Lcr-t4 12864 Graphical Transistor Tester Resistance Capacitance Esr Scr Meter

US $15.99

US, United States
Jun 7th

Open on mobile:
QR code

Specifications: Resistor: 0.1ω-50Mω Capacitor: 25pF-100000uF Inductance: 0.01mH - 20H Working power: DC-9V Standby current: 0.02uA Operating current: 25mA Material: Metal+Plastic Size: about 11.1cm/4.37"x2.6cm / 1.02"x8.5cm/3.34" [Conversion: 1cm=0.3937 inch, 1inch=2.54 cm] Features: 1. Support boot voltage detection function 2. Automatic detection of NPN and PNP transistors, N-channel and P-channel MOSFETs, diodes (including dual diodes), thyristors, triodes, resistors, and capacitors. Automatically testing the component leads and displaying them on the LCD 3. The forward bias voltage of the emitter transistor can be determined by detecting the amplification factor and base number of a transistor, a MOSFET protection diode, and the like 4. Measure gate threshold voltage and gate capacitance MOSFET 5. The display uses 12864 lcd LCD (128 * 64 characters) 6. High test speed, valid component test: In 2 seconds (except in larger capacitors, large capacitance measurement also takes a long time, the measurement time in 1 minute is normal) 7. One-button operation, power-on test. 8. Power Consumption Shutdown Mode: Less than 20 nA 9. Automatic shutdown function can avoid unnecessary waste, save battery energy and improve battery life. Package includes: 1 x LCR-T4 12864 LCD Graphical Transistor Tester

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Brand	Unbranded
UPC	Does Not Apply
