Johnson Controls Va-7152-1001 Floating Actuator With 3/4" Ball Valve

US $290

Nampa, Idaho, United States
May 27th

Open on mobile:
QR code

Proportional Electric Valve Actuator, 0 to 10 VDC he VA-715x Series synchronous motor-driven actuator provides incremental (three wire), incremental with feedback, or proportional control of valves with up to 3/4 in. stroke in heating, ventilating, and air conditioning applications. This compact, non-spring return actuator has a 90 lb force minimum and responds to a variety of input signals. Features 90 lb Force Output in a Compact Unit:Covers a wide range of applications with one actuator Magnetic Clutch: Provides constant output force for positive closeoff of valves, and protects motor in stall conditions Durable Construction: Provides a longer cycle life Unique Yoke Design: Easy field mounting to valves reduces installation and stroke adjustment time Selectable Direct/Reverse Action: Eases setup and installation Specifications Power Requirements: 24 VAC (20 to 30 VAC), 50/60 Hz 2.7 VA nominal Input Signal: Incremental: 24 VAC, 50/60 Hz; Proportional: 0 to 10 VDC Input Signal Adjustments (Proportional): Input Signal: 0 to 10, 0 to 5, 5 to 10 VDC (jumper selectable); Action: Drive up (DA) or drive down (RA) on signal increase (jumper selectable) ;Factory Setting: Calibrated 1 to 9 +/- 0.5 VDC for 0 to 10 VDC controller operation, Direct Acting (DA), 5/16 in. (8 mm) stroke for VT series valve Input Impedance (Proportional) : 100k ohms Mechanical Output: 90 lb force (400N) minimum Stroke Range: 25/32 in. (20 mm) maximum Nominal Stroke Timing: 60 Hz: 70 seconds 5/16 in. (8 mm) stroke,110 seconds 1/2 in. (13 mm) stroke,165 seconds 3/4 in. (19 mm) stroke, 50 Hz: 85 seconds 5/16 in. (8 mm) stroke, 135 seconds 1/2 in. (13 mm) stroke, 200 seconds 3/4 in. (19 mm) stroke Electrical Connections:Screw Terminals for 16 AWG Maximum Mechanical Connections: 1/4-28 UNF-2B thread for valve stem connection Enclosure: NEMA 2, IP42 Ambient Operating Conditions: 0 to 140F (-18 to 60C), 10 to 90% RH, non-condensing, 86F (30C) maximum dew point Dimensions: 3.84" diameter x 6.06" high (98 x 154 mm) Valve is in great working order or your money back. What you see in the pick is what you get Free shipping to cont USA
