JY6013 Auto Range Digital Capacitor Capacitance Tester Meter Cap 0.01pF to 47mF Click to Enlarge Click to Enlarge Click to Enlarge International Buyers – Please Note: a) Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. b) Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying. Get JY6013 for Four Reasons: 1. JINGYAN M6013 V2 Auto-ranging capacitance meter. 2. M6013 have fast reading speed and high accuracy up to 1%. 3. Using 128X64 dot matrix LCD, can display 5 digit reading, Large range of measuring 0.01pF to 470mF (470000uF) capacitance, which enough for DIY user to professional engineer usage. 4. Reading a 2200uF only take ~0.2s *PLEASE DISCHARGE THE CAPACITOR BEFORE TESTING Compare M6013 old V1 and new V2 Improvement: 1) Larger measuring range, V2 can read up to 470mF 2) New large dot matrix LCD 3) New housing with stand 4) More stable on reading, (with auto running averaging function, can read pF more stable and accuracy) 5) Can use 2X AA battery rather than 9V 6) Can use mirco usb as external power. JY6013 Specification: Range Accuracy (After Zero, tested with 1nF, 1uF, 1000uF) Refresh Time (Manual Mode) *Auto mode take 0 to 2s more time depend on value Larger capacitance take more measuring time 0.01pF to 47.000nF 1%+2Digit ~0.2s to 1s 47.00nF to 47.000uF 1%+1Digit ~0.2s to 2s 47.00uF to 470.00mF 1 to 3%+1Digit (Larger capacitance will have larger error) ~0.2s to 30s Accuracy maybe affected by the test lead’s length and distance of test leads. Especially testing pF small capacitance, shortest test lead is recommended, and be careful the surrounding EMI or RF noise may affect the pF reading. 1) Accuracy: Up to 1% (detail on above table) 2) High Resolution: 5 digit 3) Measuring voltage: <0.8V 4) Clamping voltage: ~1.25V (open voltage) 5) Battery 2X AA 1.5V battery 6) External Power: 5V micro USB 7) Operating current 0.02A 8) Battery Life time: >80 Hours Operating Introduction: 1) POWER ON Press and hold the ON/ OFF circle orange button for 1 to 2 second to power on. Press and release the ON/ OFF button to shut down meter. 2) AUTO/ MANUAL mode: i) Auto Range: Press and release the RANGE button and at the first line of LCD will show “AUTO:" At auto mode meter will automatically select the best range to detect. ii) Manual Range: Scroll the manual range from 47nF, 47uF and 470mF range by press and release the RANGE button In LCD will show MANUAL at first LCD line and show at second line: 0-47NF, 47NF TO 47UF and 47UF TO 470MF. 3) 1 Key Zero: OPEN circuit the test leads’ terminal. Press and release the “ZERO" button, LCD shows “ZERO" and wait the zero disappear. If you are using the meter array socket, you need to OPEN circuit to set zero too. 4) Socket: You can use the 8 pin socket to measure the capacitor 5) Running Average: It will automatically start running average if the capacitance reading become stable and user can get more accuracy reading. During running average it will show “AVG” at right bottom LCD or it will show raw data icon “RAW” As a result, if you want to get higher accuracy reading, you can take the reading during AVG display. This function will automatically on, once the raw data is noise. 6) Backlight: LCD backlight will on during power on 7) Auto Sleep: Around 8 to 10 hours for not testing, it will shut down automatically to save power. 8) OVERFLOW or OL: Display overflow when the value is out of range, you can check that you are zero correctly. 9) PLASTIC STAND: If you don’t use the stand, press and push the lock position: Package including: 1unit x M6013 1pair x test probe We do our best for your concerns and make sure you are fully satisfied! Warranty 1. We strive for supplying our customers qualified customer service and technical service, engaging in bring our customers more and more friendly-use shopping experience. 2. We provide free update if newest software come out. We can give you the link to download. 3. The item will be shipped out within 1 working days after payment was received. If you are not satisfied with the item you received, pls return it within 14 days for a replacement or money back. Shipping details If your delivery address is USA, we will ship out the item to you by E Packet,The estimated delivery time is about 7-10 working days. If you have not received your item after 30 days, please contact us first!!! We will track the item’s record from post at the first time and give you a satisfied solution! Feedback 1. Any problem, pls contact us first instead of giving us negative or neutral feedback! We will DO OUR BEST to solve problem for you at the first time. 2. Your positive feedback with good full five stars to the 4 DSRs will be much appreciated. Wish you have a pleasure eBay trading experience with us and welcome to visit my store okbidshop2011 to find more items! The item will be shipped out within 1 working days after payment was received. Item will be sent out by airmail (Such as: China Post,Hongkong Post,Singapore Post Etc.). Normally the estimated delivery time is 15-25 working days. If you don't receive the item after the 30 days, please contact us first!!! we will do our best to solve the delivery problem for you. 1. We prefer to accept paypal as our payment method. It is quick and safe. 2. Please make payment within 3 days after biding, or all non-pay bidders will result in a non-paymemt buyer alert from Ebay and unpaid transaction would be closed. 3. We will send item to your Confirmed Shipping Address in Paypal. If you want to post to other address, please inform us ASAP when making payment through Paypal. We will NOT be responsible for any delivery failure due to unclear, unconfirmed or incomplete addresses given. DO NOT DUPLICATE OR COPY! Template Made By: © Inkfrog Template Center inkfrog terapeak i000000 inkFrog Analytics
