K2 Cnc Machine Frame Pc Router, Drivers, Psu, Stepper Motors & B.o.b.

US $2,200.00

Cheyenne, Wyoming, United States
Mar 2nd

Open on mobile:
QR code

K2 CNC Machine Frame PC Router, Drivers, PSU, Stepper Motors & B.O.B. I purchased this super nice machine frame, motors, drivers, breakout board, power supply, router, and software packages for a great simple stable PC in a killer enclosure – just under 4 years ago for work here at Fretsong Guitars. The system has never been put into service – ALL the hardware is brand spankin’ new. The machine frame has picked up a little dust being stored in the shop – but this is a NEW system. Not the tiny plaque making stuff you see all the time – This machine frame has a 14” X 25” X 7” (!!!) axis travel, this can be used for guitars, and other larger items – NOT another toy machine like so many you see out there. This is really the only way to get into this size without stepping into the next level starting at 7K and up. Even K2 doesn't build this useful intermediate size anymore - you can set this up in a small garage shop without dedicating an entire room to it. The machine frame itself goes for over $3000. The PC was loaded with software, then stored – Just checked all software and checked the system out – this system doesn’t need to get on the net for anything, all software to run the CNC is installed and registered, including Machine3, Rhinoceros 4 and Lazy CAM (even has D-2 for those boring down times)… You can go for the new PC, and another break-out board if you choose – but this covers the need by itself. Also – it is an open architecture case – 3-unit cases fit anything without any risers or other proprietary hardware – it even locks. PDF files with the proper color coded wiring diagrams are included – and all you need is some multi-strand wire and proper logic to put this unit into service. My guitar business kept me too busy to focus on this system. And a heart attack 3 years ago added more limits. While I refined my standard approach to building instruments - I simply haven't been able to put this beauty into service. Also – with an impending move, I need to consider other options. Gotta let this one go, and put the funds into my moving expense. Bellow are some stat’s and details for the package. Shipping will be $200 within the US – and will consist of two packages. Sorry about the expensive transport, but this is some mass and weight, and needs to be handled properly… Machine Frame: K2 CNC Machine Frame Axis Travel 14” (X) - 25” (Y) - 7” (Z) 14” wide travel (side to side axis) 25” long (end to end axis) 7” deep (up and down axis) Hardened steel rods and bearings for all axis travel Billet and Structural extruded machine aluminum frame Some rolled steel reinforcement Limit switches & rubber feet installed Bosch Colt router bracket included for this machine frame MINT Bosch Colt router motor included (less than 2 hours use on router alone) Cable guides shown installed (will be removed for packing) Motor Bolts and couplings are included with bushings You can choose to mount a larger router/spindle – but will need to purchase brackets for this Computer System: 3-Unit Rackmount 24”deep PC case AMD Athlon Processor 300 GIGs of space - SATA DVD/CDRW Drive – SATA 3.5” Floppy Drive – with MEM ports Key-Lock case doors Windows XP with all updates installed No network needed to run as it is Machine 3 Installed Lazy CAM installed Rhinoceros 4 w/nerbs installed Nice case – may even be able to enclose the whole system Recommend more filtering for shop space installation MoBo has integrated Video and 25 pin DIN for connection Just needs your keyboard, mouse and monitor Tool-less access to top of case PDF files with color coded wiring diagrams for hook-up Case is in superb used condition – PC was loaded then stored Completely stable, with all you need to run the machine Please note: I cannot provide free support for your setup – it’s ready to go, but yours to setup You can setup a new system with different software in this case, but you will need to match up the motors with another break-out board and machine software – this is of course up to you, and what you are comfortable with. Stepper Motors: NEMA23 425oz/in 2.8A Stepper Motor 1/4 ” Dual shaft (KL23H286-20-8B) 425 oz In. Hybrid Motor 1.8° /200 Steps Per Rev. 2.8 Amps Current Per Phase ( Bipolar Parallel) 8-wire Bi-polar or unipolar, NEMA 23 Frame These motors have more than twice the recommended torque required for a CNC router with the larger Porter Cable router Motor attached... Power Supply: 36V/9.7A Switching CNC Power Supply (KL-350-36) 1: High Efficiency, Low Temperature, Small Size. 2: Over Load and Short Circuit Protection. 3: Over Voltage Protection. 4: Input: 120VAC or 220V Break Out Board: C10 Bidirectional Breakout Board, 6 Axis This card provides an easy way of interfacing your inputs and outputs from you parallel port. It provides terminals for the connections and conditions the signals for use in CNC applications. • Buffered inputs and outputs. Outputs are buffered through integrated circuits, allowing the card to output the signals without using the power from the parallel port. It can take the +3.3 or +5vdc at less than 1 milliamp from the parallel port and deliver solid +5vdc at 24 milliamps. • IEEE 1284 Standard compatible. Includes the circuitry recommended by the IEEE 1284 Level 1 standards for bidirectional parallel communications between personal computers and peripherals. • Has the option of using pins (2-9) for input or output. By selecting the appropriate jumper setting you can use these pins for input or output. If you use a second parallel port and set it to work in a bidirectional way, you get a total of 34 I/O pins. • Output pins 1,2,3,4,5,6,7,8,9,14,16,17. Or 1, 14,16,17. • Input pins 10,11,12,13,15. Or 2,3,4,5,6,7,8,9,10,11,12,13,15. • Input and output pins with close by ground or +5vdc connections. • The common terminal to pins 2-9 can be ground or +5vdc. The board has a jumper that allows you to select if the common terminal to pins 2-9 will carry a ground or +5vdc. So if you are connecting encoders or proximity switches, you can select it to ground. If you are connecting Geckodrives or limit switches, you can set it to be +5vdc. • External Enable Pin (EN). The board has a pin that allows you to enable/disable all the outputs at once. The board requires +5vdc in the EN pin. If it is not present, it will send all the outputs to ground. You can use this to enable or disable the system manually, or you can install an external Safety Charge Pump or other external device. • All TTL +5VDC or +3.3VDC Signals. Works with newer computers and laptops that have low voltage parallel ports Motor Drivers: KL-4030 Bipolar Stepper Motor Driver, 40VDC/3A 1: Voltage 24 to 40VDC, current up to 3.0 A 3: Suitable for 4,6,8 wire motors 4: Dip Switch setting(Micro Step): 1,1/2, 1/4, 1/8, 1/16, 1/32,1/64 5: Dip Switch setting( Current) 0.9A,1.2A,1.5A,1.8A,2.1A,2.4A,2.7A,3.0A 6: Full or Half Current Mode: Sw4: 0= Half Current 7: TTL compatible and Optically Isolated Signal I/O 8: Short-voltage, over-voltage, over-current and over temperature protection 9: Pulse input frequency up to 200 KHz 10: Support PUL/DIR and CW/CCW modes Winning bidder must contact me within three days of auction end to arrange shipping. Buyer pays $200.00 shipping in US. Instant service ONLY when buying this item - NO E-CHECK PAYMENTS - I accept CC through PayPal or standard PayPal payments. Shipping is US$350.00 to Canada – And US$420.00 to ship world wide. See my feedback and bid with confidence. From old tube amps to professional audio, and guitars to gadgets, I back up what I sell here. Thank you for your business, and good luck!

“New - stored in the open - perfect working order...”

Brand	K2 CNC
Country/Region of Manufacture	United States
Model	K2-1425
