Ka2284 Audio Level Meter Level Indicating Suit Led Indicator Diy Kit For Ard N6

US $8.39

Shenzhen, China
Jul 6th

Open on mobile:
QR code

KA2284 Audio Level Meter Level Indicating Suit LED Indicator DIY Kit for Ard n6 Melody audible, visual music! Five-point LED audio level indicator kit This package LED indication logarithmic 5:00 KA2284 integrated circuits as the core, which is characterized as follows: Constant current output a wide operating voltage (3.5V--12V) The ALC circuit without telescoped diode or transistor Brightness level in amplitude can be adjusted Chips : KA2284 PCB Board Size : 40X19mm This is an Electronic DIY KIT that utilizes the KA2284, some solde experience is required. The PCB (Printed Circuit Board) is provided with the DIY KIT and it needs to be soldered, hence the name DIY KIT. All required electronic parts are provided, please refer to the images for more details. All resistors are 0.25w metal film ,The image is for illustration . Package including : All components to build this kit 1 X PCB Board (color will be shipped out by randomly ) 2 X XH2.54-2P Curve connectors 2 X XH2.54-2P Line 1 X 100R Metal Film Resistor 1 X 10KR Metal Film resistor 1 X 2.2UF 1 X 10UF 1 X Blue&white Potentiometer 1 X KA2284 5 X 5mm diffused green 1 X 5mm diffused RED e: Random color, don't accept the specified color. e: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Brand	Unbrand
Country/Region of Manufacture	China
Marke	SODIAL
Model	Regular
Hersteller	SODIAL
Product	Regular
Sound Level	Regular
Operating Voltage	Regular
Custom Bundle	Regular
Maximum Current Rating	Regular
Bundle Description	No
Modified Item	NO
Resonant Frequency	Regular
Modification Description	No
UPC	191466823781
ISBN	191466823781
EAN	191466823781
