Lcd12864 3.3v Blue Backlight Graphic White Character Module Lcm 12864 Lcd

US $110

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Product Name: 12864 LCD12864 LCD 128*64 3.3V Blue Backlight Graphic White Character module LCM More Items In Our Store,Click Here! SKU: 1607 Parsts No. : Package: Brand: Quantity: 1 3.3V voltage, please take notice before test, to avoid any higher voltage caused damages The controller of this LCD is a ST7920: Items size unit Module volume 93 X 70 X13 mm View area 72 X40 mm Point distance 0.52 X 0.52 mm Point size 0.48 X0.48 mm Parallel mode interface definition: Pin number definition level Function specification 1 VSS 0V Power supply negative 2 VDD +3.3V Power supply positive 3 V0 - Contrast control 4 RS H/L RS=H:shows data RS=L:controls instruction 5 R/W H/L R/W+H,E=H,data was read DB7-DB0 R/w=L,E=H=L:the data of DB7-DB0 was written to IR or DR 6 E H/L Enable pin 7-14 DB0-DB7 H/L Data line 15 PSB H/L PSB=H,parallel mode,PSB=L,serial mode 16 NC - Empty pin 17 /RESET H/L Reset terminal,low level valid 18 Voult - Module drives voltage output terminal 19 A +3.3V Backlight power supply positive 20 K 0V Backlight power supply negative Serial module interface definition: Pin number definition level Function specification 1 VSS 0V Power supply negative 2 VDD +3.3V Power supply positive 3 V0 - Contrast control 4 CS H/L Chip selection terminal,high level valid 5 SID H/L Serial data input terminal 6 CLK H/L Serial synchronous clock 15 PSB H/L PSB=H,parallel mode,PSB=L,serial mode 17 /RESET H/L Reset terminal,low level valid 19 A +3.3V Backlight power supply positive 20 K 0V Backlight power supply negative Model:12864 Show: 16 Character x4 lines (WxH) 72x40 mm backColor: blue Size(WxHxT): 93.0x70.0x13.0 mm Quantity: 1 Voltage: 3.3V Dot Pitch(WxH):0.52x0.52mm Dot Size(WxH): 0.48x0.48mm Data Download Other Character Display LCD Modules IIC LCD Display Series TFT LCD Display Series Nokia LCD Display Series Dots Matrix LCD Display Modules MCU Chips 1. ATMEl AVR MCU 2 PIC MCU 3. STM32 MCU 4. C8051F 5. MSP430 MCU 6. 51 STC MCU Maybe you request 10pcs NEW 40Pin 1*40 2.54mm 20mm Long Header Pin Male Breakable Pin Header 65pcs Breadboard tie line Wire Breadboad + MB-102 Solderless breadBoard PCB Test 10pcs 2.54 Socket Connector 40 Pin 1x40 Female NEW 1PCS Board MB102 Breadboard Power Supply Module 3.3V/5V For Arduino good NEW 100pcs Dupont Head 2.54mm 4P 1x4P Dupont Plastic Shell Pin Head $ 2.43 + free shipping $ 6.25 + free shipping $ 1.61 + free shipping $ 2.69 +free shipping $ 2.46 + free shipping Any problem, please contact us freely 1) We accept PayPal payment ONLY. inkFrog Analytics
