler. In advanced stream scheduler mode, the transmission of stream groupings is interleaved per port. For example, assume a port is configured with three streams. If stream 1 is defined with IP packets at 20% of line rate, stream 2 is defined with TCP packets at 50% of line rate, and stream 3 is defined with MPLS packets at 30% of line rate, data on the port will be transmitted at an aggregate utilization of 100% with interleaved IP, TCP, and MPLS packets. EXTENSIVE STATISTICS · Real-time 64-bit frame counts and rates · Spreadsheet presentation format for convenient manipulation of statistics counters · Eight QoS counters (supporting 802.1p, DSCP, and IPv4 TOS measurements) · PRBS mode per-PGID statistics: o PRBS Bits Received o PRBS Errored Bits · PRBS BERT user-defined statistics with trigger condition · Extended statistics for ARP, ICMP, and DHCP · Transmit stream statistics for frame counts and rate · External logging to file for statistics and alerts · Audible and visual alerts with user-definable thresholds DATA CAPTURE Each port is equipped with 512 MB of capture memory, capable of storing tens of thousands of packets in real time. The capture buffer can be configured to store packets based on user-defined trigger and filter conditions. Decodes for IPv4, IPv6, UDP, ARP, BGP-4, IS-IS, OSPF, TCP, DHCP, IPX, RIP, IGMP, CISCO ISL, VLAN, and MPLS are provided. DATA INTEGRITY As packets traverse through networks, IP header contents may change resulting in the recalculation of packet CRC values. To validate device performance, the data integrity function of GbE ports allows packet payload contents to be verified with a unique CRC that is independent of the packet CRC. This ensures that the payload is not disturbed as the device changes header fields. In addition to the data integrity check, NGY-NP offers PRBS testing, which detects errors within encapsulated Ethernet frames and provides errored-bit identification and bit error rate (BERT) calculations. SEQUENCE AND DUPLICATE PACKET CHECKING Sequence numbers can be inserted at a user-defined offset in the payload of each transmitted packet. Upon receipt of the packets by the device under test (DUT), out-of-sequence errors or duplicated packets are reported in real time at wire-speed rates. The user can define a sequence error threshold to distinguish between small versus big errors, and the receive port can measure the amount of small, big, reversed, and total errors. Alternatively, the user can use the duplicate packet detection mode to observe that multiple packets with the same sequence number are received and analyzed. TCL API Ixia's GbE ports are supported by a comprehensive Tcl application programming interface (API). This API allows users to develop custom scripts, and integrate the modules into automated test environments. APPLICATION SUPPORT · IxExplorer: Layer 2-3 wire-speed traffic generation and analysis including FCoE. · IxAutomate: Automated test environment for layer 2-3 data and control plane testing, includes RFC- based test suites. · IxNetwork: Integrated layer 2-3 data/control plane performance and functional testing. Data Center Ethernet (FCoE, IxSAN) Routing/bridging emulation includes: BGP4/4+, OSPFv2/v3, IS-ISv4/v6, RIP/RIPng, RSVP-TE, LDP, L2 MPLS VPNs, L3 MPLS VPNs, VPLS, IGMPv1/v2/v3, MLDv1/v2, PIM-SMv4/v6, STP, RSTP, EIGRP, and MSTP. · IxLoad: Layer 4-7 performance testing. · IxSAN: Stateful FCoE emulation of storage devices including emulation of initiators and targets. · Tcl API: Custom user script development for layer 2-7 testing. SPECIFICATIONS LOAD MODULE NGY-NP8, NGY-NP4, AND NGY-NP2 Connector Type SFP+ for 10GbE port Number of Ports 8 / 4 / 2 Maximum Ports per Chassis: - XGS12-HS or XGS12-SD or XM12 - XGS2-HS or XGS2-SD or XM2 96 / 48 / 24ii 16 / 8 / 4 Layer 2-3 Routing Protocol and Emulation Yes Layer 4–7 Application Traffic Testing Yes Capture Buffer per Port 512 MB Number of Transmit Flows per Port (sequential values) Billions Number of Transmit Flows per Port (arbitrary values) 1 Million Number of Trackable Receive Flows per Port 1 Million Number of Stream Definitions per Port 512 in packet stream mode (sequential) or advanced stream (interleaved) modes. Each stream definition can generate millions of unique