Kit-2 Way Faston Terminal&connectors, Ul, Rohs, 6 Pcs, 6.3mm (.250), 14-10 Awg

US $5.40

Katy, Texas, United States
Jun 9th

Open on mobile:
QR code

SPECIFICATIONSOne (1) Kit includes: One (1) Receptacle housing and one (1) tab housing for single connection - 6.3 mm (0.250 Series), Two (2) straight receptacles locking lance with dimple (female), and two (2) tab with locking lance (male). Total: six (6) pieces. See below technical Information for each piece Tab with locking lance 6.3 mm (.250 series) - Without hole - Male terminal Wire Size Range (mm2) Wire Size range (AWG) Max. Temp. °F (°C) Tab Thickness (mm) Material and Finish Dimensions (mm) W L E 2.5-6 14-10 248 °F (120°C) 0.40 Pre-tin Plated Brass 6.3 28 15.8 Approval Regulations: RoHS, ULStraight Receptacle with Dimple 6.3 mm (.250 Series) - Female Terminal Wire Size Range (mm2) Wire Size range (AWG) Max. Temp. °F (°C) Resist. (m?) Tab Thickness (mm) Material and Finish Dimensions (mm) W L E 2.5-6 14-10 230 °F (110°C) 1.06 0.4 Natural Brass 7.6 19 8.5 Temperatures as per IEC 61210 standard. Approval Regulations: RoHS, UL Max. Rated current: Values on the table below show the recommended maximum current values, limited by the cross section of the cable used. These maximum values also depend on the ambient temperatures, and can be reduced depending on the working conditions. Please email us if you need any data sheet. Wire Section (mm2) Current (A) 2.50 20 4.00 26 6.00 34 Housing 6.3 mm (.250 Series) Material Color UL Standard Flammability Classification Max. Operating Temp. Dimensions (mm) W L H Nylon Natural UL310 V2 266° F (130°C) 12 32 9.2 Receptacle Housing 6.3 mm (.250 Series) Material Color UL Standard Flammability Classification Max. Operating Temp. Dimensions (mm) W L H PA66 V2 Natural UL310 V2 266° F (130°C) 10.1 23.7 6.3 RoHS compliant. Shipping Information: Kit (s) will be sent by First Class Package USPS using large envelope. Any question or concern, please do not hesitate to contact us by eBay messages.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Escubedo
Country/Region of Manufacture	Spain
MPN	10120-A
