Keyence Fd-v70a Flow Control Sensor - Amplifier Unit, Din Rail Mount Type, Npn

US $280

Hayward, California, United States
Jun 9th

Open on mobile:
QR code

Keyence FD-V70A Flow Control Sensor - Amplifier Unit, DIN Rail Mount Type, NPN Model FD-V70A Type DIN-rail mounting type Current consumption At 12 V Normal 1500 mW (125 mA) or less*1 Eco mode 1320 mW (110 mA) or less*1 At 24 V Normal 2000 mW (83 mA) or less*1 Eco mode 1700 mW (70 mA) or less*1 Display power 3 digit dual row 7-segment LED (character height: Upper characters; 8 mm 0.315", red. Lower characters; 5.7 mm 0.224", green)Display refresh cycle: 5 times/second (10 times/second when response time is 0.5 seconds in the standard display mode) Operation status indicators Red LED x 3 (corresponding to control output 1, control output 2, and the abnormality alarm output) Detecting area FD-P05 0.5 to 5 L/min FD-P20 2 to 20 L/min FD-P50 5 to 50 L/min FD-P100 10 to 100 L/min FD-F04 0.4 to 4 L/min FD-F20 2 to 20 L/min FD-F50 5 to 50 L/min Display resolution Standard display mode oraveraged display mode FD-P05 0.01 FD-P20 0.1 FD-P50 FD-P100 FD-F04 0.01 FD-F20 0.1 FD-F50 Averaged 2-digit displaymode FD-P05 FD-P20 1 FD-P50 FD-P100 FD-F04 0.1 FD-F20 1 FD-F50 Hysteresis Variable Response time (chatter prevention feature) Selectable from 0.5, 1, 2, 5, 20 and 60 Accumulated flow unit FD-P05 0.01, 0.1, 1, 10, 100Selectable fromthe above FD-P20 0.1, 1, 10, 100, 1000Selectable from the above FD-P50 Integratedflow unit FD-P100 Accumulated flow unit FD-F04 0.01, 0.1, 1, 10, 100Selectable fromthe above FD-F20 0.1, 1, 10, 100, 1000Selectable from the above Integratedflow unit FD-F50 Integration reset/bank input Input time 20 ms or greater (Analog output/abnormality alarm output switchable) Control output/integration pulse output NPN open collector Max. 50 mA (40 V or less) Residual voltage 1 V or less, 2 outputs (N.O./N.C. switchable) Abnormality alarm output NPN open collector Max. 20 mA (27 V or less) Residual voltage 1 V or less, (ON at abnormality/analog output, integration reset, bank input switchable) Analog output 4 to 20 mA Maximum load resistance 260 ?Analog output range can be set with the maximum 10% step of F.S. Repeatability ±0.5% of F.S. or less (Fluid temperature 20°C 68°F at the ambient operating temperature of 25°C 77°F) Rating Power voltage 12 to 24 VDC, ripple (P-P): 10% or less Environmental resistance Operating temperature range 0 to 50°C 32 to 122°F, no freezing Operating ambient humidity 35 to 85% RH (No condensation) Vibration 10 to 55Hz Compound amplitude 1.5 mm 0.06" XYZ 2 hours for each axis Material Main body and cover: polycarbonate, Key top: silicon rubber Accessories Power cable, mounting bracket, Instruction Manual Weight about 85 g (including power cable) *1 Excluding analog output current. Including head block. *** What you see is what you get! Pictures are taken at the time of listing. If it's not in the photos, it's not included in the lot, unless otherwise stated directly in the ad. *** Available for local pick up at our office in Hayward, California Shipping quoted includes any handling charges plus UPS Ground (5-7 days), Insured, to the lower 48 States only. If you need it shipped elsewhere, please contact us for a shipping quote. Depending on your location, your shipping may be less, in which case we will refund the difference. Returns are accepted within 14 days. Re-stocking fees may apply. Please see our full return policy for details. If you have questions or concerns, please message us, or call Nancy or Ray at 510-784-1111. We're here Monday-Friday, 8 am - 4:30 pm PST, and at other times by chance! ! ~ Thank You For Shopping ~ ! 1529 C29 -S3 -B4 RC 6/5/2015
