Jet Tools Metal Lathe Bdb-1340a, Belt Drive Bench Lathe

US $6,000.00

Colorado Springs, Colorado, United States
Jun 9th

Open on mobile:
QR code

JET Belt Drive Bench Lathes feature an enclosed gearbox with helical cut gears for noise reduction and smooth operation. The full length splash guard on all sizes prevents hot chips and fluid from contaminating the work area and the quick change gearbox allows for fast and easy gear changes for metric threading. Each JET Lathe comes loaded with features you’ve come to expect, all backed by the industry leading JET TWO Year Warranty.Size13 x 40Accessory 1Taper AttachmentAccessory 2Collet CloserSwing Over Bed (In.)13Swing Over Cross Slide (In.)7-25/32 Swing Through Gap (In.)18-3/4Length of Gap (In.)8Distance Between Centers (In.)40Spindle Bore (In.)1-3/8Spindle MountD1-4Spindle Taper with SleeveMT-5 (MT-3)Number of Spindle Speeds12Range of Spindle Speeds (RPM)60 - 1,240Number of Longitudinal and Cross Feed Rates38Range of Longitudinal Feeds (IPR)0.0018-0.0374Range of Cross Feeds (IPR)0.0006-0.013Number of Inch Threads38Range of Inch Threads (TPI)3-1/2 - 80Number of Metric Threads23Range of Metric Threads0.45-10Max Tool Size (In.)5/8 x 5/8Compound Slide Travel (In.)2-11/16Cross Slide Travel (In.)6-5/16Carriage Travel (In.)35Tailstock Spindle Travel (In.)3-3/4Taper in Tailstock SpindleMT-3Follow Rest Capacity (In.)2-3/4Steady Rest Capacity (In.)2-5/8Width of Bed (In.)7-3/8Motor (HP)2 HP, 230V, 1PhPrewired (V.)230Weight (Lbs.)1,175Overall Dimensions (L x W x H) (In.)71 x 32 x 45DriveBeltStyle (Type)Bench

“Mint condition- only used 50 hours. Still Has One Year of Factory Warentee.”
