Jabsco Pump, Rotary Lobe Pedestal, 13.7 Gpm Model: Lh320-1890

US $3,200.00

Homer Glen, Illinois, United States
Jan 30th

Open on mobile:
QR code

Product Description Pump, Rotary Lobe Pedestal, Pump Body Material 316 Stainless Steel, Carbon On Stainless Steel Seal, Elastomer Material Food Grade Nitrile, Port Size 3/4 In, Port Type Tri-Clamp, Shaft Dia. 0.6 In, Shaft Material Stainless Steel, RPM 1500, Max. Flow 13.7(GPM), Max. Pressure 217 PSI, Max. Viscosity 1 Mil (cP), Max. Temp. 284 Degrees F, Max. Dia. Solids 0.24 In, Length 8.4 In, Width 7.6 In, Height 6.5 In RestrictionsNote: Not to be run in a dry condition. Self-Priming Flexible-Impeller PumpsNo metal-to-metal contact. Excellent for fluid transfer, spraying, lawn/garden applications, filter systems, water drainage, and machine/equipment coolant recycling.Replaceable impellersJabscoReplaceable Viton impellers handle more-corrosive liquids. Rotary Lobe Pedestal models are suitable for pharmaceutical manufacturing and processing, and in beverage, dairy, and food applications.Max. temp.: 176 F 316 stainless steel and stainless steel, 180 F epoxy 1750 rpm 316 stainless steel, 3000 rpm epoxy and stainless steel. ITEM Pump TYPE Rotary Lobe Pedestal PUMP BODY MATERIAL 316 Stainless Steel SEAL Carbon On Stainless Steel ELASTOMER MATERIAL Food Grade Nitrile BEARING HOUSING MATERIAL Alloy, Polyester-Epoxy Coated PORT SIZE 3/4" PORT TYPE Tri-Clamp SHAFT DIA. 0.6" SHAFT MATERIAL Stainless Steel RPM 1500 MAX. FLOW 13.7(GPM) DISPLACEMENT .92 MAX. PRESSURE 217 PSI MAX. VISCOSITY 1 Mil (cP) MAX. TEMP. 284 Degrees F MAX. DIA. SOLIDS 0.24" LENGTH 8.4" WIDTH 7.6" HEIGHT 6.5" COMPLIANCE FDA - 3A Approved Materials, CIP, SIP, EHEDG Protocals #6utp12045az
