Lark Engineering Attenuator,variable Model Mt-511 Nsn 5985-00-476-8271

US $21.50

Farmingdale, New York, United States
Jan 29th

Open on mobile:
QR code

LARK ENGINEERING CO., ATTENUATOR,VARIABLE MODEL MT-511 NSN 5985-00-476-8271 US ARMY P/N10658397 NOS CONDITION. NOT USED. 14 DAY WARRANTY FOR COMPLETE REFUND. TELEDYNE WIRELESS P/N MT-511 NIKE HERCULES TAG DATE 2/84 Name Value III APPLICATION DESIGN TRANSMISSION LINE BODY STYLE COAXIAL TYPE OVERALL LENGTH 7.625 INCHES NOMINAL CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO LENGTH 4.000 INCHES NOMINAL CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO WIDTH 2.000 INCHES NOMINAL OVERALL HEIGHT 2.250 INCHES NOMINAL OVERALL WIDTH 2.750 INCHES NOMINAL MOUNTING SLOT WIDTH 0.156 INCHES NOMINAL MOUNTING SLOT LENGTH 0.250 INCHES NOMINAL VOLTAGE STANDING WAVE RATIO 1.15 COAXIAL CONNECTOR SERIES DESIGNATION C POWER RATING 500.0 MILLIWATTS AVERAGE INSERTION LOSS AT MINIMUM ATTENUATION IN MAXIMUM DECIBELS 1.0 OVERALL ATTENUATION RANGE IN DECIBELS +0.0/+20.0 ATTENUATION ACCURACY REFERENCE FREQUENCY 70.0 MEGAHERTZ ATTENUATION VARIATION METHOD STEPPED STEP POSITION QUANTITY 7 ATTENUATION PER STEP IN DECIBELS 0.5 AND 1.0 AND 2.0 AND 3.0 AND 6.0 AND 10.0 AND 20.0 MOUNTING FACILITY TYPE AND QUANTITY 4 SLOT FREQUENCY RANGE 50.000 MEGAHERTZ MINIMUM AND 70.000 MEGAHERTZ MAXIMUM OVERALL ATTENUATION ACCURACY IN DECIBELS -0.10/+0.60 SEGMENT ATTENUATION RANGE IN DECIBELS +0.50/+3.00 AND +3.00/+6.00 AND +6.00/+10.00 AND +10.00/+20.00 SEGMENT ATTENUATION ACCURACY IN DECIBELS -0.10/+0.10 AND -0.20/+0.20 AND -0.30/+0.30 AND -0.60/+0.60 ADJUSTMENT DEVICE TYPE AND QUANTITY 9 LEVER MOUNTING FACILITY PATTERN FOUR POSITION RECTANGULAR IMPEDANCE RATING IN OHMS 50.0 INPUT-OUTPUT TERMINAL TYPE AND QUANTITY 2 CONNECTOR, COAXIAL, FEMALE

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	LARK ENGINEERING CO
MPN	5985-00-476-8271
Model	MT-511
Country/Region of Manufacture	United States