traffic flows LOAD MODULE NGY-NP8, NGY-NP4, AND NGY-NP2 Transmit Engine Wire-speed packet generation with timestamps, sequence numbers, data integrity signature, and packet group signatures Receive Engine Wire-speed packet filtering, capturing, real-time latency for each packet group, data integrity, and sequence checking User Defined Field (UDF) Features Fixed, increment or decrement by user-defined step, value lists, range lists, cascade, random, and chained Table UDF Feature Comprehensive packet editing function for emulating large numbers of sophisticated flows. Up to 1 million table UDF entries are supported on the NGY-NP. Filters 48-bit source/destination address, 2x128-bit user-definable pattern and offset, frame length range, CRC error, data integrity error, sequence checking error (small, big, reverse) Data Field (per stream) Fixed, increment (byte/word), decrement (byte/word), random, repeating, user-specified up to 13K bytes Statistics and Rates: Counter Size: 64-Bit Link state, line speed, frames sent, valid frames received, bytes sent/received, fragments, undersize, oversize, CRC errors, VLAN tagged frames, 6 user-defined stats, capture trigger (UDS 3), capture filter (UDS 4), user-defined stat 5, user-defined stat 6, 8 QoS counters, data integrity frames, data integrity errors, sequence checking frames, sequence checking errors, ARP, and ping requests and replies Error Generation CRC (Good/Bad/None), Undersize, Oversize Packet Flow Statistics Real-time statistics to track up to 1 million packet flows on the NGY-NP with throughput and latency measurements. Latency Measurements 20ns resolution IPv4, IPv6, UDP, TCP Hardware checksum generation Frame Length Controls Fixed, random, weighted random, or increment by user- defined step, random, weighted random Operating Temperature Range 41°F to 86°F (5°C to 30°C) PAYMENT We accept payment by any of the following methods: PayPal PREFERRED WE CAN ALSO ACCEPT CASH ON PICK UP, PROCESS CREDIT CARDS THROUGH PAYPAL OR OTHER FORMS OF PAYMENT BUT WE ASK THAT YOU COORDINATE THIS WITH US PRIOR TO MAKING A PURCHASE SHIPPINGALSO PLEASE NOTE THAT WE MAY TAKE UP TO 3 BUSINESS DAYS TO SHIP FROM THE TIME YOU ORDERED, WEEKENDS ARE NOT COUNTED.... SO IF YOU PLACE AN ORDER FRIDAY NIGHT WE MAY NOT GET IT OUT UNTIL THE FOLLOWING WEDNESDAY (WORST CASE SCENARIO) THOUGH WE SHIP AS SOON AS WE CAN. WE ALSO RESERVE THE RIGHT TO CHANGE THE METHOD OF SHIPPING SELECTED AT THE TIME OF PURCHASE TO AN EQUIVALENT OR BETTER DELIVERY SERVICE THAT BEST FITS THE ITEM BEING DELIVERED. IF YOU NEED A FASTER SERVICE, PLEASE TELL US SO WE CAN ADJUST OUR PRIORITIES BUT PLEASE DON'T EXPECT EXPEDITED SERVICE UNLESS YOU ASK US TO DO SO FIRST AS OUR COMMITMENT IS 3 DAYS IF YOU HAVE NOT SPECIFICALLY ASKED FOR FASTER SHIPPING. WE SHIP WORLD WIDE .. SOME ITEMS MAY TAKE UP TO 5 DAYS TO PALLETIZE AND SHIP Please note that the US Mail (USPS) may not be an acceptable choice for international shipping due to package size and weight restrictions and export documentation requirements. If you choses USPS for your international shipment, you may be told you have to select FedEx or USPS or even DHL at a higher price due to the restrictions when using USPS. If you have a question on this, please confirm your shipping choice with us before placing your order. INTERNATIONAL SHIPMENTS MAY BE DELAYED OR CANCELLED DUE TO EAR AND ITAR EXPORT COMPLIANCE REQUIREMENTS. THE VAST MAJORITY OF OUR ITEMS DO NOT NEED EXPORT LICENSES AND CAN BE SHIPPED UNDER EAR99 AND OTHER EXEMPTIONS. ITEMS THAT DO REQUIRE EXPORT LICENSES SHOULD BE INDICATED WITHIN THE LISTING. International Orders are subject to DUTIES, TAXES or other Import Fees; the bidder/buyer[s] is solely responsible for these fees, documents and transportation if held at a customs office in the destination country. In the event that you have questions about international shipping logistics please contact us before purchase. RETURNS UNLESS INDICATED AS "SOLD AS IS NO RETURNS, If you are not 100% satisfied with your purchase, you can return the product and get a full refund or exchange the product for another one, be it similar or not. You can return a product for 30 days from the date you purchased it OR LONGER, DEPENDING ON THE TERMS IN THE LISTING. Any