Lc100a Digital Lc Meter Inductor Capacitor Inductance Capacitance Cap Tester

US $590

Shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Test Equipment GPS Antenna GSM 3G Antenna Other Antenna RF Cable Assembly RF Connector RF Adapter LC100A Digital LC Meter Inductor Capacitor Inductance Capacitance CAP Tester Product description : click to browse more test equipment~ NEW Arrival! 100% BRAND NEW & HIGH QUALITY! Features: Based on the L/C resonance principle High speed microcontroller’s precision computation Measuring range below 1uH and 1pF Especially qualify in microwave manufacture and measuring switching power supply transformer, filter inductance and so on. LC100-A has four measuring range position: 1. C range ........Capacitance (0.01pF-10uF) 2. L range ........Inductance (0.001uH-100mH) 3. Hi.L range ......Big inductance (0.001mH-100H) 4. Hi.C range ......Big capacitance range (1uF-100mF) Specification: Measurement Accuracy: 1% Capacitance Measurement Range: 0.01pF-10uF Min. Resolution: 0.01pF Inductance Measurement Range: 0.001uH-100mH Min. Resolution: 0.001uH Large Inductance Measurement Range: 0.001mH-100H Min. Resolution: 0.001mH Large Capacitance Measurement Range: 1uF-100mF Min. Resolution: 0.01uF Frequency Measurement: L Files/ C Files: 500 KHz, HL Files: 500Hz display the current frequency value Effective Display Digit: 4 Display Mode: 1602 LCD Power Supply: mini USB interface or 5V power Weight: 60g Direction for use ⑴. Switch on the L/C Meter ⑵. Chose the corresponding files, inductance: Lx, capacitance: Cx, big Inductance: Hi.L, big capacitance: Hi.C. Display as follows (testing terminal open loop) : Inductance:MEASURE Lx OVER RANGE Capacitance:MEASURE Cx 0.00pF Big inductance:MEASURE Hi.L OVER RANGE Big capacitance:MEASURE Hi.C 0.00pF Display as follows (testing terminal short circuit): Big inductance:MEASURE Hi.L 0.000mH Inductance:MEASURE Lx 0.000uH Capacitance:MEASURE Cx OVER RANGE (3).When testing terminal open loop the measured value of capacitance is not “0”, or witch of the inductance is not “0” as the testing terminal short circuit, you can reset to “0” by ways of capacitance model and inductance model, as follows: (a) Capacitance model Press red button as testing terminal open loop, it displays “CALCULATING…”, keep pressing for one second, when“CALCULATING…OK” displayed, release the red button, resetting to “0” is finished, and “0.00pF” is displayed, and then capacitances can be measured. (b) Inductance model Press red button as testing terminal shirt circuit, it displays“0.000uH” or “0.000mH”, and then inductances can be measured. (4). Please press black function button as results displayed, and corresponding frequency will be displayed. Note: 1. Please reset to “0” before testing a capacitance or an inductance, or errors may be appeared. Even if “0” displayed before measuring, resetting to “0” is needed. 2. At the time of resetting to “0”, when“CALCULATING…OK” appeared, please keep pressing for 2 to 3 seconds, and the parameter written to “<DATASAVED>” will be prompted, then release. 3. Reset to “0” is forbidden as components are being measured. If you do it, please shut down immediately and restart, then reset to “0”. 4. The time of measuring a big capacitance (above 10mF) may be more than one second, and it needs seven to eight seconds to get the measured value of the capacitance (100mF). 5. Forbid to measure a capacitance which is not discharged, otherwise it may damage the mainframe. Package content 1pcs LC100-AL/C Meter 1pcs mini USB cable, user manual Recommend Products Digital LCD Watt Meter Power Volt Amp Meter RC Battery Analyzer 60V 100A DC NEW New 5pcs Silicone High Voltage Banana to Banana Plugs Test Leads Cable 5 Colors 1Set Dual Injection 4mm Banana to Banana Male Plug Test Probe Leads Cable 1M 15A 30pcs 5 Colors SMD IC Logic Analyzer Mini Grabber Test Clip Hook Probe Jumper 20pcs Insulated Shroud Stackable 4mm Banana Plugs Connectors Male Jack Red Black Dual Display Green Red LED Digital Current Voltage Panel Meter DC0-100V 10A 0.28 15V DC Analog Panel Meter Voltage Volt Meter Voltmeter White 0-15V 65*56mm 85C1 DT-9205M Digital Multimeter Voltmeter Ammeter Ohmmeter Capacitance Tester LCD Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	TOOL079-100LC
Measurement Accuracy	1%
Power Supply	mini USB interface or 5V power
Display Mode	1602 LCD
