Kulthorn Aw2510z-2 Low Temp Compressor 2-1/2 Hp, R404a, 230v

US $960

Brooklyn, New York, United States
Nov 5th

Open on mobile:
QR code

Electrical : 200-230 V/60 Hz. 1 Phase Nominal Performance Capacity 2,946 / - Watts 10,052 / - BTU/Hr 2,533 / - Kcal/Hr Power Input 2,806 / - Watts Locked Rotor Amps 90.00 / - Amps Max Continuous Current 21.20 / - Amps Rated Load Amps 13.10 / - Amps COP 1.05 / - Watts / Watts EER 3.58 / - BTU/W-Hr Testing Conditions (ARI) Condensing Temperature 120.0 °F Evaporating Temperature -10.0 / - °F Liquid Temperature 120.0 °F Return Gas Temperature 40.0 °F Ambient Temperature 95.0 °F Application Evaporating Temp. Range LBP @ -40.0° F to 10.0° F Refrigerant R404A Refrigerant Flow Control Capillary Tube Compressor Cooling Fan Compressor and Motor data Compressor Type Reciprocating Displacement 71.00 cc. Oil Type Polyolester Oil Oil Charge 1,142 cc. Motor Type C.S.R. ; 2 Pole 3,500 / - r/m Voltage Range 198-253/- Volts 60/- Hz. Winding Resistance at 75°F Start 2.37 Ohms Run 0.71 Ohms Electrical Components Motor Protector Type Internal Overload Model Number KGE 656-17 Open / Close 130-140 / 78-60 ° C 1st Cycle trip at 25 ° C 87.0 Amps(main) 42.0 Amps(start) Motor Starter (CSR Only) Type Potential Relay Model Number KGE 681-9 (RVA4AM6D) Pick Up (max.) 242.00-272.00 Volts Drop Out (min.) 60.00-121.00 Volts Terminal Cover KGM 901-2 Start Capacitor (CSR Only) 216-259 µF 250 VAC. Disch Resistor for Start Cap 15000 Ohms 2 w Run Capacitor 45 µF 450 VAC.
