Jx9010f Ftth Fiber Fusion Splicer For Drop Cable And Patch Cord (brand New)

US $5,150.00

San Jose, California, United States
Jan 29th

Open on mobile:
QR code

JX9010F FTTH Fiber Fusion Splicer for Drop Cable and Patch Cord Model #: JX9010F Description: FTTH Fiber Fusion Splicer for Drop Cable and Patch Cord Application: FTTH, Fiber Fusing Summary: JX9010F fiber fusion splicer is proprietarily designed for FTTH environment. This fiber fusion splicer is light weighted with small form factor. It has a built in LED lamp which enables its operation in darkness. The fiber fusion splicer features a fine imaging system which makes the image display exquisite and clear. The embedded real-time operating system provides a friendly interface and great functionality. The built-in super capacity and high performance lithium battery offers reliable and long time field work. The real-time compensation function to the fluctuation of temperature, humidity and air pressure has greatly improved its ability to operate under tough environment, and to obtain stable fusion performance. Features: Designed for FTTH, also works for common optical fiber fusion application Accurate fiber core alignment Low fusion loss Small form factor and light weighted 8 seconds fusion, 30 seconds heat shrink X/ Y axis shown simultaneously, magnification up to 304 times Automatic fusion once cover is closed Automatic heat shrink Real-time discharge correction Long electrode life, as high as 4000 arc count USB and VGA interface port 5.7 inch high-definition digital display on LCD panel Built-in lithium battery with super capacity, up to 220 fusion and heating operation Real-time display of battery remaining capacity Specifications: Parameter Unit Specifications Applicable Fiber nm SMF(ITU-T G. 652), MMF(ITU-T G. 651), DSF(ITU-T G. 653), NZDSF Average Splicing Loss dB 0.02dB(SM), 0.01dB(MM), 0.04dB(DS), 0.04dB(NZDS) Return Loss dB >60 Operation Mode Auto, half auto, manual Align Mode Advanced PAS align mode Fiber Diameter µm Optical fiber cable, SC/ST connector, coating diameter 250 and 900 µm of common fiber Cleave Length mm 8 - 16 Magnification time Vertical 152, horizontal 304 Display inch 5.7 (640 x 480 pixel LCD) Pull Text N 2 (optional) Pyrocondensation Tube Length mm 60, 40 and a series of micro heat-shrinkable tubing Battery Capacity Splicing 220 times (typical), charging for 3.5 hour Battery Life Time cycle 300 – 500 times, replaceable Electrode Lifetime Times >4000, replaceable Lighting for Operation Built-in super high-brightness LED supply convenient for night work Interface Ports USB, VGA Power Supply Built in 11.1V Lithium Ion Battery. AC adopter(Input AC100 - 240, output DC13.5V/4.5A) Operating Environment Temperature range: -10 to 50°C; Humidity: 95%RH (40°C, no condensing); Altitude: 0 – 5000 m Dimension mm 160 (L) x 150 (W) x 140 (H) Weight kg 2.3 (without battery ), 2.8 (with battery) Typical Applications: · JX9010F FTTH Optical Fiber Fusion Splicer is compact. It is easy to use for optical fiber splicing even if the length of optical fiber is only a few centimeters. · JX9010F Optical Fiber Fusion Splicer is mainly applied for FTTH. It is also a great tool in fiber cable production, fiber line maintenance, emergency repair of fiber cable and tests and production of optical fiber components. Standard packing list Item Description Quantity 1 JX9010F Fiber Splicer 1 2 Flat Drop Cable Holder FH-71A-IN 2 3 Single Fiber Holder FH-71A-250 2 4 Patch Cord holder FH-71A-3.0-R 1 5 AC power adapter 1 6 AC current cable 1 7 Standby electrode 1 8 Blower brush 1 9 Bottle with siphon 1 10 Cooling tray 1 11 User’s manual and disc 1 12 Luxury carrying case 1 13 Cleaver 1 14 Flat drop cable stripper 1 15 CFS-2 fiber stripper 1 16 Heater oven accessory 1 Optional equipment Item Description Quantity 1 SC connector holder FH-71A-SC-R 1 Special fiber holders: The JX9010F FTTH Optical fiber fusion splicer is an upgrade version of JX9010 and it's specially designed for FTTH project. It includes all the functions of JX9010 and can splicing for single fiber, flat drop cable, patch cord, SC connector etc.. The three special fixtures are: · FH-71A-IN, flat drop cable holder; · FH-71A-3.0-R, patch cord holder; · FH-71A-SC-R , SC connector · FH-71A-250 Single fiber holder
