Jw3306b High Performance Handheld Optical Fiber Identifier

US $3700

FengHua, China
Jun 9th

Open on mobile:
QR code

Description: JW3306B Optical Fiber Identifier can quickly identify the direction of transmitted fiber and display the relative core power without any damages to the bended fiber. When the traffic is present, the intermittently audible tone is activated The JW3306B optical fiber identifier also recognize the modulation like,270Hz,1kHz and 2kHz .When they are used to detect the frequency, the continuously audible tone is activated There are four adapter heads available: 0.25, 0.9, 2.0 and 3.0. The WF3306A optical fiber identifier is powered by a 9V alkaline battery. Features: · Easy-to-use with “ONE KEY”l operation. · Efficiently identifies the traffic direction and frequency tonel (270Hz, 1KHz, 2KHz) with audible warning. · Displays the relative core power. · More accurate test with Sunshade. · Easy-to-replace adaptors. · Durable metal housing and quality construction. · Lower power indication. Specification: Type JW3306B Identified Wavelength Range 800-1700 nm Identified Signal Type CW, 270Hz,1kHz,2kHz Detector Type 1mm InGaAs 2pcs Adapter Type 0.25 (Applicable for Bare Fiber) 0.9 (Applicable for 0.9 Cable ) 2.0 (Applicable for 2.0 Cable ) 3.0 (Applicable for 3.0 Cable ) Signal Direction Left and Right LED Singe Direction Test Range(dBm, CW0.9mm bare fiber) -46-10(1310nm) -50-10(1550nm) Signal Power Test Range(dBm, CW0.9mm bare fiber) -50-+10 Signal Frequency Display (Hz) 270, 1k, 2k Frequency Test Range(dBm, Average Value) 0.9, 2.0, 3.0 -30-0 (270Hz,1KHz) -25-0 (2KHz) 0.25 -25-0 (1KHz,2KHz) -20~0 (2KHz) Insertion Loss(dB, Typical Value) 0.8 (1310nm) 2.5 (1550nm) Alkaline Battery(V) 9 Operating Temperature -10-+60 Storage Temperature -25-+70 Dimension (mm) 196x30.5x27 Weight (g) 200 Standard Packages: MODEL INCLUDES JW3306B JW3306B Optical Fiber Identifier, 4pcs adapter heads, Sunshade, Alkaline battery(not included), User Manual, Cotton Stick and Soft Carrying case Return policy If you have any questions for the items you received, Please contact us at once. We will resolve it for you ASAP, if you are not happy with the item you purchased, return is acceptable within 14 days after you received the items. We will make refund as soon as we get back the item. Or replace item for you, Please draw attention that shipping and handling fees for returned items should be paid by you. Feedback The feedback is very important to us, so please leave us the positive feedback, if you are not satisfied for any reason, and please contact us before leaving neutral or negative feedback. We will resolve the problem until you are satisfied. Thank you very much for your help. Certainly, we will leave a positive feedback for our kind buyers. About Customs In order to ensure you receive your order without or lower import duty, we will declare it as a "Gift" with a lower value which does not reflect the total price you paid or the market value of the product and may not apply to countries with different tariff rules. Any import charges or fees are the buyer's responsibility. About shipping By Standard Service China Post Air Mail (7-15 days) to USA, (15-25 days ) to Canada, Western Europe, Australia. Other countries will be take 25-35 business days (Shipping fee includes the local handing and packaging fee. Please contact us firstly if you are in other area ).If buyer want to use more faster shipping method, like EMS, DHL etc, please communicate with us. If the package weight is more than 2kg or the package size is larger than 90CM, we will use EMS, DHL etc or ship with two parcels or more parcels by air mail.
