Lcr-t4 Esr Meter Transistor Tester Diode Triode Capacitance M328 Scr Inductance

US $9.28

ShenZhen, China
Aug 27th

Open on mobile:
QR code

Home Arduino Module Sensor Chips About Us Features : 1,M328 version of the software ,more functions.Chip: Atmega328 2.128*64 big Backlight LCD display,only 2mA when stand by. 3.Using 9V battery (Not included) Test ranges: Inductors, capacitors , diodes, dual diode , mos, transistor, SCR , the regulator, LED tube , ESR, Resistance,Adjustable potentiometer Resistance :0.1 ohm resolution, maximum 50M ohm Capacitor :25pf -100,000 uf Inductors : 0.01mh-20H Function: 1:Automatic detection of NPN and PNP transistors, n-channel and p-channel MOSFET, diode (including double diode), thyristor, transistor, resistor and capacitor and other components 2: Automatic test the pin of a component, and display on the LCD 3:Can detect the transistor, MOSFET protection diode amplification coefficient and the base to determine the emitter transistor forward biased voltage 4: Measure the gate and gate capacitance of the MOSFET threshold voltage 5:Use 12864 liquid crystal display with green backlight Specifications: For you reference 1.One -button operation, automatic shutdown . 2.Only 20nA shutdown current. 3.Automatically detect NPN, PNP bipolar transistors , N -channel and P -channel MOS FET, JFET , diodes , two diodes, thyristors small power unidirectional and bidirectional thyristor. 4.Automatic identification components pin arrangement . 5.Measuring bipolar transistor current amplification factor and base - emitter threshold voltage. 6.Via the base - emitter threshold voltage and high current amplification factor to identify Darlington transistors. 7.Can detect bipolar transistors and MOS transistors protection diodes. 8.Measuring the gate MOS FET threshold voltage and the gate capacitance. 9.Can simultaneously measure two resistors and resistor symbol is displayed. Displayed on the right with a decimal value of 4 ,Resistance symbol on both sides shows the pin number. So you can measure the potentiometer. If the potentiometer wiper is not transferred to an extreme position, we can distinguish the middle and both ends of the pin. 10.Resistance measurement resolution is 0.1 ohms , 50M ohms can be measured . 11.Can measure capacitanceCan measure capacitance of 30pF-100mF , resolution 1pF. 12.2uF more capacitors can simultaneously measure the equivalent series resistance ESR values. The two can be displayed with a decimal value , resolution 0.01 ohms. 13.Can be in the correct order and the diode symbol display two diodes , and gives the diode forward voltage. 14.LED is detected as a diode forward voltage higher . Combo of the LED is identified as two diodes. 15.Eeverse breakdown voltage is less than 4.5V Zener diode can be identified. 16.Can measure a single diode reverse capacitance. If the bipolar transistor connected to the base and collector or emitter of a pin , 17.It can measure the collector or emitter junction reverse capacitance . 18. can be obtained with a single measurement rectifier bridge connection. Notice: Before measuring capacitance , the capacitor must be discharged , otherwise very likely damage the meter . Package Include: 1 x Mega328 Transistor Tester Diode Triode Capacitance ESR Meter MOS PNP/NPN M328 Payment Shipping Refund Payment We accept PayPal only. But we only Accept your Ebay Address,Please Make sure it's 100% right. Payment must be received in 5 business days of auction closing. Please leave note for your special request (e.g. Colors or Size) in PayPal when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. Shipping Fill your shipping info Refund All package need to wait 30 days(US only need 7-10 days),Please take care it.Less than 30 days,we can't take a refund. If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. If is item is defective in 12 months, you can return it to us. We will send you a new replacement after receiving the defective item.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
EAN	Does Not Apply
MPN	Does Not Apply
Manufacturer Part Number	Does Not Apply
Product	LCR Meter
Herstellernummer	nicht zutreffend
Measurement Functions	L
Herstellungsland und -region	China
Model	M328 LCR-T4 with Battery Box
Marke	Markenlos
Modified Item	No
Produktart	Amateurfunkempfnger
Country/Region of Manufacture	China
Country//Region of Manufacture	China
Type	LCR-T4 Tester
Marca	LCR-T4 Tester
select	LCR-T4 Tester+Battery Box
GTIN	Does not apply
UPC	Does Not Apply
Marque compatible	Universelle
ISBN	Does not apply
