LCD Display Signal Generator PWM Pulse Frequency Duty Cycle Adjustable Module Description: LCD display frequency and duty cycle, very clear, PWM output can be set to the frequency and duty cycle; Wide frequency range, high precision; Serial communication, TTL level First, the module description PWM output, you can set the frequency, duty cycle; Frequency is divided into four ranges, automatic switching: XXX (no decimal point): the smallest unit is 1Hz, the value range of 1Hz ~ 999Hz; X.XX (decimal point in the hundred) the smallest unit is 0.01Khz, the range of 1.00Khz ~ 9.99Khz; XX.X (decimal point in ten): the smallest unit is 0.1Khz; value range of 10.0KHz ~ 99.9KHz X.X.X (decimal point in ten and hundred): the smallest unit is 1Khz; value range 1KHz ~ 150KHz frequency display: 100 indicates PWM output 100Hz pulse; 1.01 indicates PWM output 1.01K pulse; 54.1 indicates that the PWM output has a pulse of 54.1 kHz; 1.2.4 indicates that the PWM output is 124 kHz pulse; Duty cycle range: 0 ~ 100%; All set parameters, power-down automatically saved. Second, the parameter settings The module has four independent keys, used to set the frequency and duty cycle, support touch (increase or decrease a unit) and long press (fast increase or decrease), set the parameters automatically save, power down Not lost. Third, the module parameters: Working voltage: 3.3 ~ 30V; Frequency range: 1Hz ~ 150KHz; Frequency accuracy: the accuracy in each range is about 2%; Signal load capacity: the output current can be about 5 ~ 30ma; Output amplitude: PWM amplitude equal to the supply voltage; Ambient temperature: -20 ~ +70 . Fourth, the scope of application: Used as a square wave signal generator, generate square wave signal for experimental development and use; Used to generate a square wave signal that controls the motor driver; generate adjustable pulse for MCU use; generate adjustable pulse, control the relevant circuit (PWM dimming speed and other applications). 5, serial control (single-chip TTL level communication) Communication standard: 9600 bps Data bits: 8 Stop bit: 1 Check digit: none Flow control: none 1, set the frequency of the PWM "F101": Set the frequency to 101 HZ (001 to 999) "F1.05": set the frequency of 1.05 KHZ (1.00 ~ 9.99) "F10.5": Set the frequency to 10.5KHZ (10.0 ~ 99.9) "F1.0.5": set the frequency of 105KHZ (1.0.0 ~ 1.5.0) 2, set the PWM duty cycle "DXXX": set the PWM duty cycle to XXX; (001 ~ 100) Such as D050, set the PWM duty cycle is 50% 3, read the set parameters Send a "read" string to read the set parameters. Package Included: 1PC*PWM Signal Generator Shipping Feedback Payment Return/Refund Shipping We will ship to worldwide by 1) Standard Economy Airmail , or 2) Registered Airmail with Tracking. It takes approximately 18 to 35 working days for delivery (business days – excluding holidays), kindly be patient. If you do not receive your delivery within the specified time frame, please contact us via eBay message for assistance. Kindly ensure that your delivery address in eBay & Paypal are the same to avoid delivery failure. Any non-received item caused by invalid address is not eligible for refund or replacement. Please ensure your purchased item(s) can be lawfully imported into and complies with all laws and regulations of the destination country. IMPORTANT NOTE: Custom duty is obligation and liability. Buyers are responsible for import duties, custom fees and taxes, if any. Kindly check with your country’s custom office to determine the additional costs impose on the item prior to purchase. We are NOT responsible for the additional costs incurred related to import duties, custom fees and taxes. Please leave a note in eBay ONLY if you got special request (e.g. colour). Kindly note that special request is subject to availability; we does NOT guarantee for random ship items. Feedback We will greatly appreciate your positive feedback and all 5-star DSRs. If we have not given you reason enough for 5-star grades on each DSR, please let us know how we can earn your 5 star rating before submitting your scores. Payment We accept PayPal payment only, and must be received within 3 days from the date of purchase. Please leave note in PayPal when making the payment if you have any special requests. Orders will be processed instantly and dispatched within 1-2 days, so we do NOT accept any email/message note after you place orders. IMPORTANT! PLEASE READ! Buyers are responsible for import duties, custom fees and taxes, if any. Please check with your country Return/Refund Kindly examine your parcel upon receiving your purchase and inform us via eBay message of any damage/defects with clear photographs/pictures/videos as proof within the first 24 hours upon receiving your purchase. NO claims will be liable or entertain after this time period. If you are not happy with your purchase for valid reason, you can return the product to us within the first 14 days after receiving the product. All shipping charges (both ways), handling and packaging costs will be charged to the buyer. The product must be sent back to us in original condition with no defect (new, unused and unopened) within first 14 days of receiving the product. No scratches, damages whatsoever & No altering of any part of the item. Original box/documentation/accessories (if any) and packaging. Buyer is responsible for return shipping cost. Please allow up to 5 working days to process your return items.
