Keysight (agilent) Technologies 4395a Network/spectrum/impedance Analyzer

US $6,750.00

Irving, Texas, United States
Jun 9th

Open on mobile:
QR code

Keysight (Agilent) Technologies 4395A Network/Spectrum/Impedance Analyzer Key Features & Specifications High-performance network, spectrum, and impedance analyzers in a single box Built-in IBASIC GPIB port, digital I/O port Network analysis Frequency range: 10 Hz to 500 MHz 115 dB dynamic range @ 10 Hz IFBW +/-0.05 dB, +/-0.3 degree dynamic accuracy Spectrum analysis Frequency range: 10 Hz to 500 MHz -145 dBm/Hz sensitivity @ 10 MHz Time-gated spectrum analysis option (4395A-1D6) Impedance analysis (option 4395A-010) Frequency range: 100 kHz to 500 MHz Equivalent circuit analysis function +/- 40 V or +/- 100 mA DC bias (Option 4395A-001) Description The 4395A provides excellent vector network, spectrum, and optional impedance measurements for lab and production applications. Gain, phase, group delay, distortion, spurious, CN, and noise measurements often required for evaluating components and circuits can be measured using one instrument. When combined with a test set, the 4395A provides reflection measurements, such as return loss, SWR, and S parameters. As a vector network analyzer, the 4395A operates from 10 Hz to 500 MHz with 1 MHz resolution; and its integrated synthesized source provides -50 to + 15 dBm of output power with 0.1 dB resolution. The dynamic magnitude and phase accuracy are +/-0.05 dB and +/-0.3 deg. so that it can accurately measure gain and group delay flatness, which are becoming more important in modern electronics systems. As a spectrum analyzer, the 4395A operates from 10 Hz to 500 MHz with resolution bandwidths (RBWs) spanning 1 Hz to 1 MHz in a 1-3-10 steps. A fully-synthesized local oscillator allows stable and accurate frequency analysis. Direct A/D conversion (no LOG amplifier is used) results in +/-0.8 dB level accuracy (@50 MHz, -20 dBm). Noise sidebands fall below -100 dBc/Hz @ 100 kHz offset from carriers, while sensitivity is -145 dBm/Hz at 10 MHz. Options installed: 010 IMPEDANCE MEASUREMENT FUNCTION 1D6 ADD TIME-GATED SPECTRUM ANALYSIS Accessories included: 36F1255 Power cord 04395-90501 Document Set & CD ROM MATsolutions “Buy with Assurance" Please Contact Nicole Augspurger at MATsolutions for Questions regarding this listing at (877)621-1280.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Keysight (Agilent)
Country/Region of Manufacture	Malaysia
Model	4395A
