KIT-6 WAY FASTON TERM & CONN, UL, RoHS,14 Pcs, 6.3mm (.250),14-10 AWG, TIN BRASS, US $210 – Picture 0
KIT-6 WAY FASTON TERM & CONN, UL, RoHS,14 Pcs, 6.3mm (.250),14-10 AWG, TIN BRASS, US $210 – Picture 0

Kit-6 Way Faston Term & Conn, Ul, Rohs,14 Pcs, 6.3mm (.250),14-10 Awg, Tin Brass

US $210

  • Katy, Texas, United States
  • May 26th
Open on mobile:
QR code
SPECIFICATIONSOne (1) Kit includes: One (1) Receptacle housing and one (1) tab housing for single connection - 6.3 mm (0.250 Series), Six (6) straight receptacle locking lance with dimple (female), and six (6) tab with locking lance (male). Total of pieces per kit: Fourteen (14). Please see pictures and count pieces per kit. Both Male & Female terminals are made with Tin Plated Brass Material (see pictures) See below technical Information for each piece Tab with locking lance 6.3 mm (.250 series) - Without hole - Male terminal Wire Size Range (mm2) Wire Size range (AWG) Max. Temp. °F (°C) Tab Thickness (mm) Material and Finish Dimensions (mm) W L E 2.5-6 14-10 248 °F (120°C) 0.40 Pre-tin Plated Brass 6.3 28 15.8 Approval Regulations: RoHS, ULStraight Receptacle with Dimple 6.3 mm (.250 Series) - Female Terminal Wire Size Range (mm2) Wire Size range (AWG) Max. Temp. °F (°C) Tab Thickness (mm) Material and Finish Dimensions (mm) W L E 2.5-6 14-10 248 °F (120°C) 0.40 Pre-tin Plated Brass 7.4 19.2 7.5 Temperatures as per IEC 61210 standard. Approval Regulations: RoHS, UL Max. Rated current: Values on the table below show the recommended maximum current values, limited by the cross section of the cable used. These maximum values also depend on the ambient temperatures, and can be reduced depending on the working conditions. Please email us if you need any data sheet. Wire Section (mm2) Current (A) 2.50 20 4.00 26 6.00 34 Housing 6.3 mm (.250 Series) Material Color UL Standard Flammability Classification Max. Operating Temp. Dimensions (mm) W L H Nylon Natural UL1977 V2 149° F (65°C) 31.5 32 18 Receptacle Housing 6.3 mm (.250 Series) Material Color UL Standard Flammability Classification Max. Operating Temp. Dimensions (mm) W L H PA66V2 Natural UL1977 V2 149° F (65°C) 28.5 24 15.2 RoHS compliant. Shipping Information: Kit (s) will be sent by First Class Package USPS using thick envelope. Any question or concern, please do not hesitate to contact us by eBay messages.
