Lasico 1282-36 Planimeter Graphic Digitizer - Stand-alone Or Computer Interface

US $875.00

Ridgecrest, California, United States
Jan 30th

Open on mobile:
QR code

Lasico 1282-36 Planimeter - Graphic Digitizer with 36 inch Arm NEVER USED - EXCELLENT CONDITION Manufacturer direct price is $1,750 plus tax & freight The 1282-36 Model is equipped with a table clamping base which secures the device to the table. This configuration provides greater security within an office environment. The instrument is fixed in place, reducing the potential for mid-stream error due to a "base movement". The 1282-36 model can be used on tables with tilt angles in excess of 15 degrees. Where-as the weighted base models require the purchase an optional clamp kit (#1286-19) to secure the instrument to the table. The 1282-36 Model is configured with a 36 inch / 91 cm arm. The length of the arm determines the measuring range. The size of the drawing or blueprint to be evaluated, as well as the size of the table on which the measurements are performed, determine the area capacity of the arm. MODEL NUMBER MEASURING RANGE INSTRUMENTAL ACCURACY LINEAR RESOLUTION AREA RESOLUTION 1282-36 4X6 ft +/- 0.020 in / 0.508 mm 0.003" / 0.076 mm 0.000009 sq.in 0.0057 sq.mm The 1282-36 digitizer provides an active measuring range of a half circular shape (when the base of the instrument is positioned at the center of the right or left edge of the table). However the practical range can be found within a semi circle with a 5 ft. radius for the model 1282-36. For example: Model 1282-36 could cover an area with a length of 9 feet. Its typical ranges include 36x108". If you need more width range, the length range is reduced. The graphic image below will explain this. Each square represents 1 Sq ft / 0.09 sq.m of area coverage. Large display panel: Shows measuring and counting results or X/Y coordinates in any measuring unit desired. Scaling is fully automatic. LED indicators verify the active operating mode. The enclosure can be tilted and rotated for optimal viewing angles. The keypad: Is used to enter scale ratios, define coordinates, select hardware drivers, manipulate results via a built in calculator and set various operating parameters. It can also be used for numerical data entry. The instrument cursor: Glides smoothly with very little friction and provides excellent support for the guiding hand. Studies have shown this system to be superior to a pen stylus with 15-20% better control and speed. For normal use, virtually all essential digitizer functions can be controlled via the cursor switches. All switches have dual functions and the switchpad includes directional keys for work in spreadsheets. A cursor handle switch can be programmed to control most functions. FEATURES: The 1282-36 Model can be used on any table with a clampable edge. The instrument is readily preprogrammed for scale compensated area and length measurements and for use as a digitizer. Measurements can be performed in the point mode (for regular shaped figures and lines), the stream mode (for irregular shaped areas and lines), or a combination of both. Any scale ratio can be used; Imperial, Metric or arbitrary. Scale ratios can be determined automatically by measuring a known length or a known area. Built in conversion from and to different measuring units. Results can be manipulated via a built-in calculator. Instrument is designed for true right or left hand operation. Standard 16 button cursor with directional keys, 24 button keypad. Battery protection for scales, decimal settings, drivers, parameters, etc. Computer interface with multiple hardware drivers for great versatility. Automatic averaging of results. Programmable memories for creation of special measuring constants for slope correction, volumetric computations, etc. Key programmable short program routines. Coordinates can be sent to computer in either switch or stream mode. Coordinates can be biased in any direction desired. Relative and absolute angle measurements. Measuring results can be accumulated or subtracted from each other. Facility for determination of the centroid and the first moment of plane areas. Built-in item counter with separate scaler can be activated via cursor button or optional item counter pen with ink cartridge. Tracer handle switch can be assigned to control most functions. Minimal desk space required: Space is at a premium in most offices. The 1282-36 needs only a 7 inch strip of table space when parked. Computer interface drivers: Computer interface drivers are readily installed to assure communication with most computers and programs. Stand Alone System: As a “stand alone system”, the 1282-36 model provides fully scale compensated area and length results, X/Y coordinates, and item counts as well as angle and centroid measurements. Payment Options: PayPal accepts Visa, MasterCard, Discover, American Express and eCheck. And, you are no longer required to start a PayPal account to pay by credit card! We also accept Visa, Mastercard, American Express, Discover and Virtual Check. Just give us a call after the auction closes and we will process your credit card payment over the telephone. Shipping & Handling: United States Continental 48 states destinations; The shipping price is included within the item price. Your item will be shipped either same business day or next business day, fully insured, via UPS Ground (1 to 7 calendar days). Alaska, Hawaii, Puerto Rico and APO destinations; The shipping price is included within the item price. However, a surcharge is added to absorb the increased cost to these distant US destinations. Go to the "Shipping Tab" above to find the surcharge amount. Your item will be shipped either same business day or next business day, fully insured, via USPS Priority Mail (3 business days). If purchasing multiple items, or if you require a different carrier service or a "next day delivery" service, then simply email us for a "freight cost" quote. Please send your request prior to placing a bid or purchase. Shipping & Handling: Canada Canada; Your item will be shipped either same business day or next business day, fully insured, via USPS Priority Mail International (6 to 10 business days). Please go to the "Shipping Tab" above to find the Canada shipping price. All Other Select International Destinations; Your item will be shipped either same business day or next business day, fully insured, via USPS Priority Mail International (6 to 10 business days). Please go to the "Shipping Tab" above to discover our international shipping destinations. Simply send us an email requesting a "freight cost" quote and we will reply post haste. Please send your request prior to placing a bid or purchase. If purchasing multiple items, then please email a request for a combined shipping "freight cost" quote and we will reply post haste. Please send your request prior to placing a bid or purchase. Replacement Policy: Should your new item(s) arrive damaged by the freight carrier, or should your new item(s) arrive with manufacturing defects, then simply contact us via telephone or email (within 3 days of item receipt). We will arrange for the freight carrier to return the item to us within 14 days and we will replace your item. It's that simple. The returned item must be UNUSED. We reserve the right to inspect the returned item prior to shipping the replacement. Return Policy: Should you opt to return your item for any reason, then simply contact us via telephone or email (within 3 days of item receipt). Return the item, in the original box if possible, within 14 days and we will promptly refund the "item cost" (minus the original shipping cost). It's that simple. A 15% restocking fee will be applied to the refund. The returned item must be UNUSED and in the original packaging. We reserve the right to inspect the returned item prior to issueing a refund.

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“I purchased 3 of these planimeters from LASICO about 5 or 6 years ago. I have used only one since. The other two are unused. This auction is one of the unused planimeters.”
