Jovy Systems Jetronix-Eco Infrared BGA Rework Station, US $969.00 – Picture 0
Jovy Systems Jetronix-Eco Infrared BGA Rework Station, US $969.00 – Picture 0

Jovy Systems Jetronix-eco Infrared Bga Rework Station

US $969.00

  • HK, Hong Kong
  • Jan 31st
Open on mobile:
QR code
Jovy Systems Jetronix-Eco is a powerful semi-automatic infrared BGA rework system with PC synchronization. Features High power: max. 3200 W. Three heating zones: reflow zone, inner preheating zone and outer preheating zone. Upper heater can move up/down, in/out and rotate 180°. Large preheating area: up to 245 x 245 mm. Three stages for full process control. Powerful pick-up tool. Wide screen LCD. Safety alarm function to protect PCB or application damage. User friendly software interface via USB 2.0. Technical Specifications Power supply 220 V AC, 50/60 Hz Total heating power 3200 W Upper heater size 80 mm x 80 mm Upper heater power 400 W Bottom heater size 245 mm x 245 mm Bottom heater power 2800 W Max board size up to 300 mm x 400 mm Thermocouple type K-type, built-in flexible Display type 128x64 graphical LCD Suction pump 60-90 dpi (lifting power up to 150 g) Light source 1 Watt LED Memory up to 50 profiles Interface USB 2.0 Software Jetronix-Eco Software Dimensions, L x W x H 450 x 520 x 455 mm Weight 28 Kg Package Contents Jovy Systems Jetronix-Eco Infrared BGA Rework Station Unit – 1 pc. Heaters – 3 pcs. USB Cable – 1 pc. Operation Manual – 1 pc. CD with Software and Operational files – 1 pc.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Jovy Systems
Type with PC synchronization, complex
Model Jetronix-Eco JX-001
Upper Heater Size 8x8 cm
Country/Region of Manufacture China
Bottom Heater Size 24.5 x 24.5 cm
Voltage 220
Heater Type with ceramic emitter
Warranty 12
PCB Holder Presence yes
