Jdsu T-berd Mts 4000 4126 Ma Long Haul Sm Fiber Otdr & P5000 Probe T Berd 4126ma

US $3,995.00

Toledo, Ohio, United States
Aug 4th

Open on mobile:
QR code

The Following Items Are Included: JDSU T-BERD 4000 Multiple Services Test Platform w/ Option: (BC# 9103A) T: Touchscreen Power Meter: 850nm 1300nm 1310nm 1490nm 1550nm 1625nm 1650nm VFL JDSU 4126 MA Long Haul SingleMode OTDR Module (BC# 42665) SM OTDR Source: 1310nm 1550nm JDSU P5000 Probe (BC# 22717M) SC Tip For Probe U12M Tip For Probe LC Tip For Probe ST Tip For Probe Ethernet Cable 4000 Platform Getting Started Guide (2) SM SC-SC Fiber Optic Cables Westover Fiber Check 2 CD-ROM (4) Fiber Wipes AC Adapter/Charger Power Cord User Manual On CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! JDSU T-BERD 4000 / MTS-4000 Multiple Services Test Platform w/ JDSU 4126 MA Long Haul SingleMode 1310 / 1550nm OTDR Module & JDSU P5000 Fiber Scope Probe Dynamic Range: 1310 / 1550 nm : 40 / 38 dB Power Meter: - 850nm - 1300nm - 1310nm - 1490nm - 1550nm - 1625nm - 1650nm Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 1 YEAR WARRANTY The Industry’s First Handheld Tester that Combines Advanced Fiber, Copper, xDSL, and Triple-Play Features Cost-effective, modular, and handheldplatform Large, 7-inch display (touchscreenoption) Flexible connectivity (WiFi/Bluetooth/1 G Ethernet/USB) andscripting capability for automaticdata reporting Up to two embedded modules forsimultaneous testing from thephysical layer to the service layer Fiber features include: OTDR, PONmeter, video inspection scope, lasersource/power meter, and VFL Copper measurements include:volt/ohm meter, TDR, resistive faultlocator, and wideband tones/spectralanalysis up to 30 MHz VDSL and ADSL testing featuresutilize Infineon Technologies chipsetand licensed option for Dr. DSL®diagnostic solutions from Aware,Inc. Triple-play service testing includesIPTV and VoIP measurements fromDSL access interfaces or standardEthernet port Automated scripting capability thatsimplifies testing and reporting Integrated web browser Remarkable growth in triple-play services has created a complex mix of topologyscenarios for delivering voice, video, and data to the customer. Triple-play servicesrequire highly scalable and resilient infrastructures to deliver a high quality ofexperience (QoE). The increasing complexity and performance requirements oftoday’s access networks puts greater than ever demands on field servicetechnicians. The JDSU T-BERD®/MTS-4000 offers the first multi-test platform that addressesthe complete requirements of field service technicians entrusted with theinstallation and maintenance of leading-edge fiber- and copper-based digitalsubscriber line (DSL) access networks and triple-play services. The T-BERD/MTS-4000 gives service providers the power of a single instrumentthat provides complete triple-play access network and services testing, thusdramatically improving productivity. This one tool lets technicians completeservice calls faster with fewer call-backs (repeats), because it quickly identifies thecauses of nearly every possible problem. The modular design of the tester enablesmaximum flexibility and upgradeability and seamless support for futurerequirements and new testing capabilities, which provides continuous return oninvestment (RoI). The lightweight T-BERD/MTS-4000 features a wide 7-inch color display with atouchscreen option that lets technicians easily view an actual Internet Protocoltelevision (IPTV) stream, web browser, or complex test results, such as an opticaltime domain reflectometry (OTDR) trace or spectrum analysis waveformanalysis. Its unprecedented connectivity capabilities give the T-BERD/MTS-4000 platformmore uses than other test equipment with features and functionalities, such asremote assistance, remote control, testing automation, and wireless connection,making it an ideal companion in the field. Install and Qualify the Fiber/Copper Architecture The T-BERD/MTS-4000 provides thefull range of capabilities needed to testtoday’s various leading-edge fiber (FTTx)and copper access networks plus theexpandability needed to test the nextgeneration. The variety of testing technologiesoffered by the T-BERD/MTS-4000provide all of the testing functions thattechnicians need at every stage of thenetwork life cycle in a single, compact, andrugged unit: Inspect and qualify optical connectorswith a fiber inspection probe. Qualify the output power levels ofthe optical line termination (OLT)/central office (CO) switch with a powermeter (for a standard or passive opticalnetwork [PON]). Ensure end-to-end fiber connectivitywith a loss test set and/or visual faultlocator (VFL). Qualify and troubleshoot fiber networkswith an OTDR. Qualify and troubleshoot copperlines with a full suite of tests,including voltage current, resistance,opens, balance, load coil detection,plain old telephone service (POTS),tones, noise, spectral, time domainreflectometry (TDR), and RFL. Qualify xDSL for network support ofADSL through very high bit-rateDSL (VDSL2). Turn Up the