Labeler Ctm 360 Merge Wipe-on

US $6400

Chicago, Illinois, United States
May 24th

Open on mobile:
QR code

CTM 360 MERGE WIPE-ON WITH STAND AND PRODUCT DETECTOR SERIAL NO. 360-3242-0604 360a Series Label Applicator The 360a Series Label Applicator evolved from the industry standard 360 Series Platform. The 360a can be configured as a merge, blow-on or tamp-blow applicator, 5", 7.5" or 10" widths and each module can also be easily switched to the opposite hand with few or no change parts in a minimum amount of time. All units are stepper motor driven to include State-of-the-art electronics and a “Self-teaching” label sensor. File encryption of the 360a allows for easy “on-site” software revisions and upgrades. Specifications · Label Sizes · Label Roll Size · Stepper Motor · Control · Operator Interface · Labeling Speeds Specifications Series 360a Voltage 120 VAC 240 VAC Available Current 5 amps Frequency 50/60 Hz Phase Single Air Consumption @ 60-90 psi. Up to 4 CFM Label Placement ± 1/32 in Air Blow Width 28 in Air Blow Height 24 in Air Blow Depth 27 1/2 in Merge Width 29 in Merge Height 25 in Merge Depth 27 1/2 in Tamp Width 28 in Tamp Height 22 1/2 in Tamp Depth 27 1/2 in Product Sensing Retroreflective scanner provided as standard, other types available Label Sizes Min. Air Blow (W x L) 3/4 x 3/4 in Max. Air Blow (W x L) 7.5 x 9 in Min. Merge (W x L) 3/4 x 3/4 in Max. Merge (W x L) 10 x 20 in Min. Tamp (W x L) 3/4 x 3/4 in Max. Tamp (W x L) 10 x 10 in Label Roll Size Max. OD Core 12 in Max. ID Core 3 in Optional 16" OD or 20" OD x 3" or 6" ID cores Stepper Motor The 360 stepper drive uses a micro pulse driver for increased accuracy and performance, and is programmable to dispense labels at up to 3000 inches per minute. Control The 360a features a combined power supply, amplifier and position controller to comprise a single drive package. The new single axis digital stepper / servo controller controls up to five tasks simultaneously plus management of variables with expanded I/O making this drive well-suited for the most demanding production applications. The 360a controller is also equipped with onboard I/O prewired to external connectors to accommodate the following: low label - single, double or triple lightstack web break - encoder velocity compensation loose loop control - product shape profiling imprinting - zero downtime configuration Each machine is shipped preprogrammed and can have the additional hardware installed at a later date for simple “plug n play” operations. The electronic control assembly is packaged as a module and can be easily removed for repair or replacement, eliminating costly downtime and servicing. Operator Interface The 6", 256 color, TFT touch screen operator interface provides a bold, bright, high contrast display with self-diagnostic platforms and multi-level intuitive set-up features. RUNS FINE BRIAN 773 972-8120
