Jacobs 0080208fc Bt 40 Milling Chuck 20mm Dia Coolant Through 100mm Proj

US $527.94

Wichita, Kansas, United States
Jan 30th

Open on mobile:
QR code

Jacobs Chuck 0080208FC BT 40 Milling Chuck 20mm Diameter with Flange Coolant Through and 100mm Projection Technical Details RPM: up to 10,000 High torque: unique bearing system provides superior grip Rigidity: High alloy steel properly hardened and heat treated provides greater durability and longer life High Precision/Accuracy: concentricity TIR <= .0002-Inch at 4-Inch from the nose Laboratory certified for accuracy and gripping torque Product Description From the Manufacturer The Jacobs BT 40 milling chuck with flange coolant through has a clamping range of up to 20-mm Diameter with 100-mm of projection. It is prebalanced at 10,000 RPM. Made of high alloy steel that is properly hardened and heat treated the Jacobs BT 40 milling chuck has both greater durability and a longer life. The Jacobs BT 40 milling chuck is extremely precise and accurate with a concentricity of TIR <= .0002-Inch at 4-Inch from the nose. The unique bearing system of the Jacobs BT 40 milling chuck provides a superior grip. The Jacobs BT 40 milling chuck is used for Heavy-duty milling and is suitable for CNC machines and machining centers with automatic tool changers. Through spindle coolant is standard for Jacobs milling chucks which have all been laboratory certified for both accuracy and gripping torque. All milling chucks include a one year factory warranty AllJacobs Chuck Tool Holders are new and factory sealed. Each tool ships in the reusable protective tool holder capsule for storing when not in use. Accessories and Tightening Wrench not included, unless otherwise stated. Can Be Purchased Locally