Services Physical layer testing in the accessnetwork does not reveal all of the qualityof service (QoS) issues that impactpacket-based triple-play applications.Turning up triple-play services andassuring QoS is a multifaceted processthat requires comprehensive and exactingattentionto detail.TheT-BERD/MTS-4000provides a full collection of physical andtriple-play service testing features to ensureproper installation, provisioning, andmaintenance of reliable networks thatconsistently provide high-quality tripleplayservices. Validate the output power levels ofthe optical network terminal (ONT)with a standard or PONpowermeter. Validate Ethernet cable with TDR;fault, polarity, and skew results forGigabit Ethernet (GigE). Validate Ethernet with ping, traceroute, and file transfer protocol/hypertext transfer protocol (FTP/HTTP) tests. Simulate customer and test servicestests at the ONT using a browser toconfigure and then test triple-playservices suite. Validate voice over Internet Protocol(VoIP) with test results, includingboth R-factor and Mean OpinionScore (MOS) as well as content,transport, transaction, and physicallink quality. Validate IPTV with test features thatcan simulate IPTV by displayingthe status of 6 simultaneous streamsin terminate mode or 10 in monitormode and can decode and displayI-frames, packet loss analysis, QoStimeline, and jitter graphs. Troubleshoot the Network Troubleshooting the access network isthe most challenging field service taskfacing today’s telecommunications operators.Faults can come from almostanywhere including problems withtriple-play services, the copper or fiberalong the network, copper or fiber in thecustomer’s premises, home wiring, theset top box or ONT, or customer’s setup,such as a misconfigured personalcomputer (PC). In addition, the networkextends over a wide geographic area andcan be difficult to access, being close toor inside the customer premises. Field service technicians who typicallyfocus on a single application—usuallycopper, fiber, or triple-play services—now must expand their skill set to addresstoday’s expansive range of possibleproblems.The T-BERD/MTS-4000 equipstechnicians with the ideal tool, becauseit provides all of the functionalityneeded to validate and troubleshootTriple-Play networks and services,such as: Testing the ONT using a browserand Triple-Play test suite tovalidate services Performing golden modem operationto troubleshoot common DSL problems Offering complete copper testing toisolate and resolve copper spanproblems Troubleshooting optical connectorswith a fiber inspection probe Determining equipment opticalinput/output power levels of the ONT using the standard or PONpower meter Conducting fiber fault locationand troubleshooting with an inservice OTDR and VFL Manage the Process Fiber optic and copper FTTx access networks and triple-play services present a greatertesting challenge to service technicians than ever before. The T-BERD/MTS-4000platform provides all of the testing capabilities needed to meet this challenge plusinnovative connectivity and automation capabilities thatmake it possible to lower costsand reduce the possibility of errors.The T-BERD/MTS-4000 can also interface directlywith automated workforce management solutions that are capable of managing thetesting process, yielding substantial improvements in operational efficiency. Technicians can utilize the T-BERD/MTS-4000 browser letting them connect to theInternet to verify data services, contact online assistance, and download referencetraces and settings from a database. A 10/100/GigE and WiFi connection providesInternet connectivity. WiFi and Bluetooth wireless connectivity makes it easy totransfer data, such as results files, fromthe T-BERD/MTS-4000 platformto a laptopor personal data assistant (PDA) without the need for a cable or client application.Technicians can also use the test platform for e-mail or FTP communications suchas sending measurement results. A PDF/HTML viewer is provided to view documentsand manuals. Internet connectivity can also be used to take full control of the T-BERD/MTS-4000froma remote location,making it possible to leverage the expertise of a single seniortechnician who can provide remote assistance without traveling to the customersite. Automatic software updates allow for keeping pace with test technologychanges and new test scripts. The T-BERD/MTS-4000 lets technicians create scripts to automate testingprocedures making their jobs simpler and thus improving productivity,completeness, and accuracy. It also promotes easy implementation and enforcementof defined best practices that can ensure best-in-class service to customers andreduce churn. Built-in intelligence manages the instrument through the test setup, execution,results storage, and results upload processes. It simplifies complex processes, whichare often reduced to the single push of a button. The new tester provides a widerange of connectivity options,making it easy to integrate scripts with the back officeto easily document, audit, and compare results