Kohler Detroit Engine Series 60 & Diesel Generator Sets - 50 Hz - 360p5 Diesel

US $15,000.00

BHAVNAGAR, GUJARAT, India
Jun 9th

Open on mobile:
QR code

Welcome to Aeliya Marine Tech Private Limited 100% Genuine Products | Buy with confident | 14 Days Return Policy DESCRIPTION KOHLER DIESEL GENERATOR SETS ENGINE MAKE : DETROIT DIESEL SERIES : SERIES 60 ENG. MODEL : 6063TK35 GEN. MODEL : 360P5 DATE : 2000-01-02 RPM 1500 HZ : 50/60 KVA : 360 @ 1500 RPM QTY : 07 SETS RUNNING HOURS AND SERIAL NUMBER # UNIT NUMBER R/H 1 06R0546601 3800 2 06R0546709 4300 3 06R0546716 3200 4 06R0546723 6800 5 06R0497645 7100 6 06R0448627 7400 7 06R0448643 8500 Shipping by Sea Freight. Sea Freight can be quote on request. Can Ship Worldwide. Purchased from a kohler rental division. Running Hours mentioned as above. Discount available on bulk purchase. Required normal service before using as lying idle since last two years. COMPANY BROCHURE DETAILS MODEL: 360P5 50Hz Diesel High fuel efficiency up to 4.3kWh / litre of diesel at 75% load. Standard Features • Kohler Co. provides one-source responsibility for the generating system and accessories. • A one-year limited warranty covers all systems and components. Two-, five- and ten-year extended warranties are available. • Heat Exchanger cooling system. • Generator features: o Brushless, rotating-field generator has broadrange reconnectability. • Other features: o Controllers are available to meet all applications. See controller features inside. o Low coolant level shutdown protects generator set from overheating. o Integral vibration isolation eliminates the need for installation of vibration spring isolators under the unit. o Electronic, isochronous governor provides precise frequency regulation. o Electronic engine controls and a generator microprocessor controller combine to make one of the most advanced control systems in today’s generator market. Generator Output Ratings Model Voltage Ph Hz Prime Rating (125°C Rise) kW / kVA 360P5 380 - 416 3 50 288 / 360 Dimensions & Weights Model Dimension, L x W x H, mm Weight, Kg (lb), Dry 360P5 3140 x 1090 x 1930 2900 (6380) NOTE: Dimensions are provided for reference only and should not be used for planning installation. Contact your local distributor for more detailed information. Ratings: PRIME RATING: Operating continuously for unlimited hours on a varying load of 75% load factor. No overload rating allowed. Altitude: Derate 0.5% per 305 m (1000 ft) elevation above 1525 m (5000 ft.) up to a maximum elevation of 3660 m (12000 ft.). Temperature: Derate 1.0% per 5.5?C (10?F) temperature above 40?C (104?F). Fuel consumption is calculated at specific gravity of 0.85 (±5%). Cooling air density taken as 1.20kg/m3. GA5-205 (360P5) 12/03 Alternator Specifications Specifications Generator Type 4-Pole, Rotating Field Exciter type Brushless, External Voltage Regulated Voltage regulator Solid State, Volts / Hz Insulation: NEMA MG1 - 1.66, Material .......... Class H, Synthetic, Nonhygroscopic Temperature rise .......... 125°C Prime Bearing: number, type 1, Sealed Coupling Flexible Disc Amortisseur windings Full Voltage regulation, no load to full load ± 1% (with <0.5% drift due to temp variation) • Compliance with NEMA, IEEE, and ANSI standards for temperature rise. • Transient performance meets the requirements of ISO 8528-5, Class G3. • Sustained short-circuit current of up to 300% of rated current for up to 10 seconds. • Sustained short-circuit capability enabling downstream circuit breakers to trip without collapsing the generator field. • Self-ventilation and drip-proof construction. • Superior voltage waveform from two-thirds pitch windings and skewed stator. • Solid State Electronic, volts-per-hertz voltage regulator with ± 1% no-load to full-load regulation. • Brushless alternator with brushless pilot exciter for excellent load response. Application Data Engine Engine Specifications 50Hz Engine: model Detroit Diesel S60 Engine: type 4-Cycle, Turbocharged Cylinder head arrangement 6, in-line Displacement, L (cu. in.) 12.7 (778) Bore and stroke, mm (in) 130 x 160 (5.12 x 6.30) Compression ratio 15.0 : 1 Piston speed, m/sec. (ft/min) 8.0 (1575) Main bearings: number, type 7, Precision Half-Shell Rated rpm 1500 Max. power at rated rpm, kWm (BHP) 321 (430) Cylinder head material Cast Iron Crankshaft material Forged Steel Valve material: Intake .......... Iron Based Seat Exhaust .......... Nickel Based Seat Governor: type, make / model Electronic, Fuel Injection Control, DDEC Frequency regulation, no load to full load Isochronous Frequency regulation, steady state ± 0.25% Air cleaner type, all models Dry Exhaust Exhaust System 50Hz Exhaust flow at rated kW, m3/min (cfm) 61.8 (2183) Exhaust temperature at rated kW, dry 442.7 (829) exhaust, °C (°F) Maximum allowable back pressure, 10.1 (3.0) kPa (in Hg) Engine exhaust outlet size, mm, (in.) 127 (5) Engine