59047 - Larsen & Toubro Ltd. Planet 50 Non-Invasive Transport Monitor (ECG, SpO2, Temp, NIBP, Printer) Click Thumbnail for Full Image Description: Display: High Resolution Color TFT: size (10.4' diagonal) Resolution: (640 x 480 dots) Excellent viewing from distance and angle. Sharp and high contrast TFT display technology. Waveform Field: Configurable screen for max. four waveforms, (ECG, SpO2, Resp.). Possible to view any 4 ECG leads, if 4 lead ECG cable is connected (5 lead version). Digital Field: HR/PR, SpO2, T1, T2 or ?T , IBP1, IBP2 & NIBP (sys., Dia., Dia., MN), EtCO2 and FiCO2 on screen display of alarm limits/status. Trace Speed: 12.5, 25 or 50 mm/sec for ECG, Invasive pressure wave forms and Plethysmopraph. 6.25, 12.5 or 25 mm/sec for respiration and CO2. Optical Encoder: Rapid access to all the functions and settings of parameters through single-knob. Quick action hard for alarm mute, NIBP start/stop, IBP Zero, Freeze and return to main screen. 3/5 lead ECG Monitoring: Automatic detection of 3 or 5 lead ECG cable. Display of I, II, III aVR, aVL, AVF and V for 5 lead mode. Built-in cautery and defibrillator protection. HR range: 30-270 bpm Monitoring: 0.5 Hz – 100 Hz Diagnostic: 0.05 – 100 Hz Respiration: Impedance pneumography principle. Display of respiration wave form with respiration rate. Respiration rate: 5 to 150 bpm User selectable aponea alarm delay: 5 to 90 seconds (in steps of 5 seconds). Temperature: Simultaneous monitoring of 2 channels. Dual temperature display, T1 & T2), with T if difference is less than 48?F (9?C) Temperature range: 53 ?F to 109.4 ?F (12 ?C to 43 ?C) Pulse Oximetry: Pitch variation with change in oxygen saturation. SpO2 range: 0 – 100% Display of pulse strength, plethysmograph and SpO2 values. Accuracy: 100 to 70% (+/- 2 digits) 69 to 50% (+/- 3 digits) 49 to 0% (unspecified) Accuracy in neonatal monitoring 100 to 70% (+/- 3 digits). Non-Invasive Blood Pressure: Oscillometric principle. Display of Systolic, Diastolic & Mean. Modes: Manual, STAT (continuous 5-minute operation) and Automatic (time interval 2-minutes to 90 minute selectable). Alarm Limits selection possible for Systolic & Diastolic. Range: 20 to 255 mmHg Accuracy: +/- 5 mmHg Alarms: Alarm setting for all parameters. Patient alarm: RED Flashing with audio and message indicator. Equipment alarm: YELLOW flashing with audio and message indicator. Alarm suspend: Continuous YELLOW. Auto setting of alarms for HR/PR, SpO2 Respiration Silencing: 3 min for current alarm only. All age groups advisory/warning. Alarm recall: last 16 alarm events with time, date and message Trends: 24 hrs of graphical and tabular trend for HR/PR, SpO2, and Resp. NIBP trend: 240 readings tabular Trends: 30-second storing. 2-hour zoom for graphical trends with mark and print facility. Date Time stamping for trends. Recording: Printing of single lead ECG, Numerical data and patient information on ink-jet printer. External recorder connection available. General: Dimension: 8' H x 12.2' W x 9.05' W (202 x 310 x 230 mm) Weight: 16.5 lbs (7.5 Kg), with built-in batteries. Direct interface possible with 'SKYLINE' Multi-lingual option available. Power Supply: Universal power: 110V/230V AC, 50/60 Hz Power ratings: 60W Built-in, rechargeable battery for 2 hours of continuous operation under ideal & full-charge condition (typical). Battery type: 6V 4Ah lead acid – 2 nos Charging time: 12 hours (typical) Ambulatory monitoring possible with car battery interface. Designed to meet the requirements of Following international standards: Class 1, Type CF of IEC 601-1 Level 2 of IEC 1000-4-4 and IEC 10004-5 Shipping: Item is shipping from Big Lake, MN 55309. This item will be shipped UPS ground. A fixed shipping charge of $26 will be charged in the lower 48 United States. Warranty: This item comes with a 30 day warranty. During that time we will refund the purchase price (less shipping). Refunds will be given once the item is received. This item is pre-owned. Common sense dictates that before it is used in conjunction with patient care, it should be checked out thoroughly by your professional biomedical staff. We will not warranty items if buyer does not follow our shipping recommendations listed above. Calibrated or sensitive electronic equipment should be sent "air ride, blank wrapped" and should not be sent straight freight if it is too large for UPS limits. Payment: We accept PayPal, Visa, MasterCard, and American Express. Payment must be made in full within 48 hours of winning auction. Tax: Buyers in Minnesota will be charged sales tax About Scientific Equipment Liquidators, Inc. This is a corporate ebay account, questions will be answered Monday through Friday. Scientific Equipment Liquidators has been in business since 1977 and is located in Big Lake, MN. We buy and sell used medical equipment from 1 piece, 1 department, or an entire hospital. We deal in all disciplines of used medical equipment. Phone 888-248-8221. Company website is http://MedUsed.com eBay's Required Disclosure for Medical Equipment: "The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, I will verify your status as an authorized purchaser of this item before shipping of the item." If you have questions about legal obligations regarding sales of medical devices, you should consult with the FDA's Center for Devices and Radiological Health: Links: http://www.fda.gov/cdrh/devadvice/ or http://www.fda.gov/cdrh/industry/support/index.html