against benchmarks. Using the T-BERD/MTS-4000 automation features guarantee adherence to providersetthresholds for service performance. JDSU customers have achieved substantialsavings in time and money through automation of service turn-up and repair. One Tool for Fiber,Copper, xDSL, and Services The T-BERD/MTS-4000 provides an integrated approach toward field testingwith test support for specific application uses. Field-swappable modules areavailable for multi-service testing, and as many as two modules can runsimultaneously. Bringing Fiber, Copper, and Triple-Play Services TestingCloser Together In leading-edge fiber- and copper-based DSL access networks fiber and coppercoexist. Technicians may have to test both fiber and copper throughout thenetwork. The JDSU T-BERD/MTS-4000 offers test performance unlike whattechnicians have experienced previously: fiber-only testing, copper/xDSL-onlytesting with triple-play services, and fiber/copper/xDSL testing with triple-playservices. Complete Fiber Optics Test Solution During FTTx network installation and maintenance, field technicians mustaccurately and completely characterize the fiber link. In addition to built-infunctionality, the T-BERD/MTS-4000 meets advanced fiber test needs. The T-BERD/MTS-4000 has built-in, basic fiber optic test options for quick andeasy verification of fiber links: Power level measurement: The broadband power meter lets technicians easilyverify the presence of a signal. This meter covers 850 to 1550 nm over a range of+10 to ?60 dBm. Visual fault location: The VFL enables easy and visual break localization andnetwork connectivity check. Optical connector inspection via USB interface: The optional Inspect BeforeYou Connect fiber inspection probe enables quick and easy control of connectorend faces. The T-BERD/MTS-4000 also has these dedicated fiber optic modules available: Last Mile OTDR Module with built-in loss test set option: Suits the installation,turn-up, and maintenance testing of Access/FTTx networks and featuresindustry-leading OTDR performance. It offers up to three simultaneous testwavelengths (between 1310, 1550, 1625, and 1650 nm) and can perform out-ofserviceas well as in-service PON testing.Using the same port as the OTDR, a losttest set is also available to easily perform quick fiber identification, power level,and insertion loss measurements. PON Selective Power Meter Module: Analyzes FTTx/PON-based systems andoffers Through Mode testing that allows simultaneous measurement of PONdownstream wavelengths (1490 and 1550 nm) and the upstream wavelength(1310 nm). Themodule also offers a BurstMode function that supports analysisat 1310 nm. Pre-define pass/fail thresholds on the instrument to simplifymeasurements and ensure easy-to-interpret results, while the module GUIensures that users will not miss the temporary collapsing signal. The JDSU FiberTrace and FiberCable PC analysis software transfers data and generatescomprehensive reports.The proof-of-performance report can be easily customized, forinstance to include pass/fail indicators for quick analysis of problemareas. Complete Copper/Triple-Play Services Test Solution Copper technologies and services in access networks evolve quickly because ofconsumer demand for high-speed Internet access, video on demand, and otherapplications. As a result, network operators must equip crews with one scalable,easy-to-use test tool that performs fast, accuratemeasurements under any condition. The T-BERD/MTS-4000 has built-in and optional features for comprehensivecopper testing and Internet Protocol (IP) service-level testing: Complete Copper Testing: Perform copper testing, including digital volt-ohmmeter (DVOM), time division reflectometry, wideband transmissionimpairment measurement set (TIMS), spectral noise, and resistive fault locator(RFL). Wideband test capabilities allow for copper troubleshooting and linequalifications testing up to 30 MHz for VDSL services. xDSL Testing: Verify the circuit and service with modem emulation andreplacement for asymmetric digital subscriber line (ADSL), ADSL2, ADSL2+,and VDSL2. Aware’s Technician Dr. DSL lets field technicians troubleshootcommon DSL problems through source identification and calculating the datarate impact of each disturber. Triple-Play Testing: Conduct advanced tests for the installation andmaintenance of DSL and PON-based Triple Play. Turn-up and troubleshootIPTV services that carry video program content over access networks, includingsupport for all video QoS measurements. VoIP Testing: Turn up and troubleshoot VoIP service connectivity; featureavailability and voice quality; and conduct IP ping, packet statistic, and traceroute analysis to identify, diagnose, and sectionalize VoIP network andequipment problems. The Ideal Platform for Testing Next-GenerationAccess Networks and Services Complete All-in-One FTTx Network Test Solution The T-BERD/MTS-4000 targets field technicians whomust performmultilayer testsstarting from the physical layer, with both copper and optical fiber qualification, toWifi, Ethernet, xDSL