Kinco Eview 8" Hmi Mt6400t-can Touch Screen Touch-panel Display Screen New

US $1,708.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Kinco Eview 8" HMI MT6400T-CAN TOUCH SCREEN TOUCH-PANEL DISPLAY SCREEN New Introduction: The MT6000 kinco HMI high-end products, its strong performance the Intel PXA270 520MHz processor and friendly interface of the Windows CE operating system, will bring you the new experience. Its open programming environment and powerful communications capabilities make it ideal for industrial automation, building automation and smart home applications. Features: *completely open man-machine interface, the product pre-installed WinCE5.0 system, limitless possibilities, to create by you; *and Code sys perfect combination, creating functional excellence in the panel PLC; *the MT6000 software development tool kit (SDK) and the necessary documentation and technical support to help customers develop software; *equipped with serial ports, USB master / slave interface, Ethernet interface and standard CAN interface. Specifications: MT6400T-CAN Display: 8" TFT LCD, resolution 640 * 480,65536 color Operating System: Windows CE 5.0 Power supply: 24VDC, 10.2W Part number MT6400T MT6400T-CAN Specifications Display module 8" TFT Resolution 640*480 Display Colors 65536 color Brightness 350 cd/m2 Backlight type 1 CCFL CPU 32-bit 520MHz RISC Operating system Windows CE 5.0(pro) Windows CE 5.0(core) RAM 64MB (RAM frequency 104MHz) Flash 32MB NOR flash SRAM 512K byte, Battery backup Expandable memory 1 SD card,2 U disk; support to 2GB USB Host interface USB Host interface: 2 compatible with USB1.1 specification interface, mouse, keyboard, USB storage devices, printers and other peripherals can be connected USB Client interface 1 USB Client interface compatible with USB1.1 specification from the interface, suitable for connection to the ActiveSync program Touch panel 4-wire precision resistor network (surface hardness 4H) LCD life 50000 hours Print interface USB HOST interface connect with a USB interface printer Ethernet A 10M/100M adaptive Ethernet port Audio output 1 Line-out 3.5mm output interface Download A USB SLAVE interface, Ethernet Communication interface COM0:RS232/RS485-2/RS485-4, COM1:RS232/RS485-2/RS485-4, COM2:RS232 Extended Interface Standard with no extension CAN open extension card Optional interface A Hilscher ® COM module slots can be configured as a Profibus-DP master interface(under development) 1 Profibus-DP slave interface 1 MPI interface Optional Ethernet interface 2 interface can be extended to the Industrial Ethernet (under development) Applicable software CoDeSys V2.3; MoviconCE V10/V11; Iconics Genesis 32;KW ProVIST Electrical Specifications Rated power 10.2W The amount of voltage DC24V Input range 21~28VDC Allows the loss of power <3ms Insulation resistance More than 50M?@500VDC Pressure resistance 500V AC 1minute environment Specifications Operating Temperature 0~45 °C Operating Humidity 10~90% RH(no condensation) Storage Temperature -10~60 °C Storage humidity 10~90% RH(no condensation) Seismic performance 10~25 Hz (X, Y, and Z the direction 2G/30 minutes) Cooling method Natural air-cooled Product certification Front Panel Protection IP65 certified (4208 93) CE certification CE compliant (EN61000-6-2: 2005/EN61000-6-4: 2007) FCC compliance Line with FCC Class A Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM Shipment: Once payment received. Item will be shipped out within 1-3 working days by DHL, Fedex, UPS, EMS ASAP. Usually it takes 3-7 working days to most of the country. You will be notified the traking number once shipped out. Kindly please note the Tax fee and Customs clearance fee are not included in the item’s listing price. Kindly please feel free to contact us before shipping if there’s any thing we can do for you. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: We accept return or refund within 14 days for the quality reason, not man-made reason. Kindly please contact us before returning the package. Payment will be refunded to you within 24hrs once the package received by us. You understanding appreciate. Kindly note: Pls check and confirm the part NO. and your application before place order, any further assistance please feel free to let us know.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Kinco
MPN	MT6400T-CAN
Model	MT6400T-CAN
Country of Manufacture	China