product you return must be in the same condition you received it and in the original packaging. Please keep the receipt. QUALITY CONTROLUNLESS AN ITEM IS INDICATED AS "SOLD AS IS - NO RETURNS" YOU ARE COVERED WITH A FULL MONEY BACK GUARANTEE FOR AT LEAST 30 DAYS OR LONGER AS SPECIFIED IN THE LISTING. ELECTRONICS IN GENERAL WHERE POSSIBLE ITEMS ARE TESTED. THE VALUE OF AN ITEM GREATLY CONTRIBUTES TO THE AMOUNT OR EFFORT PUT INTO TESTING. IT JUST ISN'T POSSIBLE TO TEST MANY LOW VALUE ITEMS DUE TO THE TIME REQUIRED AND THE EXPENSES ASSOCIATED WITH IT. ITEMS THAT ARE NOT SPECIFICALLY TESTED IN DETAIL ARE VISUALLY INSPECTED AND REVIEWED FOR THEIR OPERATIONAL STATUS. REMEMBER ...YOU ARE COVERED WITH A MONEY BACK GUARANTEE REGARDLESS. COMPUTERS IN MOST CASES THE ITEMS WE SELL ARE Removed from used computers. THEY ARE Tested where possible. ON COMPUTER ITEMS WE GO A LITTLE FARTHER WITH OUR 100% MONEY BACK GUARANTEE BY OFFERING YOU OUR ZERO RISK NO QUESTIONS ASKED 60 DAY MONEY BACK WARRANTY ON ALL OUR COMPUTER PARTS .... WE WILL EVEN PAY THE RETURN SHIPPING COSTS FOR YOU IN ADVANCE. (ANY EXCEPTIONS ARE NOTED IN THE SPECIFIC LISTING) APPLIANCE PARTS Used items are cleaned, clear plastics are hand polished to reduce visible scuffs or scratches. Paint chips are sometimes but not always repaired. Lime and rust deposits are removed to the best of our ability. Some minor repairs may be performed. Any exceptional wear will be noted in our description. We do our best to restore any used item but the final condition the restoration is subjective to ones opinion. If you take issue with an Items condition we promise to work with you to resolve this. Note that stock photos are often used and are not the exact item being sold. If you would like to request a different or an actual photo of an Item you are interested in, please submit a request before buying. Confused by the part numbers? Keep in mind that many companies make parts for many different brand names. There is a ton of crossover, here are some examples: GE Brand Part: GE brands include: Hotpoint RCA Sears / Kenmore. Frigidaire Brand Part: Frigidaire brands include: Gibson Kelvinator Westinghouse Electrolux -Electrolux also makes various appliance models for Sears / Kenmore Various others Whirlpool Brands Parts: Whirlpool brands include Whirlpool Maytag LG KitchenAid Jenn-Air Amana Magic Chef Admiral Norge Roper Samsung Various others Sears / Kenmore CONTACT USWE ASK THAT YOU STICK TO USING EBAY AS OUR COMMUNICATION MEDIUM. PLEASE DO NOT SHARE YOUR CONTACT INFO WITH US OR ASK FOR OUR CONTACT INFO UNLESS YOU HAVE PURCHASED AN ITEM AND NEED TO PICK IT UP OR YOU NEED TO DISCUSS AN ITEM THAT YOU HAVE ALREADY PURCHASED. ONCE YOU HAVE PURCHASED AN ITEM WE WILL BE GLAD TO TALK WITH YOU DIRECTLY ON THAT ITEM. ANY CONTACT OUTSIDE OF EBAY CAN RESULT IN THE SUSPENSION OF OUR ACCOUNT IN ANY SITUATION OUTSIDE OF THESE REQUIREMENTS. ATTENTION PLEASE! IXIA CLIENT SOFTWARE: The software provided on all Ixia items is the server software only. The server software has ixserver and ixplorer as the only desktop applications. The server application licensed features are accessed through various Ixia client applications that interact with the chassis server. If you do not already have this set up, you will need to download the Ixia client applications you need from Ixia. These client applications are typically free from Ixia but you will need a logon account. We will not supply you with these. In a single user environment you can set the client side GUI interface on a external PC or you can set them up on an application server when using a chassis in a multi-user environment to access and configure all the sub-license features included in a listing. WHAT YOU SEE IS WHAT YOU GET... What is included in this listing will be shown in the pictures. If you do not see an accessory in the pictures and it is not specifically listed as included in the condition description or the listing description, the accessory is not included. Please read the descriptions completely for exceptions on this. GENERAL REFUND POLICY: You are covered with a full money back guarantee for at least 30 days or longer as specified in the listing,&nsp;unless an item is indicated as "Sold as is - no returns". We go