as well as IP triple-play tests (IP video, VoIP, and IP Data). In one unit, the T-BERD/MTS-4000 includes all the features of the complete FiberOptics Test Solution and the complete Copper/Triple-Play Services test solution. Both the Fiber Optics or Copper/Triple-Play Services test solutions can be upgradedlater to the all-in-one platform. Ensuring a positive customer experience requires testing the access network and the services before the customer uses them. The T-BERD/MTS-4000 provides a single platform that deliver complete testing of copper- and fiber-based access networksand services with the highest levels of performance, convenience, and upgradeabilityon the market. JDSU 4126 MA SingleMode OTDR Module Specifications: Weight 0.35 kg (0.77 lb) Dimensions (w x h x d) 128 x 134 x 40 mm (5 x 5.28 x 1.58 in) Optical Interfaces Interchangeable optical connectors FC, SC, DIN, LC (PC or APC) and ST (PC) Technical Characteristics Laser safety class (21CFR) Class 1 Distance units Kilometers, feet, and miles Group index range 1.30000 to 1.70000 in 0.00001 steps Number of data points Up to 128,000 or 256,000 data points Distance measurement Mode Automatic or dual cursor Display range 0.5 up to 260 km Cursor resolution 1 cm Sampling resolution 4 cm Accuracy ±1 m ±sampling resolution ±1.105 x distance (excluding group index uncertainties) Attenuation Measurement Mode Automatic, manual, 2-point, 5-point, and LSA Display range 1.25 to 55 dB Display resolution 0.001 dB Cursor reolution 0.001 dB Linearity ±0.03 dB/dB/±0.05 for LA Threshold 0.01 to 5.99 dB in 0.01 dB steps Reflectance/ORL Measurements Reflectance accuracy ±2 dB Display resolution 0.01 dB Threshold 11 to 99 dB in 1 dB steps OTDR Modules Central Wavelength 1310 ±20 nm 1550 ±20 nm RMS Dynamic Range 40 dB 38 dB Event Dead Zone 0.9 m Attenuation Dead Zone 4 m Network Type FTTH/access/ metro Applications Short/medium-haul qualification FTTH test up to 1x32 splitter JDSU Westover P5000 Fiber Optic Microscope FiberChek2 is an advanced application that determines the acceptability of optical fiber end faces through automated inspection and analysis. It identifies and characterizes defects and contamination and determines their location relative to the fiber core. It then provides a PASS or FAIL result according to a pre-configured failure criteria setting. The P5000 digital probe microscope connects directly to a PC or laptop via a USB 2.0 connection, and the unique QuickCaptureTM button lets users capture, inspects, and analyzes a fiber end face image in a single automated step. As different types of contamination are located and identified, FiberChek2 measures the size of each feature, determines its location relative to the core, and analyzes the collected data using an advanced logarithm to obtain a PASS or FAIL result based on parameters configured for each pre-defined setting. Because defects and contamination on or near the core surface typically affect the light transmission most significantly, they require the most aggressive examination. FiberChek2 defines the concentric areas around the core as Zones which let users establish failure criteria by evaluating various defect categories, which include Contamination, Pit/Chip and Scratches. Features: FiberChek2 software pre-programmed to comply with International Electrotechnical Commission (IEC) acceptance criteria standards for single-mode and multimode connectors Implements standards for inspection and grading throughout every stage of fiber handling Remove human subjectivity from fiber inspection and grading to ensure consistent results Configurability allows for user-defined controls and criteria settings Identify and characterize each defect and contamination particle, and determines their location relative to the fiber core Archive results and images as HTML or PDF files and generate integrated reports Plug it directly into PC/laptop via USB 2.0 connection Produce crisp, clear view of fiber end face condition with high resolution 5MP camera and coaxial illumination Specifications: Dimensions 140 x 46 x 44 mm (5.5 x 1.8 x 1.7 in) Weight 110 g (3.88 oz) LOW-Mag field-of-view (FOV) Horizontal: 740 µm Vertical: 550 µm Diagonal: 920 µm HIGH-Mag FOV Horizontal: 460 µm Vertical: 345 µm Diagonal: 575 µm Live image 800 x 600; 15 fps Connector USB 2.0 (with latch lock) Cord length 183 cm (6 ft) Camera sensor 1280 x 1024 black and white, 1/3-in (1.27 cm) CMOS Particle size detection <1 µm Light source Blue LED, 100,000+ hour life Lighting technique Coaxial Power source USB port Certification CE For full JDSU T-Berd 4000 product specifications, please click here: JDSU T-Berd 4000 Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Sell Smarter with Kyozou. Inventory and Ecommerce Management

Condition:	Seller refurbished: The item has been restored to working order by the eBay seller or a third party. This means the item was inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See seller’s listing for full details. ...	Brand	JDSU
Model	MTS 4000
MPN	T-BERD 4000
