Knight Ml2010 Mini Lab

US $500.00

Cumming, Georgia, United States
Jan 29th

Open on mobile:
QR code

ML2010 Mini Lab - Analog Digital Trainer The ML2010 is a complete prototyping station and has been designed to consolidate all of your test equipment needs into one compact package. This miniature laboratory used in conjunction with an oscilloscope and multimeter puts everything you need at your fingertips for building and testing all types of digital and analog circuits. Specifications POWER INPUT: 120 VOLT AC 50/60 HZ FUSED (2A 250V, 5x20mm GLASS, FAST ACTING) LIGHTED POWER ON INDICATOR DC POWER SOURCES: +5 VOLTS ±3% @ 1 AMP -5 VOLTS ±3% @ 1 AMP +12 VOLTS ±3% @ 1 AMP -12 VOLTS ±3% @ 1 AMP 0 TO >+18 VOLTS VARIABLE @ 1 AMP 0 TO >-18 VOLTS VARIABLE @ 1 AMP (ISOLATED GROUND FOR VARIABLE SUPPLIES) 0.1% LINE REGULATION 0.1% LOAD REGULATION SHORT CIRCUIT AND THERMAL OVERLOAD PROTECTED AC POWER SOURCE: 15 VOLTS CENTER TAPPED @ 500 MILLIAMPS PULSE GENERATOR: CONTINOUSLY VARIABLE IN FIVE DECADE RANGES: PULSE WIDTH: =10mSEC PULSE REPETITION: = 100mSEC OVERLAP INDICATOR CAPABLE OF 100% DUTY CYCLE PULSE POSITION AND WIDTH MODULATION INPUTS TTL COMPATIBLE GATE AND TRIGGER INPUTS RISE AND FALL TIMES LESS THAN 10nSEC SWEEP RAMP GENERATOR: ADJUSTABLE PERIOD - = 1SEC ADJUSTABLE 0 TO 3.7 VOLT OUTPUT AMPLITUDE NEGATIVE LINEAR RAMP OUTPUT FOR LINEAR SWEEP SEPARATE TTL COMPATIBLE SYNC OUTPUT FUNCTION GENERATOR: SINE, SQUARE, OR TRIANGLE WAVE OUTPUT 0 TO 18 VPP OUTPUT AMPLITUDE ~500 OHM OUTPUT IMPEDANCE SHORT CIRCUIT PROTECTED DC OFFSET ADJUSTABLE FROM 0 TO %10 VOLTS SEPRATE TTL/HC COMPATIBLE CLOCK OUTPUT (20mA OUTPUT AT 0.33VDC (LOW) OR 4.3VDC (HIGH) RISE/FALL TIME LESS THAN 20nSEC CONTINUOUSLY VARIABLE FREQUENCY FROM 1HZ TO 1MHZ IN SIX DECADE RANGES (NOTE: DUE TO LIMITATIONS OF THE FUNCTION GENERATOR CHIP WAVEFORM VARIATIONS, OR ROLL OFF, MAY BE EXPERIENCED AT THE MAXIMUM RANGE.) DISTORTION: SINE WAVE = 100KHZ TRIANGLE WAVE = 100KHZ RISE & FALL: SQUARE WAVE <= 20nSEC FREQUENCY MODULATION INPUT AMPLITUDE MODULATION INPUT BURST INPUT SWEEP INPUT CAPABLE OF 1000:1 SWEEP (START FREQUENCY DETERMINED BY SWEEP RAMP AMPLITUDE STOP FREQUENCY DETERMINED BY GENERATOR FREQUENCY SETTING) SPEAKER: 2- 1/4 "e; 8? 0.25W POTENTIOMETERS: UNDEDICATED 1K? AND 100K? LINEAR TAPER 20% 0.125W INDICATORS: EIGHT BUFFERED LED CMOS/TTL COMPATABLE) SWITCHES: EIGHT LEVEL - 0V OR +5V UNBUFFERED TOGGLE SWITCHES TWO UNDEDICATED SPDT TOGGLE SWITCHES [ON - NONE - ON] TWO UNDEDICATED SPDT MOMEMTARY [ON - NONE - (ON)] PULSERS: TWO TTL LEVEL DEBOUNCED PULSERS WITH COMPLEMENTARY OUTPUTS INTERFACE: DB25 MALE -; DB9 MALE - DB25 FEMALE DB25 FEMALE - DB9 FEMALE - DB25 FEMALE (DB25 TO DB25 PINNED 1 TO 1 WITH DB9 COMMON TO FIRST 9) THREE BNC TO TIE-POINT BLOCK

Condition:

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...

Brand

Knight
