Kurz Series 454ft Insertion Mass Flow Transmitter

US $249.98

Irmo, South Carolina, United States
Aug 1st

Open on mobile:
QR code

OVERVIEW: (per manufacturer) The Kurz Instruments 454FT series of insertion mass flow transmitters are point velocity sensing devices. This bivariable transmitter also measures the process temperature. The flow element is a constant temperature thermal anemometer which intrinsically measures the process fluid Reynold’s number. The net meter response is mass rate per unit area. The engineering output may be scaled to represent standard velocity, standard volumetric flow or mass rate. Density changes are automatically accounted for negating the need for pressure and temperature compensation. A complete description of how and what the thermal anemometer measures can be found in Appendix A. The units must be calibrated in the gas type to be measured or may be correlated from Air calibrations if available. The process temperature measured with this series will read accurately (within a few degrees C) above 100 SFPM (0.5 SMPS). The unit has an optional LCD/keypad local interface which can be used for complete setup, control and monitoring. The 454FT is a 3, 4 or 5-wire device whose 4- 20 mA output current is directly proportional to the flow rate. A second 4-20 mA output can be used for temperature or a different flow scale. The unit is available as 24 VDC, 115 VAC @ 50 to 60 Hz, or 230 VAC @ 50 to 60 Hz powered. The 4-20 mA output can be nonisolated self-powered or isolated loop-powered. The typical configuration has all the electronics in one enclosure, known as the TA configuration, or with just the sensor and a terminal wiring board in a separate enclosure from the electronics in the TS configuration. Both cases are shown in the field wiring diagrams. The TS configuration is used where the sensor enclosure ambient temperature is expected to exceed 65 °C, allowing the electronics to be mounted separately in a cooler place. SPECIFICATIONS: Process Temperature Rating: MT:–40˚C to 200˚C HHT:–40˚C to 500˚C Process Pressure Rating: 300 PSIG (15 BAR) Sensor Material: Alloy C-276; optional abrasion-resistant Chromium Nitride coating on Alloy C-276 sensor materials, PTFE coating for chemical resistance on Alloy C-276 sensor and sensor support, HHT sensors, 260˚ max. Sensor Support Material: 316L Stainless Steel, optional Alloy C-276. Repeatability: 0.25% Velocity Time Constant: 1 second for velocity changes at 6000 SFPM at a constant temperature and 1 second for temperature changes at a constant velocity of 6000 SFPM. Process Temperature Time Constant: 8 seconds at a velocity of 6000 SFPM. Velocity Accuracy: See Feature 8 for overall accuracy including the effects of process temperature. Temperature Accuracy: ±(1/2% of reading +1˚C) for velocities above 100 SPFM. Power: +24 VDC ±10%,115/230 VAC ±10% 50/60 Hz; 15 watts max. Enclosure Temperature Rating: -25˚C to +65˚C with LCD/Keypad option;-40˚C to +65˚C without LCD/Keypad option. Enclosure: Dual-Chamber, Epoxy-Painted aluminum, IP66, NEMA 4X/7 with glass window for display option. Solid-State Relays: Optically isolated, .8 ampere, 24 VAC/VDC maximum Analog Outputs (4-20 mA): Optically isolated, user looppowered, 12 bit resolution and accuracy, maximum loopresistance is 500Ω at 18 VDC, 800Ω at 24 VDC, 1400Ω at 36 VDC; meets NAMUR NE43 recommendations. If for any reason you are not satisfied with order, please contact us directly BEFORE opening a case or contacting eBay. We will make every effort to resolve any issues that may arise in a timely manner. Returns: We operate according to the return policies of eBay. If your item arrives damaged, doesn't match the listing description, or is the wrong item, you can return it for a refund within 30 days. If you've changed your mind and want to return it, please contact me directly and we will do our best to assist.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Kurz
MPN	FD5081A
Model	454 FT-08-9
UPC	Does not apply
