Jet 321144 Gh1440w-3 Lathe With Newall Dp700 Dro With Taper Attachment

US $3200

Ferndale, Washington, United States
May 29th

Open on mobile:
QR code

Product Name: JET 321144 GH1440W-3 Lathe With Newall DP700 DRO With Taper Attachment Includes: (1) JET Gh1440W-3 W/Dp700 Dro & Taper Attachment Description: Features Uniquely designed exclusively by JET Hardened and ground gears are featured in the headstock and gearbox D1-4 spindle is precision ground for accuracy and supported by high quality tapered roller bearings Headstock is constantly oiled during operation Splined, not keyed, shafts are utilized Gearbox gives larger threading and feed capabilities with no gear changes V-way bed design is induction hardened and ground Gap bed section provided for larger diameter work Independent leadscrew and feed rod Spindle actuation control is apron mounted Inch-metric dials are standard Compound and cross slide have backlash elimination Adjustable gibs are incorporated in the carriage and slideways Tailstock may be offset for turning tapers and includes an inch-metric graduated quill Tolerance test certificate included Specifications Weight (Lbs.): 2191 Motor (HP): 3 HP, 230/460V, 3Ph Prewired (V.): 230 Drive: Geared Head Overall Dimensions (L x W x H) (In.): 78 x 38 x 59 Style (Type): Engine - Geared Head Carriage Travel (In.): 37-1/2 Size: 14 x 40 Follow Rest Capacity (In.): 38020 Range of Spindle Speeds (RPM): 40 - 1,800 Spindle Mount: D1-4 Max Tool Size (In.): 5/8 x 5/8 Length of Gap (In.): 39694 Swing Through Gap (In.): 20 Distance Between Centers (In.): 40 Width of Bed (In.): 37530 Spindle Taper with Sleeve: MT-5 (MT-3) Compound Slide Travel (In.): 37316 Steady Rest Capacity (In.): 38049 Other Specifications Include: Spindle Bore (In.): 37257 | Range of Cross Feeds (IPR): .0003 - .0103 | Cross Slide Travel (In.): 39602 | Digital Readout: Newall DP700 | Range of Longitudinal Feeds (IPR): .0012 - .0294 | Accessory 1: Taper Attachment | Rang United States: FREE LTL Shipping* In the contiguous 48 states (6-18 Day normal delivery time) Currently shipping for this item is available to the contiguous 48 US states only. Shipping is not available to Alaska or Hawaii. Due to the size and weight of many Freight items, some Freight items are shipped directly from the manufacturer. If this is the case, it is possible for the manufacturer to be backordered on a product. We will notify you of any backorder situations and give a timeframe at which time you can decide if you would like to wait or receive a full refund for your purchase. We try to minimize backorder situations as much as possible but it does occasionally occur. *Free shipping applies to business address with a fork lift, loading dock, or customer pick-up at the local shipping terminal ONLY. Residential businesses do not qualify as a business address. Contact us before purchasing if you prefer local pickup. If shipping to a residence, your shipping location must be accessible by a tractor-trailer truck. Truck drivers will not assist in unloading. Please be prepared for this type of delivery, as you are responsible for unloading. There may be additional charges for delivery to residential addresses up to $50, we will contact you before shipping if there are any additional charges such as limited access, wait fees, or lift gate service. If you suspect that there may be extra fees involved in getting this to you, please call or email us using the information found in the "Contact Us" section for a quote. Hardware Sales is not responsible for service transit time. This information is provided by the carrier and excludes weekends and holidays. Note that transit times may vary, particularly during peak periods. Credit Card We guarantee all of our items to work and be free from manufacturer's defects. Defective items may be returned within 7 days of receipt for a replacement or full refund free of charge. After 7 days, buyer is responsible for return shipping costs. At which time a replacement will be sent at our cost or a refund of the purchase price will be given. Non-defective items may be returned in original condition within 30 days of receipt for a refund of the purchase price of the item(s) less shipping. Buyer is responsible for return shipping costs. If you have any questions please feel free to email us using eBay's "ask a seller a question" form or call us at 1-866-556-1676. Hours of operation Monday-Friday 7:30am-4:00pm PST. 321144I MGT0504 drpshp-lrgtm