beyond that by promising that if you are dissatisfied for any reason and if we cannot fix this with you, we will give you 100% of your purchase price back as a cash refund. This will include the original shipping costs if your dissatisfaction is due to an issue with the item you bought being "Not as described". ALL WE ASK IS THAT YOU CONTACT US FIRST AND GIVE US A CHANCE TO WORK THINGS OUT WITH YOU. PLEASE DO NOT LEAVE NEGATIVE FEEDBACK IF YOU HAVE NOT FIRST CONTACTED US TO FIX WHATEVER ISSUE YOU HAVE. WE SHIP WORLD WIDE! See our other items NGY-NP8-01 Ixia's NGY-NP family of load modules is the industry’s highest performing density application traffic generation solution. It offers complete layer 2-7 packet generation, and routing and application testing functionality in a single load module. NGY-NP combines the CPU processing and Ixia’s unique NP (network processor) architecture to create a scalable, high-performance application traffic generation platform, emulating up to 40Gbps of data traffic. Each 10GbE port uses multiple network processors, a powerful RISC processor running Linux, and a complete TCP/IP stack – all of which are optimized for layer 4-7 testing. Each test port also supports wire-speed layer 2-3 traffic generation and analysis, and high-performance routing/bridging protocol emulation in conjunction with true layer 4-7 application subscriber emulation and traffic generation. NGY-NP is available in 2-port, 4-port and 8-port configurations offering a wider range of price points, interfaces densities, and performance capabilities. A single twelve slot XGS12 chassis can generate up to 480Gbps of stateful traffic in a single test system. • Extensive support for layer 4-7 protocols including DHCPv4, DHCPv6-PD, PPPoE, IPSec, VLANs, 802.1q, and 802.1p. • True user emulation with multiple applications per subscriber. • Realistically simulates dynamic network interface setup and teardown behavior linked with subscriber emulation. • Advanced network attachment support to test with any network topology. • Sets up 802.1x and EAPoUDP sessions and carries out authentication and access control. • Transmits high-performance multiplay traffic over authenticated sessions for performance benchmarking, while performing web-based HTTP session authentication and running HTTP performance scalability tests. • HTTP, SSL, FTP, peer-to-peer, RTSP, RTP, SMTP, POP3, IMAP, CIFS, Radius, SSH, Radius, Telnet, DNS, DHCP, LDAP, DDoS, • vulnerability attacks and application replay for true replay of application flows. '• VoIP, SIP, SCCP (Skinny), H.248, SIP, and MGCP. '• IPTV, video on demand, streaming video, RTSP, RTP, IGMP, and MLD APPLICATION TRAFFIC CAPABILITIES APPLICATION FEATURE DETAILS Network Protocols Extensive support for layer 4-7 protocols including DHCPv4, DHCPv6- PD, PPPoE, IPsec, VLANs, 802.1q, and 802.1p. Unique MAC addresses, flexible IP and VLAN mapping, traffic to network associations are available for complex scenarios. Dynamic Subscriber Behavior True user emulation with multiple applications per subscriber. Realistically simulates dynamic network interface setup and tear-down behavior linked with subscriber emulation. Advanced network attachment support to test with any network topology. Layer 2-3 Authentication and Access Control Sets up 802.1x and EAPoUDP sessions and carries out authentication and access control. Transmits high-performance multiplay traffic over authenticated sessions for performance benchmarking, while performing web-based HTTP session authentication and running HTTP performance scalability tests. Data Protocol Emulation HTTP, SSL, FTP, peer-to-peer, RTSP, RTP, SMTP, POP3, IMAP, CIFS, Radius, SSH, Radius, Telnet, DNS, DHCP, LDAP, DDoS, vulnerability attacks and application replay for true replay of application flows. Voice Protocol Testing VoIP, SIP, SCCP (Skinny), H.248, SIP, and MGCP. Video Protocol Testing IPTV, video on demand, streaming video, RTSP, RTP, IGMP, and MLD. APPLICATION PERFORMANCEi NGY-NP load modules provide the industry’s highest performance in real-world application emulation. METRIC NGY-NP8 NGY-NP4 NGY-NP2 L2/3 Throughput 160Gbps 80Gbps 40Gbps L7 Throughput 40Gbps 20Gbps 10Gbps Connections/sec 400,000 252,000 125,000 Concurrent Connections 3,200,000 