Kdx-02a Signal Generator Frequency Duty Cycle Driving Led 4.5-5.5v 13ma

US $2400

shenzhen, China
Nov 5th

Open on mobile:
QR code

New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Galler Power Modules Sensors Module Function Modules Development boards Wireless Modules DIY LED Boards LCD Modules Description KDX-02A Signal Generator Frequency Duty Cycle Driving LED 4.5-5.5V 13mA Product Introduction: 1.Power Voltage:4.5V-5.5V 2.Operating Current:13mA 3.Output Port OUT1 Output Signal Amplitude:0-Vcc 4.Max Output Current:20mA 5.Output Wave Shape:square wave 6.Output Frequency Stabilization:1/1000 7.Pin Space:2.54mm 8.Size:20*15*7.5mm(not include pin) 9.Output Signal Frequency:300Hz-160kHz adjustable;adjusting step distance is 1/100 of current frequency 10.Output Signal Duty Cycle:adjust step distance 1% Key Functions: 1.Simultaneously push "Frequency Adjusting" and "+" key;everytime push them,frequency will increase 1% by current frequency,duty cycle remains unchanged.If push the key for over 1s,frequency will increase quickly 2.Simultaneously push "Frequency Adjusting" and "-" key;everytime push them,frequency will decrease 1% by current frequency,duty cycle remains unchanged.If push the key for over 1s,frequency will decrease quickly 3.Simultaneously push "Duty Cycle Adjusting" and "+" key;everytime push them,duty cycle will increase 1%,frequency remains unchanged.If push the key for over 1s,duty cycle will increase quickly 4.Simultaneously push "Duty Cycle Adjusting" and "-" key;everytime push them,duty cycle will decrease 1%,frequency remains unchanged.If push the key for over 1s,duty cycle will decrease quickly 5.Simultaneously push "Frequency Adjusting" and "Duty Cycle Adjusting" key:save current frequency and duty cycle parameter,power off memory,then it will automatically operate according to saved parameter 6.Simultaneously push "+" and "-":reset function,restore to factory settings.Frequency is 10kHz,duty cycle is 50% Note:during the process of adjusting,you should push "frequency adjustment "and "duty cycle adjustment" key first, then push "+"and "-" key.When oscillator stops vibrating,OUT 1 port and OUT 2 port are both low level,until all keys rise Output Port OUT 2: 1.Auxiliary output terminal output frequency ia the same woth OUT 1 port,wave shape is opposite phase position 2.Auxiliary output port OUT 2 output signal is amplitude 0-5V,max output current is 20mA Shipping Payment Return Gurantee About us 1. Items are only shipped after PAYMENT confirmed. 2. Please check out your Paypal ADDRESS carefully when processing order. 3. Please CONTACT us ASAP if you haven't received the package in 35 days. 4. If you don't receive the parcel in 45 days, please allow us 3-5 working days for checking undelivered parcels before we issue you refund. 1. We only accept Paypal payment if you buy on ebay. 2. Please make sure you notice the entire desciption and agree to the transaction before buying. 1. If for some reason you're not satisfied with our service or product quality, please contact us within 3 days after you get the package, you can return the products to us in 30 days and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2. Although we test each item and they are packed professionally, few item(less than 0.1%) might be damaged during the shipping. You are welcome to contact us within 3 days after you receive your package about replacement. 3. Repair Some items might be broken caused by improper use, we are always happy to offer any helpful repair service. Of course, you can send the broken items back to us and we will help you resolve the situation and charge reasonable repair fees. 1.We Can promise to offer you the refund or replacement if you can not get packages on the normal delivery time. 2.If there is any problems with the item when you get it, please send us the ebay message for solution; Or you can return the item to us in 30 days. In our ebay shop, we mainly sell electronics, outdoor finishing accessoires, and all Funny Sorts. We can als offer wholesale service. inkfrog terapeak inkFrog Analytics On Nov-05-16 at 09:15:09 PDT, seller added the following information:
