L293d Motor Control Shield Motor Drive Expansion Board For Arduino Mo Qj

US $4.56

Shanghai, China
May 18th

Open on mobile:
QR code

L293D Motor Control Shield Motor Drive Expansion Board For Arduino Mo qj Features: L293D is a monolithic integrated, high voltage, high current, 4-channel driver.Basically this means using this chip you can use DC motors and power supplies of up to 36 Volts, thats some pretty big motors and the chip can supply a maximum current of 600mA per channel, the L293D chip is also what's known as a type of H-Bridge. The H-Bridge is typically an electrical circuit that enables a voltage to be applied across a load in either direction to an output, e.g. motor. 2 interface for 5V Servo connected to the high-resolution dedicated timer - no jitter! Can drive 4 DC motors or 2 stepper motors or 2 Servo Up to 4 bi-directional DC motors with individual 8-bit speed selection Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil or interleaved stepping. 4 H-Bridges: per bridge provides 0.6A (1.2A peak current) with thermal protection, can run motors on 4.5V to 36V DC Pull down resistors keep motors disabled during power-up reset button 2 external terminal power interface, for seperate logic/motor supplies Tested compatible for Mega, Diecimila & Duemilanove Package Included: Motor Drive Shield L293D*1

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Manufacturer Part Number	Does not apply
Model	//
UPC	Does not apply
MPN	Does Not Apply
Type	//
Brand	Unbranded