Electrical Engine Electrical System 50Hz Starter motor rated voltage (DC) 24 Recommended battery cold cranking 950 amps (CCA) rating Quantity of batteries 2 Battery voltage (DC) 12 Fuel Fuel System 50Hz Fuel supply line, min. ID, mm (in.) 12.7 (0.50) Fuel return line, min. ID, mm (in.) 8.0 (0.31) Max. lift, engine-driven fuel pump, m (ft) 2.1 (6.8) Max. fuel flow, Lph (gph) 348.5 (92.2) Fuel prime pump N/A Fuel filter 2, Primary / Secondary Recommended fuel #2 Diesel Lubrication Lubricating System 50Hz Type Full Pressure Oil pan capacity, L (qts.) 30.0 (32) Oil pan capacity with filter, L (qts.) 36.0 (38) Oil filter: quantity, type 2, Cartridge Oil cooler Water-cooled GA5-205 (360P5) 12/03 Application Data Available Cooling System Cooling System (Heat Exchanger) 50Hz Ambient temperature, °C (°F) 50 Engine jacket water capacity, L (gal) 23 (6.1) Engine jacket water flow, Lpm (gpm) 302.4 (80) Heat rejected to cooling water, 121.3 (6900) at rated kW (Btu/min) Heat rejected to air charge cooler 65.0 (3700) kW (Btu/min) Water pump type Centrifugal Max. permissible ext. rest. in CAC 10.1 (3.0) circuit, kPa (in Hg) Max. permissible ext. rest. in JW 5.07 (1.5) circuit, kPa (in Hg) Temperature of raw water available, °C (°F) 32 (89.6) Raw water flow rate through JW cooler, Lpm 200 Raw water flow rate through CAC cooler, Lpm 160 Operation Requirements Air Requirements 50Hz Radiator-cooled cooling air, N.A. m3/min. (scfm)† Combustion air, m3/min (cfm) 24.8 (876) Heat rejected to ambient air: Engine kW (Btu/min) .......... 43.9 (2500) Generator kW (Btu/min) .......... 19.4 (1108) † air density = 0.075 lbm/ftS or 1.20 kg/m Fuel Consumption 50Hz Diesel, Lph (gph) at % load Prime Rating 100% 71.8 (19.0) 75% 54.4 (14.4) 50% 37.4 (9.9) 25% 20.8 (5.5) Controller Decision-MakerTM 3+, 16-Light Controller Audiovisual annunciation with NFPA 110 Level 1 capability. Microprocessor logic, AC meters, and engine gauge features. 12- or 24-volt engine electrical system capability. Remote start, prime power, and remote annunciation options. Decision-MakerTM 3+, 16-Light ABOUT US We are one of the big collectors of Marine Equipment & Spares from India with our reputed name since last many years, we have very deep knowledge of Marine Equipment & Automation Equipment. We believe that client satisfaction is the basic factor which determines the success of any business. Therefore, in order to satisfy our clients, we provide the highest quality products along with excellent customization facilities. The favorable attributes of our organization have enables us to successfully cater to the international markets. PAYMENT We accept payment through PayPal as it is safest and quickest mode of payment which not only enables us to expedite your shipment but also protects every one's interest. SHIPPING We ship Worldwide and assure dispatching the Product 2 - 6 days soon after the Payment Confirmation is received. If for some reasons, shipping of the product is delayed, you would be duly informed about the same along with the expected date when the product would be shipped. If for some reasons beyond our control, your area is not serviceable by our logistic partners, we will refund the money. Tracking number will be provided once consignment shipped. Import duties and other destination taxes would be buyer's responsibility. PACKING We understand that you want your product to reach you in its Best Condition, Thus the products would be packed properly in a Tamper Proof Packing Material that Protects the product from being Damaged or Soiled or any other Damages. RETURN POLICY If there is any problem with the Item or delivery, please contact us Before leaving the Feedback. We will make sure that the issue is sorted out Refund is payable after receiving product has to be returned in Good salable condition. Return will be accepted within 14 Days only. In case of return Buyer will pay the return charges. Shipping charges is nonrefundable. FEEDBACK In case you are not satisfied, please contact us immediately. We will do everything possible to please you and bring a smile on your pretty face. Looking forward for your Positive Feedback. We believe that all disputes can be settled by proper communication. So please communicate for faster resolution. CONTACT US If you have any query please feel free to contact us through eBay message system or By clicking "Ask a Question" tab below the listing. Our Email : ebay@aeliyamarine.com

“Purchased from a kohler rental division. Running Hours mentioned in below message.Discount available on bulk purchase. Required normal service before using as lying idle since last two years.”

Brand	Detroit Diesel , Kohler
kVA	360
Model	6063TK35 - 360P5
Kilowatt	288
MPN	SPEC A 343795 SP
Make	Kohler
Country/Region of Manufacture	United States
Type/Series	Diesel Engine, Stationary Generator
Rated Speed	1500 RPM
BC Category	Miscellaneous/Generator Sets
