Jet 321383 Gh-1640zx Lathe With Acu-rite 300s Dro And Collet Closer

US $6800

Ferndale, Washington, United States
May 28th

Open on mobile:
QR code

Product Name: JET 321383 GH-1640ZX Lathe With ACU-RITE 300S DRO and Collet Closer Includes: (1) JET Gh-1640Zx Lathe W/300S Dro & Collet Clsr Description: Features Uniquely designed exclusively by JET ISO 9001 certified manufacturer 3-1/8 bore spindle is supported by two tapered and one ball bearing" Chrome molybdenum headstock gears are hardened, ground and shaved Universal gearbox allows inch, metric, diametral and module pitch threads, no change gears required Carriage features one-shot lubrication and Turcite-B on bed sliding surfaces T-slotted compound slide featuring a four-way tool post One piece cast iron base absorbs vibration allowing heavier cuts High quality ANSI Class 50 wear resistant cast iron bed ways are hardened and ground Removable gap allows up to 23-5/8 diameter work on14", 25-7/8" on 16" , 27-1/2" on 18" and 29-1/2" on 22"" Five position automatic carriage stop increases productivity Attractive chrome control levers, dials and knobs complete this impressive package Tolerance test certificate included 10 scroll 3-jaw chuck with top reversing jaws" 12 independent 4-jaw chuck" Specifications Weight (Lbs.): 5475 Motor (HP): 7-1/2 HP, 230/460, 3 Ph Prewired (V.): 230 Drive: Geared Head Overall Dimensions (L x W x H) (In.): 96 x 44 x 66 Style (Type): Engine - Large Spindle Bore Carriage Travel (In.): 35 Size: 16 x 40 Follow Rest Capacity (In.): 1/2 - 3-1/2 Range of Spindle Speeds (RPM): 25 - 1,800 Spindle Mount: D1-8 Max Tool Size (In.): 1 x 1 Length of Gap (In.): 38322 Swing Through Gap (In.): 25-7/8 Distance Between Centers (In.): 40 Width of Bed (In.): 13-3/8 Spindle Taper with Sleeve: MT-7 (MT-5) Compound Slide Travel (In.): 39569 Steady Rest Capacity (In.): 39149 Other Specifications Include: Spindle Bore (In.): 39508 | Range of Cross Feeds (IPR): .0006 - .0365 | Accessory 2: Collet Closer | Cross Slide Travel (In.): 9 | Digital Readout: ACU-RITE 300S | Range of Longitudinal Feeds (IPR): .0015 - .0913 | Range of M United States: FREE LTL Shipping* In the contiguous 48 states (6-18 Day normal delivery time) Currently shipping for this item is available to the contiguous 48 US states only. Shipping is not available to Alaska or Hawaii. Due to the size and weight of many Freight items, some Freight items are shipped directly from the manufacturer. If this is the case, it is possible for the manufacturer to be backordered on a product. We will notify you of any backorder situations and give a timeframe at which time you can decide if you would like to wait or receive a full refund for your purchase. We try to minimize backorder situations as much as possible but it does occasionally occur. *Free shipping applies to business address with a fork lift, loading dock, or customer pick-up at the local shipping terminal ONLY. Residential businesses do not qualify as a business address. Contact us before purchasing if you prefer local pickup. If shipping to a residence, your shipping location must be accessible by a tractor-trailer truck. Truck drivers will not assist in unloading. Please be prepared for this type of delivery, as you are responsible for unloading. There may be additional charges for delivery to residential addresses up to $50, we will contact you before shipping if there are any additional charges such as limited access, wait fees, or lift gate service. If you suspect that there may be extra fees involved in getting this to you, please call or email us using the information found in the "Contact Us" section for a quote. Hardware Sales is not responsible for service transit time. This information is provided by the carrier and excludes weekends and holidays. Note that transit times may vary, particularly during peak periods. Credit Card We guarantee all of our items to work and be free from manufacturer's defects. Defective items may be returned within 7 days of receipt for a replacement or full refund free of charge. After 7 days, buyer is responsible for return shipping costs. At which time a replacement will be sent at our cost or a refund of the purchase price will be given. Non-defective items may be returned in original condition within 30 days of receipt for a refund of the purchase price of the item(s) less shipping. Buyer is responsible for return shipping costs. If you have any questions please feel free to email us using eBay's "ask a seller a question" form or call us at 1-866-556-1676. Hours of operation Monday-Friday 7:30am-4:00pm PST. 321383I MGT0504 drpshp-lrgtm
