Lcd Transistor Tester Diode Capacitance Inductance Resistance Frequency Meters

US $45.99

Weinan, China
Aug 31st

Open on mobile:
QR code

LCD Transistor Tester Diode Capacitance Inductance Resistance Frequency Meters Description Multi-functional transistor tester for automatic detection of NPN and PNP transistors, FET, diodes, dual diode, thyristor, SCR, automatic identification of the transistor pinout. It also can be used as square signal and PWM signal generator. Feature: Digital LCD display for easy readings of data and graphics. Rotary switch control. Main chip is the DIP, easy for electronic enthusiasts to DIY or update. Uses 9V battery (not included) or use DC power (DC 6.8-12V). Automatic shutdown (shutdown current is about 20nA). Test NPN and PNP transistor common-emitter current amplification factor, the base-emitter threshold voltage, off the collector - emitter leakage current. Support 2 resistors measurement, show its positive and negative, on-state voltage. Resistance measurement maximum resolution 0.01, can be measured up to 50M. Automatically test the pins of a component and show on the display. Measure FET gate threshold voltage and gate capacitance. For the following 2100 resistor while measuring its inductance measuring range from 0.01mH - 20H. Can be used as signal generator and frequency meter: frequency range from 1Hz-2MHz and can generate 1%-99% PWM (pulse width modulation) signals. Notice: Before measuring capacitance, the capacitor must be discharged, otherwise it can very likely damage the meter. Specification: Display: 160 x 128 LCD Power supply: 9V Battery (not included), DC 6.8-12V Current: Approximately 30 mA Resistance measurement: Max. 50M Resistance resolution: 0.01 Capacitance measurement: 25pF - 100mF Capacitance resolution: 1pF DC voltage measurement: Up to 50V Screen size: 3.7 x 3 cm (1.45 x 1.18 in) PCB size: 7.8 x 6.2 cm (3.1 x 2.44 in) Package Includes: 1 * Resistance Inductance Capacitance Meter ESR Detector 1 * Transparent Case

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Supply Voltage	DC 6.8 -12V or 9V Battery
Type	Logic ICs
MPN	6742134130
Model	diymore GM328A
Brand	Unbranded
Modified Item	No
Application	Computer
Country/Region of Manufacture	China
Dissipation Power	Transistor Tester
Product	Impedance/Gain-Phase Analyzer
Operating Temperature	-20 -65
Custom Bundle	No
UPC	Does not apply
