La1016 Logic Analyzer 100mhz Max Sample Rate,16channels,10g Max Depth,pwm Output

US $109.00

shanghai, China
May 4th

Open on mobile:
QR code

LA1016 Logic Analyzer 100MHz max sample rate,16Channels,10G Max Depth, PWM output X2 software and user guide download link: please click here Description: Overview: Logic analyzer is the instrument that collects and displays the digital signal from the devices under test. It is mainly used for timing judgement and analysis. Unlike the oscilloscope with many voltage grades, it has only two grades (logic one and logic zero). After the reference voltage is set, the logic analyzer could decide from the test signal that the signal above the reference voltage is logic one, and the signal below is logic zero. The digital waveform is formed with 1 and 0. Compared with the oscilloscope, when testing and measuring the digital systems like MCU, ARM, FPGA and DSP, the logic analyzer could provide better accuracy, much more data and more complicated measuring methods. For example, if you are sampling a signal with the logic analyzer, the sample rate of which is 1Mhz, and the reference voltage is set to 1.5V, the logic analyzer would compare the current voltage with 1.5V would be low level (logic 0). Thus we get a sample point, and then we could link all these points (logic 1 and logic 0) to get a waveform, in which the user could see and analyze the timing of the signal, logic errors and the relation between each other. The figure below shows how the logic analyzer samples the signal: The Jiankun Logic analyzer include three models: LA1016, LA2016 and LA5016. Technical specification: Product type LA1016 LA2016 LA5016 Input Total number of channels 16 16 16 Max sample rate 100MHz 200MHz 500MHz Measurement bandwidth 20MHz 40MHz 80MHz Min pulse captured 20ns 12.5ns 6.25ns Hardware storage 1Gbits 1Gbits 512Mbits Hardware Sample depth 50M/channel 50M/ channel 32M/ channel Max compression depth 10G/ channel 10G/ channel 5G/ channel Input voltage range -50V~+50V -50V~+50V -50V~+50V Input impedance 220K?, 12pF 220K?, 12pF 220K?, 12pF Threshold voltage =1.6V high level =1.6V high level =2.0V high level PWM output Number of channels 2 2 2 Output frequency range 0.1~20MHz 0.1~20MHz 0.1~12.5MHz Min interval for frequency adjustment 10ns 10ns 8ns Min interval for pulse width adjustment 5ns 5ns 8ns Output voltage +3.3V +3.3V +3.3V Export impedance 50? 50? 50? power supply Power supply port USB2.0/3.0 USB2.0/3.0 USB2.0/3.0 Standby current 130mA 150mA 300mA Maximum active current 260mA 300mA 550mA PC software Supported protocols UART(RS-232/485/422)?I2C?SPI?CAN?DMX512?I2S/PCM? Manchester?1-Wire?Simple Parallel?UNI/O Supported OS Windows XP?Vista?Windows 7/8(32bit/64bit) Features: 1. English software, support Win XP, Win 7/8 (32/64 bit) 2. User friendly interface, Powerful analysis function 3. Support decoder: UART(RS232/485/422), I2C, SPI, CAN, DMX512, I2S/PCM, Manchester, 1-Wire, UNI/O, etc. 4. Data display format: Decimal/ hex/ bin/ ASCII 5. Support data export, for save or other softwares use 6. Free online automatic upgrade csv format export example: (also support txt, bin, etc.) Package include: 1. LA1016 X1 2. 9P colorful wire (8 channels+1GND) X3 3. 2P Wire X2 4. Test hook X20 5. USB cable X1 6. CD-ROM X1 Shipping Details: Please note: If the item is urgent for you, please choose "Expedited shipping"! How to track your parcel? Please click here Different country has a different Customs policy. You can contact us at any time if you have any problem or some special requirements . We will reply to you As Soon As Possible! Communication & Feedback At first, we appreciate every customer feedback. We would be very grateful if you can give us some advice on our products. If you have any complaints, you can contact us and we will actively find a suitable solution. No communication and leaving the neutral or negative feedback may not advisable and cannot solve any problems. Welcome! We wish you a happy shopping here!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Jiankun
MPN	LA1016 Logic Analyzer
Model	LA1016
Country/Region of Manufacture	China