1,600,000 800,000 FLEXIBLE PACKET GENERATION Each Ixia 10 gigabit Ethernet test port is capable of generating precisely controlled network traffic at wire speed using Ixia’s IxExplorer test application. Millions of packet flows, with fully customizable packet header fields, can be configured on each port. Flexible header control is available for Ethernet, IPv4/v6, IPX, ARP, TCP, UDP, VLANs, QinQ, MPLS, GRE, and many others. Payload contents can also be customized with incrementing, decrementing, fixed, random, or user-defined information. Frame sizes can be fixed, varied according to a pattern, or randomly assigned across a weighted range. Rate control can be flexibly defined in frames per second, bits per second, percentage of line rate, or inter-packet gap time. REAL-TIME LATENCY Packets representing different traffic profiles can be associated with packet group Identifiers (PGIDs). The receiving port measures the minimum, maximum, and average latency in real time for the packets belonging to different groups. Measurable latencies include: · Instantaneous latency and inter-arrival time where each packet is associated with one PGID · Latency bins, where PGIDs can be associated with a latency range · Latency over time, where multiple PGIDs can be placed in "time buckets" with fixed durations · First and last time stamps, where each PGID can store the timestamps of first and last received packets TRANSMIT SCHEDULER There are two modes of transmission are available - packet stream and advanced stream scheduler: · Packet Stream Scheduler. In packet stream scheduler mode, the transmit engine allows configuration of up to 4000 unique sequential stream groupings on each port. Multiple streams can be defined in sequence, each containing multiple packet flows defined by unique characteristics. After transmission of the first stream, control is passed to the next defined stream in the sequence. After reaching the last stream in the sequence, transmission may either cease, or control may be passed on to any other stream in the sequence. Therefore, multiple streams are cycled through, representing different traffic profiles to simulate real network traffic. · Advanced Stream Scheduler. In advanced stream scheduler mode, the transmission of stream groupings is interleaved per port. For example, assume a port is configured with three streams. If stream 1 is defined with IP packets at 20% of line rate, stream 2 is defined with TCP packets at 50% of line rate, and stream 3 is defined with MPLS packets at 30% of line rate, data on the port will be transmitted at an aggregate utilization of 100% with interleaved IP, TCP, and MPLS packets. EXTENSIVE STATISTICS · Real-time 64-bit frame counts and rates · Spreadsheet presentation format for convenient manipulation of statistics counters · Eight QoS counters (supporting 802.1p, DSCP, and IPv4 TOS measurements) · PRBS mode per-PGID statistics: o PRBS Bits Received o PRBS Errored Bits · PRBS BERT user-defined statistics with trigger condition · Extended statistics for ARP, ICMP, and DHCP · Transmit stream statistics for frame counts and rate · External logging to file for statistics and alerts · Audible and visual alerts with user-definable thresholds DATA CAPTURE Each port is equipped with 512 MB of capture memory, capable of storing tens of thousands of packets in real time. The capture buffer can be configured to store packets based on user-defined trigger and filter conditions. Decodes for IPv4, IPv6, UDP, ARP, BGP-4, IS-IS, OSPF, TCP, DHCP, IPX, RIP, IGMP, CISCO ISL, VLAN, and MPLS are provided. DATA INTEGRITY As packets traverse through networks, IP header contents may change resulting in the recalculation of packet CRC values. To validate device performance, the data integrity function of GbE ports allows packet payload contents to be verified with a unique CRC that is independent of the packet CRC. This ensures that the payload is not disturbed as the device changes header fields. In addition to the data integrity check, NGY-NP offers PRBS testing, which detects errors within encapsulated Ethernet frames and provides errored-bit identification and bit error rate (BERT) calculations. SEQUENCE AND DUPLICATE PACKET CHECKING Sequence numbers can be inserted