Kentech -1.25 Kv High Voltage Picosecond Pulse Generator Nanosecond Ns Ps

US $1160

Santa Fe, New Mexico, United States
Jun 13th

Open on mobile:
QR code

Kentech -1.25 kV Dual Channel High Voltage Picosecond Pulse Generator Includes Refurbished Kentech MPS2/110/NN pulse generator Hofstra Group refurbishment Replaced degraded mechanical and electronic components Adjusted for best performance Fully characterized Download Test Report Applications Gated microchannel plate detectors Ultra-wideband radar systems Transient testing Electro-optic modulation Gated image intensifier cameras Streak cameras Options available from Hofstra Group Output pulse width changed to between 1.5 and 20 ns Output pulse forming for generation of monocycles or other simple waveforms Low-distortion high-voltage cable assemblies Reconfigure for 240 V AC input power The MPS series allows very high voltage, fast rising pulses to be obtained from a compact bench top unit. Low inter-channel jitter means that the outputs may be used to drive synchronized loads, such deflection plates, or be combined to drive low-impedances. This aspect makes the pulsers particularly useful for driving microchannel plate systems. This pulser can feed into a short circuit load without damage. This allows it to be used in sub-nanosecond pulse chopping systems by feeding through a pockels cell into a shorting stub. This unit requires AC power and a trigger signal to operate. The trigger signal, which is applied to the trigger input (BNC), should be approximately 10 V with a fast rising edge of <5 ns to achieve the lowest possible jitter. When triggered, the "triggered" light on the front panel will flash. The main output of the unit appears at the front panel connector (BNC). If it is necessary to monitor or characterize this pulse, suitable attenuators should be used. Kentech recommends the use of a high voltage, high speed attenuator manufactured by Barth as the first attenuator in a series. The high voltage pulse from this unit is capable of destroying many lower power attenuators, including GR types. The output may be characterized using a >3 GHz bandwidth oscilloscope. If the output of the HMPS pulser is to be used directly or via any passive network it is essential that cable lengths are kept as short as possible and that only high quality cable is used. This will enable the fast rising edge generated by the unit to reach the load without serious degradation. Specifications Output Impedance 50 Ω Fall Time 600 picoseconds Pulse Amplitude -1.25 kV Output Pulse Width 6.3 ns AC Power 120 V (or 240 V via internal jumpers) Number of Channels 2 Retail Price $12,770.79 Inspection by a Hofstra Group technician allows us to guarantee this hardware to perform to your satisfaction. This item carries a 7-day unconditional right of return and a 90-day warranty. In the unlikely event that you need to return it, we will arrange and pay for return shipping in addition to refunding the purchase price and original shipping. Please review our Sales Agreement for more information. _gsrx_vers_625 (GS 6.9.7 (625))
