Kern Dkm2-a - Operation, Service And Maintenance Manual - Pdf File

US $29.00

Gais, Switzerland
Aug 10th

Open on mobile:
QR code

PDF File of: Kern DKM2-AA - Operation, Service and Maintenance Manual Describsion Beschreibung Kern & Co., Aarau Kern DKM2-AA Theodolite, Surveying, Directional 1 Second of Arc. Operation Service and Maintenance Manual all you need to know to use and take care about you instrument ! many pictures, all parts are listed with part numbers and Describtion. In the back you will find 6 cross section with all parts no. The booklet has 82 pages and was printed in 1969 Content see below Please also visit my website Virtual Archive of WILD Heerbrugg , there you will find everything imaginable, many information and a lot of user manuals to Wild Heerbrugg, Heinrich Wild and Kern & Co. Aarau ... happy browsing J And if you can’t find what you’r looking for …. Please contact me, I have much more to offer. Kern & Co., Aarau Kern DKM2-AA Theodolite, Surveying, Directional 1 Second of Arc. Operation Service and Maintenance Manual hier finden Sie alles was Sie fr den Gebrauch und die Wartung fr Ihr Instrument wissen mssen! Viele Bilder und alle Teile sind mit Artikel Nummer und Beschreibung aufgelistet. Im Anhang finden Sie zustzlich 6 Schnittzeichnungen mit allen Nr. Text in Englisch ! Das Buch hat 82 Seiten und wurde 1969 gedruckt. Einen Ausdruck des Inhaltsverzeichnisses finden Sie weiter unten. Besuchen Sie doch auch einmal meine Webseite Virtual Archive of WILD Heerbrugg , dort finden Sie alles erdenkliche an Informationen und viele Gebrauchsanweisungen zu Wild Heerbrugg, Heinrich Wild und Kern & Co. Aarau … viel Spass beim stbern J Und sollten Sie etwas suchen was Sie nicht finden …. Einfach melden, ich habe noch viel mehr anzubieten. Technical Data Technical Data · Made in Switzerland · File Size : 9.1 MB · Made in Switzerland · Dateigrsse 9.1 MB Auction Includes Auktion beinhaltet · PDF FILE send by email after payment · PDF Datei zugeschickt by email nach Eingang der Zahlung Shipping Costs (Economy) Versandkosten (Economy) free, file (size 9.1 MB) will be send by email --- kostenlos, Datei (Grsse 9.1 MB) wird per email geschickt Payments & Invoice Bezahlung wire transfer (prefered) or Paypal, VAT invoice will be issued on request. Payment is expected within 5 days of listing end, or non paying bidder alerts will be issued by ebay. Bankberweisung (bevorzugt) oder Paypal Auf Wunsch wird eine Rechnung mitgeliefert Bezahlung wird innerhalb 5 Tagen erwartet, nichtzahlende Bieter werden an Ebay gemeldet Designed by : Virtual Archive of WILD Heerbrugg © ded5 Kern DKM2-AA - Operation, Service and Maintenance Manual Detail Classification: Operation, Service and Maintenance Manual Publiher: Kern & Co. Aarau Title Directional 1 Second Theodolite Surveing Instrument Type: DKM2-AA Category: --- Date: IX 69 Pages: 82 Language: English Table of Contents Section 1 ldentification and Description 1-1 General 1-2 Description 1-3 Technical Data 1-4 Accessories Section 2 Unpacking and Setting Up 2-1 Tripod 2-2 Shipping Case 2-3 Metal Carrying Case 2-4 Theodolite Section 3 Operation 3-1 Horizontal Angle Measurement 3-2 Vertical Angle Measurement 3-3 Example of Circle Reading 3-4 Electric Illumination 3-5 Elbow Eyepieces 3-6 Accessory Canvas Case 3-7 Knapsack Section 4 Testing and Adjusting 4-1 General 4-2 Plate Level 4-3 Index Error 4-4 Collimation Error 4-5 Optical Plummet 4-6 Tripod Section 5 Maintenance 5-1 General 5-2 Troubleshooting Section 6 Overhaul and Repair 6-1 General 6-2 Tribrach, Assembly 6-3 Cleaning and Lubricating of the Tangent Screws 6-4 Replacement of the Cover with Mieremeter Gear 6-5 Changing of the Plate Level 6-6 Cleaning and Lubricating of the Vertical Axis System 6-7 Adjustment of the Horizontal Circle Reading System 6-8 Cleaning and Lubricating of the Horizontal Axis System 6-9 Adjustment of the Vertical Circle Reading System 6-10 Cleaning of Horizontaland Vertical Circles 6-11 Replacement of the Telescope Objective, Adjusting of the Reticle and the Stadia Constant Section 7 Parts List 7-1 Theodolite, Tribrach, Assembly (Fig. 18) 7-2 Theodolite, Base with Optics, Assembly ( Fig. 19) 7-3 Theodolite, U-Standard, Assembly (Fig. 20) 7-4 Theodolite, Micrometer, Assembly (Fig. 21) 7-5 Theodolite, Telescope, Assembly (Fig. 22) 7-6 Theodolite, Metal Carrying Case (Fig. 6) 7-7 Shipping Case, No. 11 5.814.0003 (Fig. 5) 7-8 Tripod, Assembly, No. 184 BW (Fig. 23) 7-9 Battery-Case, No. 115.505.0010 ( Fig. 8) 7-10 Accessory Canvas Case ( Fig. 11) 7-11 Lighting Fixture, Optical plummet, No. 115.570.0017 ( Fig.11) 7-12 Elbow Eyepiece, Telescope, No. 461 F (Fig.11) 7-13 Elbow Eyepiece, Circle Reading, No. 461 K (Fig. 11) Appendix A References B Basic lssue ltems List C Maintenance Allocation Chart D List of Repair Parts and Special Tools

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Brand

Kern Aarau