at a user-defined offset in the payload of each transmitted packet. Upon receipt of the packets by the device under test (DUT), out-of-sequence errors or duplicated packets are reported in real time at wire-speed rates. The user can define a sequence error threshold to distinguish between small versus big errors, and the receive port can measure the amount of small, big, reversed, and total errors. Alternatively, the user can use the duplicate packet detection mode to observe that multiple packets with the same sequence number are received and analyzed. TCL API Ixia's GbE ports are supported by a comprehensive Tcl application programming interface (API). This API allows users to develop custom scripts, and integrate the modules into automated test environments. APPLICATION SUPPORT · IxExplorer: Layer 2-3 wire-speed traffic generation and analysis including FCoE. · IxAutomate: Automated test environment for layer 2-3 data and control plane testing, includes RFC- based test suites. · IxNetwork: Integrated layer 2-3 data/control plane performance and functional testing. Data Center Ethernet (FCoE, IxSAN) Routing/bridging emulation includes: BGP4/4+, OSPFv2/v3, IS-ISv4/v6, RIP/RIPng, RSVP-TE, LDP, L2 MPLS VPNs, L3 MPLS VPNs, VPLS, IGMPv1/v2/v3, MLDv1/v2, PIM-SMv4/v6, STP, RSTP, EIGRP, and MSTP. · IxLoad: Layer 4-7 performance testing. · IxSAN: Stateful FCoE emulation of storage devices including emulation of initiators and targets. · Tcl API: Custom user script development for layer 2-7 testing. SPECIFICATIONS LOAD MODULE NGY-NP8, NGY-NP4, AND NGY-NP2 Connector Type SFP+ for 10GbE port Number of Ports 8 / 4 / 2 Maximum Ports per Chassis: - XGS12-HS or XGS12-SD or XM12 - XGS2-HS or XGS2-SD or XM2 96 / 48 / 24ii 16 / 8 / 4 Layer 2-3 Routing Protocol and Emulation Yes Layer 4–7 Application Traffic Testing Yes Capture Buffer per Port 512 MB Number of Transmit Flows per Port (sequential values) Billions Number of Transmit Flows per Port (arbitrary values) 1 Million Number of Trackable Receive Flows per Port 1 Million Number of Stream Definitions per Port 512 in packet stream mode (sequential) or advanced stream (interleaved) modes. Each stream definition can generate millions of unique traffic flows LOAD MODULE NGY-NP8, NGY-NP4, AND NGY-NP2 Transmit Engine Wire-speed packet generation with timestamps, sequence numbers, data integrity signature, and packet group signatures Receive Engine Wire-speed packet filtering, capturing, real-time latency for each packet group, data integrity, and sequence checking User Defined Field (UDF) Features Fixed, increment or decrement by user-defined step, value lists, range lists, cascade, random, and chained Table UDF Feature Comprehensive packet editing function for emulating large numbers of sophisticated flows. Up to 1 million table UDF entries are supported on the NGY-NP. Filters 48-bit source/destination address, 2x128-bit user-definable pattern and offset, frame length range, CRC error, data integrity error, sequence checking error (small, big, reverse) Data Field (per stream) Fixed, increment (byte/word), decrement (byte/word), random, repeating, user-specified up to 13K bytes Statistics and Rates: Counter Size: 64-Bit Link state, line speed, frames sent, valid frames received, bytes sent/received, fragments, undersize, oversize, CRC errors, VLAN tagged frames, 6 user-defined stats, capture trigger (UDS 3), capture filter (UDS 4), user-defined stat 5, user-defined stat 6, 8 QoS counters, data integrity frames, data integrity errors, sequence checking frames, sequence checking errors, ARP, and ping requests and replies Error Generation CRC (Good/Bad/None), Undersize, Oversize Packet Flow Statistics Real-time statistics to track up to 1 million packet flows on the NGY-NP with throughput and latency measurements. Latency Measurements 20ns resolution IPv4, IPv6, UDP, TCP Hardware checksum generation Frame Length Controls Fixed, random, weighted random, or increment by user- defined step, random, weighted random Operating Temperature Range 41°F to 86°F (5°C to 30°C)

“LIKE NEW *** 60 DAY RETURNS *** COMES WITH TEST REPORT”

Model

NGY-NP8-01

Unit Type

Modules

Country/Region of Manufacture

United States

Network Analyzer Type

PROTOCOL

MPN

NGY-NP8-01

Brand

Ixia
