JONES & SHIPMAN SURFACE GRINDING MACHINE 540H, US $9200 – Picture 0
JONES & SHIPMAN SURFACE GRINDING MACHINE 540H, US $9200 – Picture 0

Jones & Shipman Surface Grinding Machine 540h

US $9200

  • Riverside, California, United States
  • Nov 1st
Open on mobile:
QR code
JONES & SHIPMAN SURFACE GRINDING MACHINE 540H Basic Information: Model:                         540H Manufacturer:             Jones & Shipman, England Serial Number:            B015432 Year Built:                   1987 Location:                     City of Riverside, California, USA Condition:                   Used, Excellent Specifications: TABLE Working surface:                                                         6” x18” Longitudinal traverse (max):                                       18.9” Table traverse per rev of handwheel:                          4.9” Width of tenon slot:                                                    0.55” WHEELHEAD Vertical movement (max):                                           16.7” Capacity between wheel & table (new wheel):          16” Size of grinding wheel: Standard                                                          8” x 3/4” x 1.1/4” Optional (Dia.x width)/max width                  7” x 1/2” x 1” Speed of grinding wheel:             Standard wheel                                                2640 rpm             Optional wheel                                               3000 rpm Wheelhead motor:                                                       2 hp CROSSFEED Total cross traverse:                                                   6.7” Movement per rev of handwheel:                               0.19” Fine feed graduations:                                                 0.00005” Handwheel graduations:                                              0.002” WHEELFEED Handwheel graduations standard/option:                   0.0001 in/0.0005 in Movement per rev of handwheel:                               0.008” Powered wheelhead elevation motor (option):           1/4 hp BASE AND COLUMN Machine weight (approx.):                                         1874 lbs Shipping dimensions (approx.):                                  99 cubic feet Equipped with: GS1  AC Drive, USA ‘Heidenhain’ Digital Readout in Y-axis 0.0001”, Germany Z-axis Power-Feed Grinding wheel- and flange adapters (16 assorted items) Diamond wheels (11 assorted items) - Brand New, never used Stand with additional assorted grinding wheels Contact Information Please call, text, or e-mail me with any questions: C:        (951)-333-2146 E:         ngnsinc@gmail.com
